Beijing Flyingvoice technology Co.
,

User Manual

G201N4
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G201N4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Flying Voice Technology G201N4

  • Page 1: User Manual

    Beijing Flyingvoice technology Co. User Manual G201N4 Version 1.1...
  • Page 2 Beijing Flyingvoice technology Co. Revision Record Version Date Author Firmware Version Applicability V1.0 2013-07-22 Chen Jianjun V1.0 The initial version(lack of the panel pictures) V1.1 2014-01-02 Maylin second edition, update V3.05(201312311 based on the new firmware. 327)

  • Page 3: Table Of Contents

    3. IVR(Interactive Voice Response)....................4 3.1 The method of configuring a home gateway................ 4 3.2 Start IVR..........................4 3.3 IVR description........................4 3.4 Notice............................ 6 4. G201N4 webpage settings......................8 4.1 Login WEB page........................8 4.1.1 URL format........................8 4.1.2 About Passwords......................8 4.2 WEB Page..........................9 5 .Configure from web........................10...
  • Page 4 Beijing Flyingvoice technology Co. 5.5.1 Preferences......................37 5.5.2 Dial Plan........................40 5.5.3Phonebook.......................42 5.5.4 Call Log........................43 5.6 Diagnosis..........................45 5.7 Administration........................45 5.7.1 Management......................46 5.7.2 Firmware Upgrade....................49 5.7.3 Provision......................... 49 5.7.4 SNMP........................51 5.7.5 TR069........................52 6 Functions............................53 6.1 Making Calls........................53 6.2 Call Waiting........................53 6.3 Call Hold..........................

  • Page 5: Preamble

    Beijing Flyingvoice technology Co. 1.Preamble Thank you for choosing G201N4 VOIP home gateway products. G201N4 home gateway is a highly integrated access device, and it is a kind of high-end multi-in-one gateway product which based on IEEE802.11n standard. This product is for individual users, SOHO (Small Office or Home Office) and small enterprises to provide high-performance access.

  • Page 6: Indicators And Connectors

    Beijing Flyingvoice technology Co. 2.Indicators and Connectors Before you use the high speed home gateway G201N4, please get acquainted with the LED indicators and connectors first. 2.1 LED Indicators (1) The positive side panel （2）The rear panel （3）The left side panel...

  • Page 7: Hardware Installation

    Step 5.Check the Power and WAN, LAN LEDs to assure network connections. Warning: Please do not attempt to use other different power adapter or cut off power supply during configuration or updating the G201N4 VoIP home gateway. Using other power adapter may damage G201N4 and will void the manufacturer warranty.

  • Page 8: Ivr(Interactive Voice Response)

    Customer can use the IVR function by referring to the following steps： (1) Connect analog phone to G201N4’s phone port, and connect the device well, off-hook and press the "****" key to start the IVR, then the user will hear a voice prompt device "Please enter your option, one WAN Port ..".
  • Page 9 Beijing Flyingvoice technology Co. Operation Code Contents 1) Pick up the phone and press "****" key to start the IVR; 2) Select "1", then the device will broadcast the current WAN port connection type; 3) To change the WAN port network connection type, users hear "Please enter password" and enter the correct password, and end with "#"...

  • Page 10: Notice

    Beijing Flyingvoice technology Co. 3) Enter the new DNS address and ends with a "#"; ◆Please use "*" to replace ". ", for example, the user can enter 192 * 168 * 20*1 to set up the new DNS to be 192.168.20.1. ◆When enter the new DNS please ends with a "#"...
  • Page 11 ◆ When the WAN port network address type is set to static IP mode, user needs to set the IP address, subnet mask and default gateway; If set the device to work in DHCP mode, please make sure that DHCP Server is available in your exiting broadband connection to which WAN port of G201N4 is connected.

  • Page 12: G201N4 Webpage Settings

    Beijing Flyingvoice technology Co. 4. G201N4 webpage settings 4.1 Login WEB page G201N4 has an embedded Web server that will respond to HTTP get/post requests. User can use a Web browser like Microsoft's IE to login and then configure G201N4. 4.1.1 URL format Login web page URL format: http://WAN port IP address, for example, if your home gateway's WAN port IP address is 192.168.20.199, please enter in the address bar, enter the appropriate...

  • Page 13: Web Page

    Beijing Flyingvoice technology Co. 4.2 WEB Page Number Name Description Navigation bar Click navigation bar, many sub-navigation bar will appear in the place 2. Sub-navigation bar Click sub-navigation bar to enter to configuration webpage Configuration title The configuration title Configuration bars The configuration bars Display the firmware version, DSP version, Current Device Information...

  • Page 14: Configure From Web

    Press it to reboot G201N4 5 .Configure from web 5.1 Status On this page, users can view the G201N4 system information and system log information. It is the first page which user will see firstly after login to WEB. 5.1.1 System Information On this page, user can view the product information of G201N4, SIP account status, network status and system status.

  • Page 15: System Log

    Beijing Flyingvoice technology Co. 5.1.2 System Log In this configuration page, the user can view the system log, G201N4 system recordings contain important configuration information. On this page, users can click the corresponding button to refresh, remove and save the relevant...

  • Page 16: Network

    Beijing Flyingvoice technology Co. 5.2 Network 5.2.1 WAN 1) Static: In static mode, user should fill in the values of IP Address, Subnet Mask, Default Gateway, Primary DNS and Second DNS.
  • Page 17 Beijing Flyingvoice technology Co. Field Name Description Use keywords to indicate WAN port service model (the parameters are Connect Name defined in Network--> multi-WAN page) Temporarily only one IPv4 option IP Protocol Version Choose Static IP. Internet Set network working mode, options are route and bridge. Route/Bridge Mode This requires multi-WAN port Page settings, please refer to 5.2.7 NAT Enable...
  • Page 18 Beijing Flyingvoice technology Co. 2） DHCP Mode Field Name Description Connect Name Use keywords to indicate WAN1-WAN5 port service model(the parameters are defined in Network--> multi-WAN page) IP Protocol Version Temporarily only one IPv4 option Internet Choose DHCP Route/Bridge Mode Set network working mode, options are route and bridge.
  • Page 19 Beijing Flyingvoice technology Co. Port Bind Port bind is used for binding the service for different LAN ports and SSIDs. 3）PPPOE Mode Field Name Description Connect Name Use keywords to indicate the WAN1~WAN5 service mode (set relevant parameters in the WAN port settings page) IP Protocol Version Currently, only one IPv4 option INTERNET...
  • Page 20 Currently, G201N4 only supports IPv4 mode. INTERNET Bridge: If user make the option be Bridge mode, the PC which is connected to G201N4’s LAN port use PPPoE to connect Internet. Port Bind Port bind is used for binding the service for different LAN ports and...

  • Page 21: Lan

    Beijing Flyingvoice technology Co. 5.2.2 LAN Field Name Description IP Address Enter the IP address of the router on the local area network, all the IP addresses of the computers which are in the router’s LAN must be in the same network segment with this address, and the default gateway of the computers must be this IP address.

  • Page 22: Vpn

    Beijing Flyingvoice technology Co. DNS Mode Select DNS mode, options are Auto and Manual: ♦ When DNS mode is Auto, the device under LAN port will automatically obtains the preferred DNS and alternate DNS. ♦ When DNS mode is Manual, the user should manually configure the preferred DNS and alternate DNS Primary DNS Enter the preferred DNS address.

  • Page 23: Mac Clone

    Beijing Flyingvoice technology Co. 5.2.4 MAC Clone MAC address is the hardware address of the network device. Sometimes the network provider may set the network device's MAC bound to the network accounts. So when the user uses a new home gateway may not pass vendor certifications. In this case, the user can use the MAC clone function to clone your computer's physical address to the device’s Internet port.

  • Page 24: Ddns

    Beijing Flyingvoice technology Co. Field Name Decryption DMZ Enable If or not enable DMZ DMZ Host IP Address Used to enter the DMZ host IP address 5.2.6 DDNS Field Name Description Dynamic DNS Provider DDNS is enabled and select a DDNS service provider Account Enter the DDNS service account Password...

  • Page 25: Port Setting

    Auto-negotiation, options are Auto, 100M full, 100M half, 10M half LAN1~LAN4Port Speed and 10M full, select port speed negotiation methods. Nego 5.2.9 Multi WAN G201N4 support multi WAN function, user can set different vlans on WAN port.

  • Page 26: Wireless

    Beijing Flyingvoice technology Co. Field Name Description VLAN ID Configure VLAN ID Select Route mode or Bridge mode. Route/Bridge Mode There these options VOICE, TR069, INTERNET, Service TR069-INTERNET, TR069-VOICE, and VOICE-INTERNET, and TR069-INTERNET-VOICE, and Other Whether or not carry VLAN tag Take VLAN tag 5.3 Wireless 5.3.1 Basic...
  • Page 27 It is the basic identity of wireless LAN. SSID can be any SSID alphanumeric or a combination of special characters. It will appear in the wireless network access list. G201N4 supports multiple SSIDs. Multiple SSID1~SSID3 After the item is checked, the SSID is no longer displayed in the Hidden...

  • Page 28: Wireless Security Setting

    Beijing Flyingvoice technology Co. 5.3.2 Wireless Security Setting SSID choice Select a SSID from SSID, multi SSID1, multi SSID2. multi-SSID3. Security Mode Select an appropriate encryption mode to increase the security and privacy features of wireless dhome gateway. Select a different encryption mode, the web interface will be different, user can configure the corresponding parameters under the mode you select.
  • Page 29 Beijing Flyingvoice technology Co. Security Mode This is used to select one of the 4 WEP keys, key settings on the clients should be the same with this when connecting. WEP Keys Set the WEP key. A-64 key need 10 Hex characters or 5 ASCII characters;...
  • Page 30 Beijing Flyingvoice technology Co. WPA Algorithms This item is used to select the security algorithm for encryption of wireless dhome gateway, options are TKIP, AES, TKIPAES three Pass phrase Setting up WPA2-PSK security password Key Renewal Interval Set the key scheduled update cycle, default is 3600s 4) WPAPSKWPA2PSK manner is consistent with WPA2PSK settings WPA-PSK/WPA2-PSK WPA/WPA2 security type is actually a simplified version, which is based on the WPA shared key mode, higher security setting is also relatively simple, suitable for ordinary home...

  • Page 31: Wi-Fi Multimedia

    By using the WPS button on G201N4, we can freely enjoy quick encrypting the wireless network dhome gateway, protecting illegal users from invading. On one hand, this can ensure the security...
  • Page 32 WPS Mode PIN：Enter the PIN code of the wireless device which accesses to this LAN in the following option, and press apply. Then G201N4 begins to send signals, turn on the PIN accessing method on the clients, and then it can access the wireless AP automatically.

  • Page 33: Wireless Client

    Beijing Flyingvoice technology Co. two methods, only when the clients choose PCB access, the clients can connect the AP automatically. WPS shows status in three ways: WSC: Idle WPS Status WSC: Start WSC Process(begin to send messages) WSC: Success; this means clients have accessed the AP successfully, WPS connects well.
  • Page 34 Define the transmission power of the current AP, the greater it is, the stronger the signal is. Short Preamble Default is enable, G201N4 system is not compatible with traditional IEEE802.11, the operation rate can be 1,2Mpbs Short Slot If or not enable short slot, default is enable, it is helpful in improving the transmission rate of wireless communication.

  • Page 35: Sip Account

    Beijing Flyingvoice technology Co. 5.4 SIP Account 5.4.1 Line 1 In this webpage, user can configure the information on Line 1, including the following 4 parts: Basic, Audio Configuration, Supplementary Service Subscription and Advanced. Basic Set the basic information provided by your VOIP Service Provider, such as Phone Number, Account, password, SIP Proxy and so on.
  • Page 36 Beijing Flyingvoice technology Co. Display Name The number will be displayed on LCD Phone Number Enter telephone number provided by SIP Proxy Account Enter SIP account provided by SIP Proxy Password Enter SIP password provided by SIP Proxy Audio Configuration Field Name Description Audio Codec Type1...
  • Page 37 Beijing Flyingvoice technology Co. Enable gmd attribute Enable If or not enable gmd attribute. 3) Supplementary Service Subscription Field Name Description Call Waiting If or not enable Call Waiting Hot Line Fill in the hotline number. Pickup handset or press handsfree/headset button, the device will dial out the hotline number automatically.
  • Page 38 Beijing Flyingvoice technology Co. Field Name Description Domain Name Type If or not use domain name in the SIP URI. Carry Port Information If or not carry port information in the SIP URI. Signal Port The local port of SIP protocol, default is 5060. DTMF Type Choose the DTMF type from Inbound, RFC2833 and SIP INFO.

  • Page 39: Sip Setting

    Beijing Flyingvoice technology Co. SIP OPTIONS Enable When you set enable, the device will send SIP-OPTION to the server, instead of sending periodic Hello message. The sending interval is Keep-alive interval. Primary SER Detect Test interval of the primary server, the default value is 0, it Interval represents disable.

  • Page 40: Qos

    2) NAT Traversal Field Name Description NAT Traversal 1．If or not enable NAT Traversal 2. G201N4 supports STUN Traversal; If you want to traverse NAT/Firewall, select the STUN. STUN Server Address Add the correct STUN service provider IP address. NAT Refresh Interval Set NAT Refresh Interval, default is 60s.

  • Page 41: Preferences

    Beijing Flyingvoice technology Co. 5.5.1 Preferences 1) Volume Settings Field Name Description Handset Input Gain Adjust the handset input gain from 0 to 7. Handset Volume Adjust the output gain from 0 to 7. 2) Regional Field Name Description Tone Type Choose tone type form China, US, Hong Kong and so on.
  • Page 42 The Max value of home gateway’s jitter delay, home gateway is an adaptive jitter mechanism. Ringing Time How long G201N4 will ring when there is an incoming call. Regional Ring Waveform Select regional ring waveform, options are Sinusoid and Trapezoid, the default Sinusoid.
  • Page 43 If or not enable CWCID. If enable, the device will display the waiting CWCID Service call’s caller ID, or it won’t display. Default is disable. How long G201N4 will sound dial out tone when G201N4 dials a Dial Time Out number.

  • Page 44: Dial Plan

    Beijing Flyingvoice technology Co. If or not enable ICMP Ping. ICMP Ping If enable this option, home gateway will ping the SIP Server every interval time, otherwise, It will send “hello” empty packet to the SIP Server. Open special character translation function; if enable, when you press Escaped char enable the # key, it will be translated to 23%, when disable, it is just # 5.5.2 Dial Plan...
  • Page 45 Beijing Flyingvoice technology Co. Deny means G201N4 will reject the matched number, while Dial Out means G201N4 will dial out the matched number. Press it to move up. Move Up Press it to move down. Move Down 2) Adding one dial plan: Step 1.

  • Page 46: 3Phonebook

    G201N4; Click to save the phonebook file to your local computer. 2)Upload&&Download Blacklist Click to select the blacklist file and click to upload it to G201N4; Click to save the blacklist file to your local computer. 3)Phonebook...

  • Page 47: Call Log

    Beijing Flyingvoice technology Co. Select one contact, click Edit to edit it, click Delete to delete, and click Move to blacklist to move the contact to blacklist. Click Add, user can add one new contact, as the upon picture, enter the contact name and phone number, and select one ring tone, there are ten kinds of different ring tones to choose, click OK to confirm and click Cancel to cancel.
  • Page 48 Beijing Flyingvoice technology Co. 2) Answered Calls 3) Missed Call...

  • Page 49: Diagnosis

    Beijing Flyingvoice technology Co. 5.6 Diagnosis In this page, user can do ping test and traceroute test to diagnose the device’s connection status. 1) Ping Test Enter the destination IP or host name, and then click Apply, device will perform ping test. 2) Traceroute Test Enter the destination IP or host name, and then click Apply, device will perform traceroute test.

  • Page 50: Management

    Beijing Flyingvoice technology Co. 5.7.1 Management You can configure the value of Time/Date, password, web access, and system log and so on. 1) Save config file Field Name Description Config file upload and Upload: click on browse, select file in the local, press the upload button to download begin uploading files Download: click to download, and then select contains the path to download...
  • Page 51 Beijing Flyingvoice technology Co. Input the new password New Password Confirm Password Input the new password again Language Select the language for the web, the device support Chinese, English, and Spanish and so on. Remote Web Login If or not enable remote Web login Web Port Set the port value which is used to login from Internet port and PC port, default is 80.
  • Page 52 Beijing Flyingvoice technology Co. Set the summer time steps: Step 1. Enable Daylight Saving Time. Step 2. Set value of offset, like the upon picture Step 3: Set staring Month/Week/Day/Hour in Start Month/Start Day of Week Last in Month/Start Week/Start Hour Day, analogously...

  • Page 53: Firmware Upgrade

    5.7.3 Provision Provisioning allows G201N4 auto-upgrading and auto-configuring, and Flyingvoice devices support TFTP, HTTP and HTTPs three ways.  Before testing or using TFTP, user should have tftp server and upgrading file and configuring file.
  • Page 54 Set the periodic time for resync, default is 3600s. Delay(rec) Forced Resync If it’s time to resync, but G201N4 is busy now, in this case, G201N4 will wait Delay(sec) for a period time, the longest is “Forced Resync Delay”, default is 14400s, when the time over, G201N4 will forced to resync.

  • Page 55: Snmp

    Description Upgrade Enable If or not enable firmware upgrade via provision. Upgrade Error Retry If the last upgrade fails, G201N4 will try upgrading again after Delay(sec) “Upgrade Error Retry Delay” period, default is 3600s. Upgrade Rule URL of upgrade file 5.7.4 SNMP...

  • Page 56: Tr069

    Beijing Flyingvoice technology Co. 5.7.5 TR069 Field Name Description TR069 Enable If or not enable TR069 CWMP If or not enable CWMP ACS URL address ACS URL User Name ACS username Password ACS password Periodic Inform Enable If or not enable the function of periodic inform, default is enable Periodic Inform Interval Periodic notification interval, the unit is seconds, default is 43200s User Name...

  • Page 57: Functions

    ◆Dial the number directly and wait for 5 seconds (default No Key Entry Timeout). ◆Dial the number with ending char #, G201N4 will dial out immediately ◆ Dial the phone number which matches one dial rule, G201N4 will dial out immediately, no need to press # or wait for 5 seconds.

  • Page 58: Attended Transfer

    Step 1. Open Phone→Preferences→Call Forward, enable the one call forward mode and fill forwarded number Step 2: G201N4 will forward incoming call to the forwarded number according to the settings of Call Forward and call status 6.7 Direct IP calls Direct IP calling allows two phones, that is, an home gateway with an analog phone and another VoIP Device, to talk to each other without a SIP proxy.

  • Page 59: Speed Dialing

    Step 1.Set phone number(E.g.3333) in SIP Account→Line 1→Speed Dial, and then save the changes Step 2.Dial*74 to active speed dial function Step 3.Then dial 2 to call 3333, and G201N4 will dial out immediately. 6.9 Hotline Step 1.Set hotline in SIP Account→Line 1→Supplementary Service Subscription, you can refer to the following picture.

  • Page 60: Upgrade Firmware

    Beijing Flyingvoice technology Co. Step 4.Set starting Month/Week/Day/Hour in Start Month/Start Day of Week Last in Month/Start Day of Week/Start Hour of Day, analogously set stopping Month/Week/Day/Hour in Stop Month/Stop Day of Week Last in Month/Stop Day of Week/Stop Hour of Day. Step 5.Press Saving button to save and press reboot button to active changes.

  • Page 61: System Log

    In local: Step 1.Open Administration/Management page, System Log Setting column. Step 2.Choose log level from INFO and Debug, in INFO level, G201N4 records INFO log, and in Debug level, G201N4 records all debug information. Step 3.Press Save button to save and then press Reboot button to make changes effective.
