Summary of Contents for Prosonic NeoMatic IIe
- Page 1 NeoMatic ProsonicIIe ® Hearing Sound Amplifiers [Battery Operated] I N S T R U C T I O N S M A N U A L...
-
Page 3: Table Of Contents
TABLE OF CONTENTS: Get extra copies of this User’s Instructional Brochure..Installing & replacing battery........Turn ON/OFF & adjusting volume......Wearing the device............. Maintenance & repair service........Use and care............... Limited Warranty............Statement of using hearing aids......Identification of known side effects......Warning to hearing aid dispensers...... -
Page 4: Get Extra Copies Of This User's Instructional Brochure
You have our commitments to continue provide with support for you in using the ProSonic IIe™ Hearing Sound Amplifier you just bought. It is primary important for you to read thoroughly this User’s Instructional Brochure before using the ProSonic IIe™... - Page 5 The ProSonic IIe™ Hearing Sound Amplifier consists of one ProSonice IIe™ sound amplification unit, one flex ear hook, three silicone flange ear tips, two AG13/LR-44 1.5 volt Alkaline button cell batteries, as illustrated below. - 3 -...
- Page 6 Illustrations of the ProSonic IIe™ hearing amplifier provided in below and the following page indicating the function of all controls intended for user adjustment, and the location of the battery compartment convenient to you in using the device. ProSonic IIe™ side-view-right diagram: ON/OFF and High &...
- Page 7 ProSonic IIe™ side-view-left diagram: Flex Hook Volume Control Silicone flange eartip Receiver (speaker) Battery Pivot door - 5 -...
- Page 8 INSTALLING SILICONE EARTIP: 1. The ProSonic IIe™ Hearing Sound Amplifier comes with 3x silicone flange ear tips each has its different head diameter to accommodate to different size of ear canals. You may want to try out all three sizes for your most comfortable fit and best listening result.
-
Page 9: Installing & Replacing Battery
INSTALLING & REPLACING BATTERY: The battery compartment of the ProSonic IIe™ Hearing Sound Amplifier is sized to fit two of the AG13/LR-44 1.5V Alkaline battery cells to operate on 3.0 volts. Battery polarity is clearly marked on the bottom of its battery compartment. - Page 10 INSTALLING & REPLACING BATTERY (cont’d): 2. Lift the battery compartment cover with your right hand, install two AG13/LR-44 battery cells that supplied to you. Be sure the positive “+” post (flat end) of each battery you installed is facing you; see diagram below. 3.
- Page 11 Battery life of each AG13/LR-44 Alkaline battery cell is in approximately 14 hours of continuous use. To prolong life of battery, turn the ProSonic IIe™ Hearing Sound Amplifier off when not in use. For optimal performance, replacing batteries in the device on a regular basis is recommended.
-
Page 12: Turn On/Off & Adjusting Volume
HOW TO TURN ON/OFF AND ADJUSTING VOLUME: 1. To turn ON the device, slide the switch located on the side of the device to either “Low” or “Hi” position. The red LED light will light indicating the device in its ON operating state. Hi - is for listening to high pitch sound (e.g. - Page 13 HOW TO TURN ON/OFF AND ADJUSTING VOLUME (cont’d): 2. To turn off the device, simply slide same switch to its “OFF” position. The red light comes off indicating the device in its OFF operating state. 3. Volume control is located on the other side of the device. Turn the knob with your thumb or index finger for adjusting volume up-down.
-
Page 14: Wearing The Device
RIGHT or LEFT ear to give a perfect fit. 1. Wearing the ProSonic IIe in your LEFT ear, hold securely the device between the thumb and index finger of your LEFT hand with its bottom (the side where the ear tip is... - Page 15 HOW TO WEAR THE PROSONIC IIe™: (cont’d): 3. The following illustrations are for adjusting the Flex Ear Hook to fit your RIGHT ear. (a) Setup of the device below in the diagram on your left is for fitting your LEFT ear. Now rotate counterclockwise the device on its pivot with the spear tip pointing to your RIGHT.
- Page 16 HOW TO WEAR THE PROSONIC IIe™: (cont’d): (b) Wrap the device with fingers and thumb of your RIGHT hand; position the index finger, middle finger and thumb of your LEFT hand on the midway of the flex wire, pull it straight up from the device.
- Page 17 ProSonic IIe™ Hearing Sound Amplifier. To appropriately tune sound volume is always helpful to eliminate feedback.
-
Page 18: Maintenance & Repair Service
3. Wipe the case with damp cloth only. Do not use liquid or aerosol cleaners to clean the device. 4. When you are not using your ProSonic IIe™ Hearing Sound Amplifier, take the batteries out of the device and store it in a dry cool place, keep out of reach of children. -
Page 19: Use And Care
Avoid using your ProSonic IIe™ Hearing Sound Amplifier in a hot and humid environment, the device can be sensitive to excessive heat and moisture. -
Page 20: Limited Warranty
LIMITED WARRANTY: ProSonic IIe™ Hearing Sound Amplifier you bought is warranted against manufacturing defects in materials and workmanship under normal and intended use for a period of 60 days from date of purchase. If your ProSonic IIe™ Hearing Sound Amplifier... -
Page 21: Statement Of Using Hearing Aids
STATEMENT OF USING HEARING AID: A hearing aid will not restore normal hearing and will not prevent or improve a hearing impairment resulting from organic conditions. In most cases infrequent use of a hearing aid does not permit a user to attain full benefit from it. The use of a hearing aid is only part of hearing habilitation and may need to be supplemented by auditory training and instruction in lip-reading. -
Page 22: Warning To Hearing Aid Dispensers
WARNING TO HEARING AID DISPENSERS: A hearing aid dispenser should advise a prospective hearing aid user to consult promptly with a licensed physician (preferably an ear specialist) before dispensing a hearing aid if the hearing aid dispenser determines through inquiry, actual observation, or review of any other available information concerning the prospective user, that the prospective user has any of the following conditions: (1) Visible congenital or traumatic deformity of the ear. -
Page 23: Important Notice For Prospective Hearing Aid User
WARNING TO HEARING AID DISPENSERS (cont’d): Special care should be exercised in selecting and fitting a hearing aid whose maximum sound pressure level exceeds 132 decibels because there may be risk of impairing the remaining hearing of the hearing aid user. IMPORTANT NOTICE FOR PROSPECTIVE HEARING AID USERS: Good health practice requires that a person with a... - Page 24 IMPORTANT NOTICE FOR PROSPECTIVE HEARING AID USERS (cont’d): If you have reservations about your ability to adapt to amplification, you should inquire about the availability of a trial-rental or purchase-option program. Many hearing aid dispensers now offer programs that permit you to wear a hearing aid for a period of time for a nominal fee after which you may decide if you want to purchase the hearing aid.
-
Page 25: Medical Evaluation Requirements
IMPORTANT NOTICE FOR PROSPECTIVE HEARING AID USERS (cont’d): Medical Evaluation Requirements - Federal law requires that every prospective user, prior to being fit with hearing aids, must have their hearing tested by a hearing professional. Hearing aid dispenser shall not sell a hearing aid unless the prospective user has presented to the hearing aid dispenser a written statement signed by a licensed physician that states the patient’s hearing loss has been medically evaluated and... -
Page 26: Statement Of Waiving Medical Evaluation
The prospective user is required to mail a signed copy of the Statement of Waiving Medical Evaluation to the Customer Service Center of the ProSonic Hearing Sound Amplifier at P O Box 1000, Bellingham WA 98225, U.S.A. Each Statement of Waiving Medical Evaluation will be on record kept for three years on submission. - Page 27 Note: Food and Drug Administration (FDA) wants to ensure that consumers do not mistake pesonal sound amplification products (PSAPs) and the approved hearing aids. Hearing aids and personal sound amplification products (PSAPS) can both improve the ability to hear sound, they are both wearable, and some of the technology and function is similar.
-
Page 28: Product & Technical Information
PRODUCT INFORMATION: ™ Model name: ProSonic IIe Model number: WB-182 U.S. FDA Listed: Class l [510k exempt] TECHNICAL DATA (tested against ANSI S3.22-2003 standard): Amplifier setting: high Battery (2x 1.5V AG13/LR-44 3.0V 3.0V alkaline cells): Battery current drain: 5.1mA 5.1mA... - Page 29 ProSonic IIe™ Hearing Sound Amplifier is measured in dBSPL. The citation test data for the ProSonic IIe™ Hearing Sound Amplifiers on the earlier page and the frequency response curve charts in the above of this page are obtained on testing of the device against the ANSI S3.22-2003 standard which is in compliance with the Class I...
-
Page 30: Manufacturer & Distributor Information
53-57 Kwai Fung Crescent Kwai Chung, New Territories Hong Kong Phone: (852)2619-0833 Fax: (852)2429-0960 Email: info@wellbrain-intl.net FDA registration number: 3004950644 FDA owner/operator number: 9032154 The ProSonic IIe™ Hearing Sound Amplifiers are imported and/or distributed to/in the United States by: - 28 -... - Page 32 As the result of continuous product development, photos and graphics for illustration purpose in this User’s Instructional Brochure may slightly vary from the actual device delivered. ©Well Brain International Ltd, all rights reserved. PP0125E...
