- Page 1 INVERTER SERIE H5A Installation and owner's manual MUPR-H5A CL20025 to CL20028 English www.mundoclima.com...
-
Page 2: Table Of Contents
CONTENT OWNER'S MANUAL ...................... Read before operation ....................Safety precautions ......................Names of parts ....................... Operating instructions ....................Care and maintenance ....................Troubleshooting ......................INSTALLATION MANUAL .................... Safety precautions ......................Installation ........................Indoor unit installation ....................Outdoor unit installation ....................REMOTE CONTROLLER .................... -
Page 3: Owner's Manual
OWNER´S MANUAL Before using your air conditioner, please read this manual carefully and keep it for future reference.. INVERTER SPLIT-TYPE ROOM AIR CONDITIONER The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. -
Page 4: Read Before Operation
READ BEFORE OPERATION CAUTION Contact an authorised service technician for repair or maintenance of this unit. Contact the authinstaller for installation of this unit. This appliance is not intended for use by persons(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. - Page 6 SAFETY PRECAUTIONS CAUTION Do not clean the air Ventilate the room well When the air filter is to be conditioner with water. when used together removed, do not touch the with a stove, etc. metal parts of the unit. Water may enter the unit and An oxygen shortage It may cause an injury.
-
Page 7: Names Of Parts
NAMES OF PARTS ★ IndoorUnit Air inlet Indoor Unit 、 1 Fron t pan el 、 2 A ir filter 、 Auto button 、 4 Louver 、 5 S ign al receptor Air outlet 、 6 S upply c ord 、... -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Operating temperature O utdoor ＞47℃ C ooling ＜ ℃ Indoor O utdoor ℃ ＜ H eating ＞ ℃ Indoor Manual operation Manul operation can be used temporarily in case the remote controller is disable or maintenance necessary. NOTE: The unit must be turned off before operating the manual control button. - Page 9 OPERATING INSTRUCTIONS Airflow direction control Adjust the air flow direction properly otherwise, it might cause discomfort or cause uneven room temperatures. Adjust the horizontal louver using the remote controller. Adjust the vertical louver manually. To set the vertical air flow(Up--Down) direction Perform this function while the unit is in operation.
- Page 10 OPERATING INSTRUCTIONS How the air conditioner works AUTO operation When you set the air conditioner in AUTO mode, it will automatically select cooling, heating(cooling/heating models only), or fan only operation depending on what temperature you have selected and the room temperature.
-
Page 11: Care And Maintenance
CARE AND MANTENANCE Care and maintenance Cleaning the Grille, Case and Remote Controller Turn the system off before cleaning. To clean, wipe with a soft, dry cloth. Do not use bleach or abrasives. NOTE: Supply power must be disconnectd before cleaning the indoor unit. - Page 12 CARE AND MANTENANCE Maintenance Checks before operation If you plan to idle the unit for a long time, perform Check that the wiring is not broken off or the following: disconnected. (1) Operate the fan for about half a day to dry the Check that the air filter is installed.
-
Page 13: Troubleshooting
TROUBLESHOOTING The following events may occur during normal operation. Protection of the air conditioner. Compressor protection The compressor can't restart for 3 minutes after it stops. Anti-cold air (Cooling and heating models only) The unit is designed not to blow cold air on HEAT mode, when the indoor heat exchanger is in one of the following three situations and the set temperature has not been reached. - Page 14 TROUBLESHOOTING Troubleshooting If one of the following faults occurs, stop the air conditioner immediately, disconnect the power and then connect it in again. If the problem still exists, disconnect the power and contact the nearest customer service center. OPERATION/RUN indicator or other indicators continue flashing. Fuse blows frequently or circuit breaker trips frequently.
-
Page 15: Installation Manual
INSTALLATION MANUAL Before using your air conditioner, please read this manual carefully and keep it for future reference.. INVERTER SPLIT-TYPE ROOM AIR CONDITIONER The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. -
Page 16: Safety Precautions
SAFETY PRECAUTIONS INSTALLATION PRECAUTIONS Please read this installation manual carefully before operating the unit to ensure correct installation. If the power cord is damaged, replacement work shall be performed by authorised personnel only. Installation work must be performed in accordance with the national wiring standards by authorised personnel only. -
Page 17: Installation
INSTALLATION SELECT THE BEST LOCATION Indoor unit There should not be any heat source or stream near the unit. Above 15cm There should not be any obstacles blocking the air circulation. A place where air circulation in the room is good. A place where drainage can be easily done. -
Page 18: Indoor Unit Installation
INDOOR UNIT INSTALLATION INSTALLATION PLATE MOUNTING NOTE: NOTE: The mounting wall is strong and solid Mount the Installation Plate and drill enough to prevent it from the vibration. holes in the wall according to the wall structure and corresponding Installation Plate Mounting mounting points on the installation 1. - Page 19 INDOOR UNIT INSTALLATION CONNECTIVE PIPE AND DRAINAGE INSTALLATION Dr ai nag e 1. Run the drain hose sloping downward. Do not install the drain hose as illustrated in wrong figures. 2. When connecting extension drain hose, insulate the connecting part of extension drain hose with a shield pipe, do not let Wrong the drain hose slack.
- Page 20 INDOOR UNIT INSTALLATION CONNECT THE CABLE TO THE INDOOR UNIT Electrical work Electric safety regulations for the initial Installation 1. If there is serious safety problem about the power supply, the technicians should refuse to install the air conditioner and explain to the client until the problem is solved. 2.
-
Page 21: Outdoor Unit Installation
OUTDOOR UNIT INSTALLATION OUTDOOR INSALLATION PRECAUTION Install the outdoor unit on a rigid base to prevent increasing noise level and vibration. Determine the air outlet direction where the discharged air is not blocked. In the case that the installation place is exposed to strong wind such as a seaside, make sure the fan operating properly by putting the unit lengthwise along the wall or using a dust or shield plates. - Page 22 OUTDOOR UNIT INSTALLATION CONNECT THE CABLE TO THE OUTDOOR UNIT 1. Remove the electrical control board cover from the outdoor unit by loosening the screw. 2. Connect the connective cables to the terminals as identified with their respective matched numbers on the terminal block of indoor and outdoor units.
- Page 23 OUTDOOR UNIT INSTALLATION 2. When using the Vacuum Pump 1. Completely tighten the flare nuts, A, B, C, D, connect the manifold valve charge hose to a charge port of the packed valve on the gas pipe side. 2. Connect the charge hose connection to the vacuum pump. 3.
-
Page 24: Remote Controller
REMOTE CONTROLLER Please read this Owner's Manual carefully before operation. Save this manual in a safe place for future reference. - Page 25 REMOTE CONTROLLER AIR-CONDITIONER REMOTE CONTROLLER INSTRUCTIONS 自动 自动 自动 AUTO 制冷 制冷 制冷 COOL HIGH 除湿 除湿 除湿 制热 制热 制热 HEAT ON/OFF MODE CLEAN SPEED SLEEP FRESH STRONG SWING DUST FEELING HEALTH FUNGUSPROOF SCREEN TIMER “ ” Read this instructions carefully so that ●...
- Page 26 REMOTE CONTROLLER Buttons description LCD displays ins truction TRANSM IT DIGITAL O N/OFF 自动 自动 自 动 AU TO RUNN ING SE T ROO M 制冷 制冷 制 冷 MO DE COOL HIG H 除湿 除湿 除 湿 RUNNING MODE 制热...
- Page 27 REMOTE CONTROLLER “ ” FEELING button “ ” When it displays FEELING button Pres s this bu tton can be used to set the feeling function. The LCD sho ws the a ctual room temperature when the function set and it shows the setting temperature when the function cancelle d.
- Page 28 REMOTE CONTROLLER “ ” “ ” button “ ” “ ” Press the + or - button,you can set the temperature ℃ ℃ range from to 32 ,Display will change as you touch the button. “ ” CLEAN button “ ”...
- Page 29 REMOTE CONTROLLER ” button 13.“ SWING Press this button, the horizontal wind direction vanes can rotate automatically, when you have the desired vertical wind direction, press it again, the horizontal wind direction vanes will be stopped at th e situation of your choice. ”...
- Page 30 REMOTE CONTROLLER Usage Fix batteries 1.Slide open the cover according the direction indicated by arrowhead. 2.Put into two brand new batteries (7#), position the ＆ batteries to right electric poles (+ -). 3.Put back the cover. Automatic operation mode 1.Press the MODE button, select the automatic operation mode.
- Page 31 REMOTE CONTROLLER Fan operation mode 1.Press the MODE button, select the C ooling or Heating operation mode. 2.Press the SPEED button, you can select fan speed. You can select fan speed from LOW, MID, HIGH. 3.Press the ON/OFF b utton, th e operation indicator is o n, the air-condition er starts to operate the a utomatic mode.
- Page 32 REMOTE CONTROLLER Attention 1.Aim the remote con troller toward s the receiver on the air- conditio ner. 2.The remote controller s hould be within 8 meters away from the receiver. 3.No obstacle s be tween the re mo te controller and receiver. 4.Do not drop or throw the remote con trolle r.
- Page 33 NOTES...
- Page 34 ASK FOR MORE INFORMATION Phone: (+34) 93 446 27 81 eMail: info@mundoclima.com TECHNICAL ASSISTANCE Phone: (+34) 93 652 53 57 www.mundoclima.com...
