Summary of Contents for GRK Global R31House
- Page 2 Assemble tools (Not include ) Screwdriver small Long nose piller Hex wrench 1.5&2.0mm Side cutter Socket driver 7.0mm...
- Page 3 BAG A Diff grease Diff grease B.Bearing Black grease Black grease B.Bearing Assembly 2 Set Front BAG B B.Bearing Rear...
- Page 4 BAG C BAG SPONGE BAG D Make 2 Front Diff. This side. Rear Diff. This side.
- Page 5 BAG E M3x12mm M3x12mm M3x12mm BAG F M3x12mm M3x12mm M3x12mm M3x12mm Std.position M3x12mm Std.position M3x12mm M3x12mm...
- Page 6 BAG G M3x8mm--2 2.5x5x2mm washer--x12 Front lower arm--x2 Suspension mount--x1 Suspension pin Long--x2 Suspension mount 2.5x5x2mm 2.5x5x2mm 2.5x5x2mm 2.5x5x2mm 2.5x5x2mm 2.5x5x2mm BAG H M3x8mm Suspension pin Long M3x8mm--x2 M3x8mm 2.5x5x2mm washer--x10 2.5x5x1mm washer--x4 Rear lower arm--x2 M3x8mm--x1 Suspension pin Long--x2 M2.5x5x2mm M2.5x5x2mm Suspension mount...
- Page 7 BAG I Steering linkage Assm.--make 2 Ball end cap standard--x4 Turnbuckle 20mm Ball end cap short--x4 Turnbuckle 36mm--x2 Ball end cap short Ball end cap short Turnbuckle 20mm--x2 Front unival shaft--x2 4mｍ Front axle--x2 Cross joint--x2 Front upper linkage Assm.--make 2 Cross joint pin--x2 M3x2.5mm set screw--x2 M3x2.5mm...
- Page 8 BAG K BAG SPONGE B.Bearing Sponge 2mm Std. position Rear upper arm 25.5mｍ Assembly--4 set BAG L Customer choice for with or without the bladder. F：12.5mm R：13.5mm...
- Page 9 Std. position Don’t over tighten. M3x12mm BAG M M3x12mm--x4 Shock lower ball--x4 Std. position Don’t over tighten. M3x12mm BAG N Servo horn--x 4.3x6mm M3 nut Servo saver--x1 Servo saver 23T KO. SANWA 24T Hi TECH Servo saver spring S--x2 25T FUTABA Spring S Spring S Servo horn...
- Page 10 BAG O Ball end cap standard Ball end cap standard M3x8mm 3x6x0.5mm washer--x4 Turnbuckle 30mm M3x8mm--x4 M3x12mm--x1 M3x8mm--x2 3x6x0.5mm 3x6x0.5mm 10.4mｍ M3x12mm M3x8mm Servo saver cap Turnbuckle 30mm--x1 Servo saver cap--x1 Ball end cap standard--x2 Servo mount--x2 M3x15mm M3x15mm BAG P Body clip M3x15mm--x2 E clip--2...
- Page 11 BAG Q Body post--x2 Rear Diffuser--x1 Body post support--x2 Rear body post mount--x2 Body clip M3x8mm--x2 M3x10mm--x2 Body clip Body clip--x4 M3x10mm M3x8mm M3x8mm BAG R Motor mount adapter--x1 M3x8mm--x4 M3x8mm M3x8mm M3x8mm M3x8mm...
- Page 12 BAG S Wheel--x4 2x9.8mm Pin--x4 M4 Lock nut--x4 Wheel hub--x4 Wheel hub Wheel 2x9.8mm PIN M4 Lock nut BAG T R clip--x2 Battery plate--x1 P.10...
- Page 13 R31# 商品名 構成部品 数量 1.6mm Ball 3.175mm Ball Thrust bearing washer Diff. spring Diff. screw M2.5 Nylon Nut Diff plate R31G001 Ball diff set 5x8x2.5mm Bearing Diff. joint ring 39T Ball Diff. ring gear Diff. joint Long Diff. joint Short 10x12.5x0.1mm washer 10x12.5x2mm washer 1.6mm Ball...
- Page 14 2.5x5x2mm washer R31G025 Sus pin set 2.5x5x1mm washer R31G026 Sus pin sus pin (2.5x52.8) Front lower arm R31G027 Front & Rear lower arm Rear lower arm Ball end cap standard R31G028 Ball end set Ball end cap short R31G029 Front axle Front axle R31G030 Front dog bone...
- Page 15 Body post sleeve E clip Front lower bumper R31G050 Front bumper set Front upper bumper M3x6 M3x8mm M3x15mm Rea diffuser R31G051 Rear diffuser ste M3x8 R31G052 Wheel Wheel Wheel hub R31G053 Wheer hub 2.0x9.8mm PIN R31M100 850 bearing 5x8x2.5mm Balling R31M101 1060 bearing 6x10x3mm Bearing...
