INSTRUCTION MANUAL
Semi-Automatic
Digital Blood Pressure Monitor
with Memory
04-267-001 (Adult size cuff)
04-267-006 (Large adult size cuff)
Please read this instruction manual
completely before operating this unit.
English • Spanish

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 04-267-001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MABIS 04-267-001

  • Page 1 INSTRUCTION MANUAL Semi-Automatic Digital Blood Pressure Monitor with Memory 04-267-001 (Adult size cuff) 04-267-006 (Large adult size cuff) Please read this instruction manual completely before operating this unit. English • Spanish...
  • Page 2: Table Of Contents

    Blood Pressure Log ........20 Manufactured by: MABIS Healthcare Inc. 1931 Norman Drive • Waukegan, IL 60085 847-680-6811 • FAX 847-680-9646 • www.mabis.net...
  • Page 3: Introduction

    Introduction Product Identification and Caution To achieve the maximum benefit from your blood pressure monitor, we Digital Display recommend that you first consult with your physician or trained health care professional. Thank you for purchasing a Digital Blood Pressure Monitor. With proper care and use, your monitor will provide you with many years of reliable readings.
  • Page 4: General Blood Pressure Information

    What Influences Blood Pressure? General Blood Pressure Information Many factors such as genetics, age, sex, altitude, physical activity, anxiety, muscular development, certain medications or even the time of day can What is Blood Pressure? influence blood pressure. Influences such as sleep or relaxation decreases Blood pressure is the pressure that is exerted by blood flowing against the blood pressure, while anxiety or exercise increases blood pressure.
  • Page 5: Important Information Before Use

    CATEGORY SYSTOLIC (mmHg) DIASTOLIC (mmHg) Important Information Before Use Optimal <120 <80 Normal <130 <85 1. Blood pressure measurements should only be interpreted by a High - Normal 130-139 85-89 physician or a trained health care professional who is familiar with your Mild Hypertension 140-159 90-99...
  • Page 6: Battery Installation/Replacement

    Battery Installation/Replacement Setting the Date/Time 1. Press the Time Set Button to enter into the Replace the batteries when the Low Battery symbol Time Adjustment mode. The blinking Month will appears on the display, Fig. 1, or when the display display, Fig.
  • Page 7: Applying Your Blood Pressure Cuff

    6. The bottom edge of the cuff should be Applying Your Blood Pressure Cuff positioned approximately one inch ABOVE the elbow joint, Fig. 3. Avoid smoking, eating, taking medication, alcohol consumption or physical 7. Reaching underneath your left arm with your activity 30 minutes prior to taking a reading.
  • Page 8: Taking Your Blood Pressure Reading

    6. Upon achieving the proper inflation level, Taking Your Blood Pressure Reading release the pressure on the bulb. 7. The pressure in the cuff will automatically Proceed only after reading the previous sections of this manual. begin to decrease. The display will Remember! Remain still;...
  • Page 9: Recalling Measurements In Memory

    Recalling Measurements in Memory Description of Display Symbols You can recall up to 60 measurements plus an average of all currently stored measurements in memory to share with your physician or trained healthcare professional. SYMBOL CONDITION ACTION 1. Press the ‘M’ Button. The first reading displayed is the average of all measurements stored in memory.
  • Page 10: Troubleshooting

    Error Codes Troubleshooting Err 0 If any abnormality occurs during use, please check and correct the No pulse is detected following: Err 1 Inflation rate is too low Err 2 Systolic reading unattainable Condition Correction Err 3 Cuff pressure is too high Display is blank when power is on.
  • Page 11: Product Specifications

    Product Specifications Sample Blood Pressure Log Name and Model Number MABIS Semi-Automatic Digital Blood Pressure Monitor, 04-267-001, 04-267-006 Display System Digital display/LCD Measuring Method Oscillometric Power Source 4 AA batteries Measuring Range Pressure: 30 to 280 mmHg Pulse: 40-200 beats/minute Accuracy Pressure: ±3 mmHg...
  • Page 12: Blood Pressure Log

    Blood Pressure Log Name: Age: Weight: Date Monitor Semiautomático con Time mmHg Memoria para Presión Arterial 04-267-001 (Brazalete tamaño adulto) 04-267-006 (Brazalete tamaño adulto grande) Sírvase leer toda esta guía antes de operar la unidad. Pulse Body Con- dition Inglés • Español...
  • Page 13 Registro de Preción Arterial ........42 unidad. Línea Gratuita de Atención al Cliente 1-800-622-4714 Fabricado por: MABIS Healthcare Inc. 1931 Norman Drive • Waukegan, IL 60085 847-680-6811 • FAX 847-680-9646 • www.mabis.net...
  • Page 14: Introducción

    Introducción Identificación del Producto y Precaución Para obtener el máximo beneficio del monitor de presión arterial, se Visor Digital recomienda consultar primero con el médico o profesional capacitado del área de salud. Gracias por comprar un Monitor Digital de Presión Arterial. Con el debido cuidado y uso, obtendrá...
  • Page 15: Información General Acerca De La Presión Arterial

    CICLO CARDÍACO. hogar le brinda la oportunidad de complementar las mediciones El Monitor Automático MABIS leerá automáticamente su presión arterial y realizadas en el consultorio del médico. Cuando dichas lecturas en el mostrará las lecturas sistólica y diastólica en la pantalla. La presión hogar se toman durante un período de tiempo, pueden indicar un cambio...
  • Page 16: Información Importante Previo Al Uso

    CATEGORIA SISTÓLICA (mmHg) DIASTÓLICA (mmHg) Información Importante Previo al Uso Optima <120 <80 Normal <130 <85 1. Las mediciones de la presión arterial sólo debe interpretarlas un médico o profesional capacitado del área de salud familiarizado con su Alto - Normal 130-139 85-89 historia clínica.
  • Page 17: Colocación/Cambio De Baterías

    Colocación/Cambio de Baterías Cómo Colocar la Fecha/Hora Cambie las baterías cuando aparezca el símbolo de 1. Presione el Botón para Configurar la Hora Poca Batería en el visor, Fig. 1, o cuando el visor para ingresar en el modo Ajuste de la Hora. permanezca en blanco al presionar el Botón de Aparecerá...
  • Page 18: Cómo Colocar El Brazalete De Presión Arterial

    6. El borde inferior del brazalete debería Cómo Colocar el Brazalete de Presión Arterial colocarse aproximadamente una pulgada por ARRIBA del codo, Fig. 3. Evita fumar, comer, tomer medicamentos, el consume de alcohol o la 7. Con la mano derecha yendo por debajo, actividad física 30 minutos antes de la lectura.
  • Page 19: Cómo Tomar La Lectura De La Presión Arterial

    hasta alcazar el nivel adecuado, Fig. 5. Cómo Tomar la Lectura de la Presión Arterial 6. Una vez alcanzado el nivel de inflado adecuado, libere la presión de la bomba. Proceda luego de haber leído las secciones anteriores de este manual. ¡Recuerde! Permanezca inmóvil;...
  • Page 20: Descripción De Los Símbolos Del Visor

    Descripción de los Símbolos del Visor ómo Llamar las Mediciones de la Memoria Puede llamar hasta 60 lecturas totales y también el promedio de todas las lecturas grabadas en la memoria para registrar en un Diario de la Presión Arterial o para que pueda informarle a su médico o SÍMBOLO CONDICIÓN ACCIÓN...
  • Page 21: Análisis De Fallas

    Códigos de Error Análisis de Fallas Err 0 Si ocurriera una anomalía durante el use, verifique y corrija lo siguiente: No se detectó el pulso Err 1 El nivel de inflación es demasiado bajo Condición Corrección Err 2 No se puede obtener la lectura sistólica El visor está...
  • Page 22: Especificaciones Del Producto

    Especificaciones del Producto Ejemplo de Registro de Preción Arterial Nombre y Número MABIS Monitor Semiautomático Digital para Presión de Modelo Arterial con Memoria, 04-267-001, 04-267-006 Tipo de Visor Visor digital/LCD Método de Medición Oscilométrico Fuente de Energía 4 baterías tipo AA Alcance de la Medición...
  • Page 23: Registro De Preción Arterial

    Registro de Presión Arterial...
