Essence Sophia Installation Instructions

Remove the fireplace suite from the packing, checking that neither the heater nor the power cable has been damaged during transport. Do not
operate the heater if damaged. The accessories are found in a box that is packed at the side of the fireplace. Your fireplace suite is guaranteed for
one year from the date of purchase. In the unlikely event of a breakdown you have access to our customer services team, simply call 01543 251122
during office hours, 9am – 5pm or e-mail on info@flameritefires.com
Where a chimney is not blocked off completely it will cause the heater to cut out during use.
The fireplace must be positioned so that the plug socket is accessible once installed. In the unlikely event of breakdown access must be allowed to
the rear so that the fire maybe serviced, do not seal to the wall. The mains cable must therefore be long enough to allow this. If the removal of the
plug is absolutely necessary for installation, cut off in an area within 100mm only of the plug itself. Any further may affect your warranty. Where
the fireplace suite is being used in an existing chimney, it is important that the chimney is blocked off to prevent airflow problems with the fire.
Where a chimney is not blocked off sufficiently, it will cause the heater to cut out and the flame effect to stop or work inefficiently.

Electrical connections

Your appliance comes fitted with a plug that incorporates a 13A fuse. The replacement fuses must be 13A and ASTA approved. If the fuse cover is
lost the plug must not be used until a replacement cover, of the same colour, is obtained from an electrical retailer.
The appliance is fitted with a moulded plug if it is necessary cut off the plug, for any reason, it must be discarded immediately with the fuse
removed. Under no circumstances should any attempt be made to reuse the plug, do not insert into any 13A socket as this could cause a
hazard. If the mains cable is damaged it must be replaced by the manufacturer or an authorised technical service centre.
WARNING THIS APPLIANCE MUST BE EARTHED
As the colours of the wires in the mains lead of this appliance may not correspond with the colour markings in your plug proceed as follows: -
The wire which is coloured green and yellow must be connected to the terminal in the plug which is marked with the letter E, or
coloured green or coloured green and yellow, or marked with the earth symbol
The wire which is coloured blue must be connected to the terminal in the plug which is marked with the letter N, or coloured
black.
The wire which is coloured brown must be connected to the terminal in the plug which is marked with the letter L, or coloured
red.

Fuel Effects

Once the fireplace suite has been installed in the correct position unpack the fuel effect from the accessory box. Pebbles (and wood
effect/cost option) may be arranged in a random formation on top of the fuel bed.
Controls (The fire may only be operated by the remote control).
The main on/off switch can be found on the underside of the opening, it is marked with I/O and will need to be switched to I to
operate the fire. In this position you will be unable to operate the fire further unless the
first.
To operate the flame effect (and further functions) simply press and release the
To set the light to your desired brightness, press then release the button marked
brightness will continuously phase from high to low. At a desired point press then release the
The heater will always start in the lower setting. For 750w of heat, press then release the button marked
the temperature to 1500w press then release button marked
I/II at anytime. To turn the heater off, press then release the button marked
To turn the flame effect off and deactivate the heater and dimmer functions press then release the button marked
Recommended To turn the fire off completely the main on/off switch must be switch back to O.
Sophia Instructions

Installation of Fireplace

The wires in the mains lead are coloured in accordance with the following code.
Green and yellow:
Blue:
Red:

Operating the fire

IMPORTANT
EARTH
NEUTRAL
LIVE
button on the remote.
I/II. You may alternate from 750w to 1500w by pressing
O/I.
Page 1 of 2
button on the remote is pressed
. You will notice the flame effect
button to stop the phasing.
O/I. To increase
.
