Summary of Contents for Blade CG02+ 3-Axis
- Page 1 ® CG02+ 3-Axis Brushless Camera/Gimbal Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.
- Page 3 Safety Precautions and Warnings • Always keep a safe distance in all directions • Never operate your model with low transmitter around your model to avoid collisions or injury. This batteries. model is controlled by a radio signal subject to in- •...
-
Page 4: Table Of Contents
IC Information ............17 Transmitter Programming ........10 Compliance Information for the European Union ..17 Using the Gimbal ........... 10 Box Contents A. CG02+ 3-axis camera/gimbal D. (3) M2.5 x 10 mounting screws ™ B. Chroma mounting plate E. 4 pin Y-harness C. -
Page 5: Technical Specifi Cations
Technical Specifi cations Dimensions LxWxH (with lens): 3.00 x 101.62 x 129.12mm Weight: 163 g Working Voltage: Wireless Frequency Range: North America: 5745MHz–5825MHz** Europe: 5180MHz–5240MHz** Lens Sensor: Angle of view: 155° Controlled Rotation Range: Pitch Axis Control: –90°–0° Effective Pixels: 16 million White Balance: Automatic... -
Page 6: Gimbal Components
Gimbal Components Front Bottom Mounting rails Micro SD card slot Microphone Camera lense WiFi antenna Left side Right side PWM ports 12V gimbal power port... -
Page 7: Installing The Mounting Plate
Installing the Mounting Plate The CGO2+ camera gimbal is compatible with ™ 350 QX3 and Chroma quadcopters. Install the appropriate mounting plate using the 3 included M2.5 x 10 screws. Do not overtighten. IMPORTANT: If you are mounting the CGO2+ to the 350 QX3, you must fi... -
Page 8: Transmitter Programming
Transmitter Programming Transmitter control of the pitch angle of the CG02+ is To change the gimbal angle BEFORE starting the ™ possible with most 6-channel and above Spektrum motors for fl ight, set switch A to position 1. The transmitters. Control of the pitch angle in fl ight is throttle stick will now control the angle of the gimbal. -
Page 9: Using The Gimbal
DX7, DX9, DX18 ST10+ Personal Ground Station In Channel Input Confi guration: The ST10+ requires no additional programming to use the CGO2+. Proceed to “Using the CGO2+ With Your • Assign Channel 7 Input (AUX2) to R Knob. ST10+ Personal Ground Station.” •... -
Page 10: Using The Cgo2 App
Using the CGO2 App • With the CGO2+ powered on, open the WiFi You can now take still photos or start/stop recording settings on your smartphone or tablet and video by using the on-screen controls on your connect to the CGO2 GB network device. -
Page 11: Led Codes
Use the buttons on the top of the ST-10+ to control the camera functions and the left slider to control the vertical angle of the camera gimbal. Photo Video Start / Button Stop Button Camera Tilt Slider LED Codes Green Blue Yellow Initializing.............. -
Page 12: Troubleshooting
Troubleshooting Problem Possible Cause Solution The gimbal vibrates after Gimbal did not initialize correctly Re-initialize with the gimbal clear of switching ON or was obstructed obstructions Keep the quadcopter and gimbal level Gimbal does not respond to Gimbal did not initialize and immobile for 5 seconds after control input switching ON... -
Page 13: Limited Warranty
Limited Warranty What this Warranty Covers Limitation of Liability Horizon Hobby, LLC, (Horizon) warrants to the original HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, purchaser that the product purchased (the “Product”) will INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF be free from defects in materials and workmanship at the PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN date of purchase. - Page 14 Inspection or Services Non-Warranty Service If this Product needs to be inspected or serviced and is Should your service not be covered by warranty, compliant in the country you live and use the Product in, service will be completed and payment will be please use the Horizon Online Service Request submission required without notifi...
-
Page 15: Service Contact Information
Service Contact Information Country of Horizon Hobby Contact Information Address Purchase Horizon Service Center servicecenter.horizonhobby.com/ (Repairs and Repair Requests) RequestForm/ www.quickbase.com/db/ Horizon Product Support United States 4105 Fieldstone Rd bghj7ey8c?a=GenNewRecord (Product Technical Assistance) of America Champaign, Illinois, 61822 USA 888-959-2304 sales@horizonhobby.com Sales 888-959-2304... -
Page 16: Ic Information
IC Information This device complies with Industry Canada license- and (2) this device must accept any interference, exempt RSS standard(s). Operation is subject to the including interference that may cause undesired following two conditions: operation of the device. (1) this device may not cause interference, Compliance Information for the European Union EU Compliance Statement: Horizon Hobby, LLC ... - Page 17 ©2015 Horizon Hobby, LLC. Blade, Chroma, DSM, DSM2 and DSMX are trademarks or registered trademarks of Horizon Hobby, LLC. iTunes is a trademark of Apple, Inc. Registered in the U.S. and other countries. Google is a registered trademark of Google, Inc.
