- Page 1 INSTRUCTION MANUAL Ultra Resolution Day & Night IR Dome Camera Ultra Resolution Vandal Model: DPV24DL Day & Night IR Dome Camera Indoor Model: DPD24DL P/N 01.BMS.11.0071401B Please read this manual thoroughly before use and keep it handy for future reference.
- Page 2 -ii-...
-
Page 3: Specifications
• 2.8-10.5mm Varifocal Day/Night Lens F1.4 DC Iris • Camera Mounting: Surface / Semi-Flush Mount • 600 TV lines of resolution • Advanced Digital Noise Reduction (DNR) DPV24DL • Shadow Reduction (ATR) • Vandal Dome Model • Smart IR technology •... -
Page 4: Packing Contents
MEASUREMENTS PACKING CONTENTS Indoor Dome package contains the following: Camera in housing ---------------------------------1 Camera Locking screws (PA3 Type) -----------2 Instruction guide (This Document) -------------1 3.4" Surface & Flush Mounting Templates----------2 Locking Conduit Allen Key 87 mm Screw RCA - BNC test cable ------------------------------1 Junction Box Plate ----------------------------------1 Ø... -
Page 5: Junction Box Installation Types
VANDAL DOME FITTINGS JUNCTION BOX INSTALLATION TYPES 2S FITTING a. 2S Fitting requires only 2pcs of 2S/4S screws. Note: You have a reduced space in which to hide cables using this type of Screws installation. Recommended for indoor dome only. Wall Mount - model # MNTV2XW Pendant Mount - model # MNTV2XC Cable... - Page 6 INSTALLATION. VANDAL DOME INSTALLATION. VANDAL DOME ATTENTION - If using DC power, follow the correct polarity as marked on the power cable. 1) Loosen the three tamper screws using the provided allen key. Lift the dome cover. 4) Remove camera cover by squeezing the back and front of the cover (as indicated by the arrow indicators) at the Note: If you plan to use conduit fitting, remove conduit same time and lifting it up and away from the lens.
- Page 7 INSTALLATION. INDOOR DOME INSTALLATION. INDOOR DOME (Semi-Flush Mount) (Surface Mounting) ATTENTION - If using DC power, follow the correct ATTENTION - If using DC power, follow the correct polarity as marked on the power cable. polarity as marked on the power cable. 1a) Press down on the tab marked with an arrow to lift 1a) Press down on the tab marked with an arrow to lift up the dome cover slightly...
-
Page 8: Camera Adjustment
CAMERA ADJUSTMENT CAMERA ADJUSTMENT AUTO MANUAL SETUP HIGH LUMINANCE MODE SHUT+AGC SHUTTER MODE SHUT+AUTO IRIS 1/60 6.00 BRIGHTNESS LOW LUMINANCE MODE BRIGHTNESS x0.50 RCA Service Connector RETURN RETURN Use supplied RCA - BNC cable OSD function joystick. Pressing down If you require BNC output. - Page 9 CAMERA ADJUSTMENT CAMERA ADJUSTMENT OSD MENU control Select the language in which to display the OSD menu. Note: Selection changes the language displayed immediatley. Press down on the function joystick to access the setup menu. LANGUAGE: English,Japanese,German, French • Main setup menu is displayed on the monitor screen. Russian, Portuguese, Spanish, Chinese.
- Page 10 CAMERA ADJUSTMENT CAMERA ADJUSTMENT SHUTTER/AGC SETUP MENU LANGUAGE ENGLISH SPEED LENS AUTO SHUTTER/AGC AUTO DELAY CNT WHITE BAL ATW ATW FRAME x1.00 DAY/NIGHT AUTO ENVIRONMENT OUTDOOR PICT ADJUST Shutter has two options: AUTO or MANUAL 2DNR ...
- Page 11 CAMERA ADJUSTMENT CAMERA ADJUSTMENT ANTI CR Activates color rolling suppression. • DELAY CNT 000-255 MANUAL WB • DAY - NIGHT 000-255 MANUAL WB Threshold for Night status from day status. LEVEL • NIGHT - DAY 000-255 Threshold for the Day status from night status. ...
- Page 12 CAMERA ADJUSTMENT CAMERA ADJUSTMENT SHADOW REDUCTION (ATR) NR MODE Y / C OFF / ON Y LEVEL C LEVEL This function compensates for darker areas surrounding the object to provide naturally sharp picture and improves contrast in bright/dark areas. RETURN...
- Page 13 CAMERA ADJUSTMENT CAMERA ADJUSTMENT MOTION DET OFF / ON BOTTOM: Set the bottom side of the monitoring frame selected by the AREA SEL parameter Motion Detection is defined by rectangular areas. This give a visual identification LEFT: Set the left side of the monitoring frame selected by the AREA SEL of motion areas.
-
Page 14: Troubleshooting
CAMERA ADJUSTMENT TROUBLE SHOOTING Refer to the following table if you are experiencing trouble with your camera. Contact an authorized technician if the table does not provide you with a PHASE solution to the trouble. Nothing appears on the screen. Check that the power cord and line connection between the camera and monitor are connected properly.
