TO :
42-5 DAEWON B/D, JAMWON-DONG, SEOCHO-KU, SEOUL, KOREA

TFT LCD MONITOR 17"

1. Introduction
With an LCD Panel Monitor using a TFT Color LCD, you can use TU17VR a substitution of general PC
Monitor because it can receive the R.G.B input of PC VGA Signal. TU17VR has OSD Function in order to
display the best quality of the screen according to VGA Cards' features. Besides, DVI, NTSC/PAL, S-Video
Signals are available by option, and Touch Screen is also available by customer's request, it can be usable
simultaneously with PS/2 Mouse
Safety Precautions
The safety recommendations outlined in this section are to be read, understood and followed before
operating the product. Keep this information in a safe place for future reference. Failure to comply with any of
the following safety procedures could result in serious hazard.
A. Do not operate product for any purposes other than its intended use.
B. This product is intended for indoor use only.
C. Do not operate product if power cord is damaged in any way.
D. Do not insert object into openings.
E. Do not immerse product in water or permit liquids to spill inside.
F. Turn off power when attended or not in use unplug product before moving it or when it is not
in use for an extended period of time.
Note : These specifications are subject to change for up-date without notification
Jinyoung Contech Co., Ltd.
TEL : 82-2-517-0728
HOME PAGE :
TU17VR
- With Touch Screen (Optional)
TFT LCD Monitor : TU17VR 1/ 13
FAX : 82-2-3442-5029
http://www.jyct.com/
Issued Date :
Dec 23, 2002
Page :
13pages
USER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the TU17VR and is the answer not in the manual?

Questions and answers

Summary of Contents for Jinyoung Contech Co TU17VR

  • Page 1: Tft Lcd Monitor

    1. Introduction With an LCD Panel Monitor using a TFT Color LCD, you can use TU17VR a substitution of general PC Monitor because it can receive the R.G.B input of PC VGA Signal. TU17VR has OSD Function in order to display the best quality of the screen according to VGA Cards’...

  • Page 2: Specifications

    Storage Temperature : -20 ~ 60°C Operating Temperature : 0 ~ 50℃ Dimensions (W x H x D) : 483 x 354.8 x 80 mm Weight : 8.8 Kg Frequency : Hor. 15~60 KHz, Ver. 56~75 Hz TFT LCD Monitor : TU17VR 2/ 13...

  • Page 3: Osd Functions

    - UP/RIGHT :Used for moving BAR position to the rightside from Main Menu or increasing parameter value from SUB Menu. - DOWN/LEFT :Used for moving BAR position to the leftside from Main Menu or decreasing parameter value from SUB Menu. TFT LCD Monitor : TU17VR 3/ 13...
  • Page 4 * The following OSD screen is shown with pressing OSD button. : Automatic adjustment for sharpening screen image. With selecting “YES ”,the text “Auto Adjusting ” is displayed with black screen on the LCD. : Adjusts the black level of the backlight. TFT LCD Monitor : TU17VR 4/ 13...
  • Page 5 : Adjusts the screen position,ADC lock and phase. - Horz. Position : Adjusts the screen position horizontally. - Vertical Position : Adjusts the screen position vertically. - Clock : Adjusts the value of clock per line. TFT LCD Monitor : TU17VR 5/ 13...
  • Page 6 - Phase : Adjusts ADC Sample pixel Clock : Adjusts the gain of each RGB - Red : Adjusts the gain of Red. - Green : Adjusts the gain of Green. - Blue : Adjusts the gain of Blue. TFT LCD Monitor : TU17VR 6/ 13...
  • Page 7 - DOS/GFX :Selects DOS Mode only. - ON : 640 x 400 - OFF : 720 x 400 - OSD Time : Selects OSD time out. - OSD H-Position : Adjusts OSD position horizontally. TFT LCD Monitor : TU17VR 7/ 13...
  • Page 8 : Selects the mode the display.(optional) - Analog : Analog R.G.B Input Select - Digital : DVI(Digital Video Interface) Input Select - Video : NTSC/PAL Video input Select - S-Video : S-Video Input Select TFT LCD Monitor : TU17VR 8/ 13...
  • Page 9 * Video Menu : Adjusts and saves the parameter value related with video function from Video Menu. : Adjusts the black level of the backlight. : Adjusts the contrast ratio of the video image. : Adjusts the combination of the Hue. TFT LCD Monitor : TU17VR 9/ 13...
  • Page 10 Input Not Supported Mode : In case of detecting the mode that cannot be supported by LCD,the below message is displayed on black screen.In order to remove the phenomenon,it should be switched into the mode that can be supported by LCD. TFT LCD Monitor : TU17VR 10/ 13...
  • Page 11 - Adjusts the screen to be the best by selecting PHASE. - After completion of the adjustment,close the OSD screen first and select “NO ” from SHUT DOWN screen,and then check the display quality. TFT LCD Monitor : TU17VR 11/ 13...
  • Page 12 4. Connectors Touch, S-Video, NTSC/PAL, DVI is Optional 5. Dimensions TFT LCD Monitor : TU17VR 12/ 13...
  • Page 13 1. Packing List Ÿ LCD Monitor Ÿ LCD Monitor Manual Ÿ AC Power Inlet Cable Ÿ VGA Cable Ÿ Touch Cable (Optional) Ÿ Touch Screen Install Diskette (Optional) Ÿ Touch Screen User’s Manual (Optional) TFT LCD Monitor : TU17VR 13/ 13...
