Wilson Electronics 952-1800 Operating Instructions & Service Manual

Pneumatic 1800 rpm torque controlled tube roller
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual
Enlarged version
SPECIFICATIONS
MODEL
952-1800
TUBE CAPACITY (OD)
Up to 1/2 in (12.7mm)
FREE SPEED
1800 RPM
MIN. TORQUE
18 in-lbs (2 N-m)
MAX. TORQUE
45 in-lbs (5 N-m)
TORQUE STD. DEV.
±3%
AIR CONSUMPTION
19 CFM
AIR PRESSURE
90 PSI
OPERATING HOSE
3/8 in (9.5 mm)
DRIVE
3/8" Square Spindle
CHUCK
1/4" Quick Connector
WEIGHT
2.16 lbs
O. A. L.
8.66 in
DIAMETER
1.69 in
8
SM-155B
TORQUE CONTROLLED TUBE ROLLER
USER MUST READ AND UNDERSTAND OPERATOR'S MANUAL.
PNEUMATIC 1800 RPM
• 952-1800
OPERATING INSTRUCTIONS
&
SERVICE MANUAL
TO REDUCE THE RISK OF INJURY AND EQUIPMENT DAMAGE
Thomas C. Wilson, Inc.
21-11 44th Avenue, Long Island City, New York 11101
Tel: (718)729-3360 Fax: (718)361-2872 http://www.tcwilson.com
Email: tcwilson@tcwilson.com
SM-155B
