ZuumMedia MAHCL4X4 User Manual

Hdbaset hdmi 4x4 matrix switcher with full 3d support
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MAHCL4X4
HDBaseT HDMI 4x4 Matrix Switcher with
Full 3D Support
User Manual
Here for You 24/7!
1-888-861-7351

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAHCL4X4 and is the answer not in the manual?

Questions and answers

Related Manuals for ZuumMedia MAHCL4X4

Summary of Contents for ZuumMedia MAHCL4X4

  • Page 1 MAHCL4X4 HDBaseT HDMI 4x4 Matrix Switcher with Full 3D Support User Manual Here for You 24/7! 1-888-861-7351...

  • Page 2: Table Of Contents

    Please be careful though because just like any other electronic device; the MAHCL4X4 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to reduce the risk of damage to the unit.

  • Page 3: Introduction

    INTRODUCTION   The ZuumMedia MAHCL4X4 provides the most reliable and cost effective solution in the market to switch high definition video plus multi-channel (up to 7.1-channel) digital audio from any of the four HDMI sources to the remote displays at the same time. Simple and easy setup with auto signal equalization and amplification (no dipswitches or dials to adjust) ensures the best possible picture quality and sound transmission.

  • Page 4: Specifications

    Operation: 32 to 104°F, Storage: -4 to 140°F, Humidity: up to 95% Dimensions - inches 17.25"(w) x 1.73"(h) x 7.76"(d) Weight - lbs 5.29 Model: HE1LBIR232-HRX (MAHCL4X4 optional CAT5/6 receiver) Resolution Up to 1080p/60Hz/48bit, 3D, 4Kx2K Distance 328ft (100m) Max HDMI Connector...

  • Page 5: Hardware Installation

    HE1L-HRX (MAHCL4X4 optional CAT5/6 HE1LBIR-70M-HRX (MAHCL4X4 optional Model: receiver) CAT5/6 receiver) Resolution Up to 1080p/60Hz/48bit, 3D, 4Kx2K Up to 1080p/60Hz/48bit, 3D, 4Kx2K Distance 328ft (100m) Max CAT5 196ft (60m), CAT6 229ft (70m) Max HDMI Type A [19-pin female] Type A (19-pin female)

  • Page 6: Connection Diagram

    CONNECTION   D IAGRAM  ...

  • Page 7: Panel Descriptions

    PANEL   D ESCRIPTIONS   Front Panel 1. Power Button: Turn matrix On/Off, Blue LED(Power On), Red LED (Standby), LED Off (Power Off) 2. LCD Display: Display for navigating menu 3. Front Button Control: Front panel push buttons used to navigate through setup menu and select output to input ports 4.

  • Page 8: Control & Operation

    CONTROL   &   O PERATION   Method A: Push-in Buttons 1. Front Panel Button Control POWER Power On/Standby Cursor Up DOWN Cursor Down LEFT Cursor Left RIGHT Cursor Right ENTER Select and Confirm MENU Back to Main Menu *When the sub-menu setting is changed, press the ENTER button to confirm the setting.
  • Page 9 Operation: • Press the UP or Down button to move (*) within the main page, select one of the options in the main list and press the ENTER button to enter sub-page. • When the selected sub-page setting is complete, press the MENU button to return to the main page. SWITCH SETTING: (Default: 1 2 3 4) This option is used to switch the input/output port, enter the SWITCH SETTING menu.
  • Page 10 * MATRIX MODE allows the selection of any RS-232 port 1~4 to work with any of the HDBaseT ports 1~4, In this example the R-232 port 1 is transmitting to multiple receivers that are connected to HDBaseT port 1, 2, 3 and the RS-232 port 4 is transmitting to HDBaseT port 4 only.
  • Page 11 IR RX SETTING: (Default IR TX: O O O O) This option is used to setup whether the IR signal will be sent to MATRIX from remote devices to control local source equipment. IR from the receiver connected to HDBaseT 1~4, to control a local source, setting should be O for on and X is for off.
  • Page 12 This option can be changed to prevent HDBaseT remote control (IR1) conflicts with other remote control devices. After entering the HDBaseT IR ID menu, press ENTER, the bottom line of LCD text will start to flash, press UP or DOWN button to select, then press ENTER to confirm setting. After completing the HDBaseT IR ID setting, the HDBaseT remote control (IR1) must also be programmed to the same IR ID in order to operate as normal.
  • Page 13 EDID: (Default: LPCM-2CH) Matrix output will be based on TV EDID, this matrix also provides two default EDID modes – BUILD-IN MODE and COPY MODE. The EDID learning option (COPY MODE) is only necessary whenever you encounter any display on the HDMI output port that cannot play audio and video properly.
  • Page 14 Setup the remote control IR ID to be the same as Matrix, the first time using the remote control or replacing the batteries requires learning a new IR ID. • Local side (MAHCL4X4 Matrix) IR ID default is 4 • Remote side (HDBaseT) IR ID default is 5 •...
  • Page 15 Remote Control Button Define: Symbol Local Side Remote Side POWER ON/Standby Output Off LEFT Left No Function RIGHT Right No Function No Function DOWN Down No Function ENTER Confirm No Function MENU Menu No Function Quick Button 1 Select Input 1 Quick Button 2 Select Input 2 Quick Button 3...
  • Page 16 Local side (MAHCL4X4 Matrix) remote control quick button operation: For example, to connect output port 1 to input port 4, press the quick button 1 (Output 1) and then press the quick button 4 (Input 4). Remote side (HDBaseT) remote control quick button operation: For example, to select input 2, press 2, or press 0 to turn output off.
  • Page 17 Method C: Local PC RS-232 Control (Console) RS232 Protocol/ASCII Commands Serial COM Port Settings Connect a 9-pin straight through RS-232 cable from the MAHCL4X4 to your Home or Commercial Automation System. Configure the serial communications port on your automation system or PC to these settings.

  • Page 18: Hdbaset Receivers

    HDBASET   R ECEIVERS   * Note - The MAHCL4X4 has optional receivers that will extend HDMI, IR and Serial over the HDBaseT RJ45 ports at distances up to 328ft (100m) using CAT5/6 cable (CAT6 Recommended). HE1L-HRX HDBaseT HDMI Receiver over CAT5/6 Cable up to 328ft (100m)

  • Page 19: Faq

    FAQ   Can every TV work with the HDMI matrix? Basically, the answer is YES. But if your TV cannot support 1080p, please refer to the EDID/COPY MODE section to learn EDID from your TV. What is EDID? Why do I need to learn EDID? EDID (Extended Display Identification Data) contains information data from a display device such as video and audio capabilities in which it can support.

  • Page 20: Warranty

    Date Code by ZuumMedia or an approved authorized dealer. Should this product fail to be in good working condition within two (2) years from the date code, ZuumMedia, at its option, will repair or replace the unit, provided that the unit has not been subjected to abuse, static discharge, power surge or any unauthorized modifications and disassembly.
