Streamline Supplies 50GPD-FP-CLK Instruction Manual

Filterplus clk
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

STREAMLINE ®
Products for the Pure Water Cleaning Industry
INSTRUCTION MANUAL
PRODUCT
FILTERPLUS ® CLK
50, 75 & 100GPD Pumped RO Water Filtration
Systems.
PRODUCT CODE
50GPD-FP-CLK, 75GPD-FP-CLK,
100GPD-FP-CLK
WARRANTY
Covered for one year from
recorded date of purchase.
(See back page for further details)
Packed By_________ Checked By_________
Date ____/____/____

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 50GPD-FP-CLK and is the answer not in the manual?

Questions and answers

Summary of Contents for Streamline Supplies 50GPD-FP-CLK

  • Page 1 INSTRUCTION MANUAL PRODUCT FILTERPLUS ® CLK 50, 75 & 100GPD Pumped RO Water Filtration Systems. PRODUCT CODE 50GPD-FP-CLK, 75GPD-FP-CLK, 100GPD-FP-CLK WARRANTY Covered for one year from recorded date of purchase. (See back page for further details) Packed By_________ Checked By_________...
  • Page 2 The STREAMLINE ® water filtration system is designed to de-ionise tap water and is simple to install and maintain. It is the installer’s responsibility to ensure that this appliance is plumbed in accordance with local authority’s bye-law regulations. THIS KIT INCLUDES 1 x Filtration System 1 x Tap Valve 1 x Waste Saddle Clamp...
  • Page 3 Connect an appropriate length of white tubing to the elbow marked ‘Water Inlet’, allowing enough tubing to connect to the mains water supply. The plastic fastening nut should be loos- ened, and the tube pushed in as far as possible, before tightening the plastic nut securely .
  • Page 4 FIG. 4 WATER FEED 15mm WATER SUPPLY Connect an appropriate length of tubing to the fitting marked ‘Drain’ or ‘Waste Water Tube’ (See Fig 5), allowing enough tubing to reach the nearest 40mm waste pipe. Attach the black saddle clamp to a 40mm waste outlet pipe by using the two bolts supplied.
  • Page 5 START UP Ensure that all fittings are tightened securely. Turn the mains water supply on and check for leaks. Allow a few minutes for the system to allow trapped air to escape and for filter fines to be flushed out before securing the feed tube on the RO housing. Plug the booster pump into a mains power supply and switch it When fully pressurised, check all fittings again for leaks.
  • Page 6 STREAMLINE ® WARRANTY The warranty on Machines and Equipment is for 1 year from RECORDED DATE OF PURCHASE. THIS WARRANTY EXCLUDES NORMAL MAINTENANCE ITEMS, including but not limited to HOSES, FILTERS, O-RINGS, DIAPHRAGMS, VALVES, GASKETS, CARBON BRUSHES and damage to motors and other components as a result of failure to replace normal maintenance items.

This manual is also suitable for:

100gpd-fp-clk75gpd-fp-clk,
