Summary of Contents for Edge-Core RPS900W

  • Page 1 RPS900W Redundant Power Supply I n s t a l l a t i o n G u id e www.edge-core.com...
  • Page 3 I n s t a ll a ti o n G u id e RPS900W Redundant Power Supply Single DC Output Port with Dual Output Voltages RPS900W E102013-CS-R01 150200000812A...
  • Page 5: How To Use This Guide

    How to Use This Guide This guide includes detailed information on the RPS hardware, including power requirements and LED status indicators . This guide also provides general installation guidelines and recommended procedures. To deploy this RPS effectively and ensure trouble-free operation, it is recommended to first read the relevant sections in this guide so that you are familiar with all its hardware components.
  • Page 6 How to Use This Guide Conventions The following conventions are used throughout this guide to show information: Note: Emphasizes important information or calls your attention to related features or instructions. Caution: Alerts you to a potential hazard that could cause loss of data, or damage the system or equipment.
  • Page 7: Table Of Contents

    Contents How to Use This Guide Contents RPS Description and Specifications Overview Key Hardware Components Key Technical Specifications Installing the RPS Package Contents General Installation Guidelines How to Install the RPS in a Rack How to Install the RPS on a Shelf or Desktop RPS Cooling Requirements Grounding the Chassis Connecting the RPS to a Switch and AC Power Source...
  • Page 8 Contents – 8 –...
  • Page 9: Rps Description And Specifications

    RPS Description and Specifications Overview Thank you for choosing the RPS900W redundant power supply (RPS). This RPS is built to provide a reliable redundant power source for Edge-Core ECS4510-52P and ECS4620-52P PoE-enabled switches that are equipped with a redundant DC power input connector.
  • Page 10: Key Hardware Components

    Chapter 1 | RPS Description and Specifications Key Hardware Components ◆ The RPS will operate under a no-load condition. Key Hardware Components Two status indicators, SYS and PoE LEDs, are located on the RPU’s front panel. While the AC input socket, grounding point, and DC output connector are located on the RPU’s rear panel.
  • Page 11 Chapter 1 | RPS Description and Specifications Key Hardware Components AC Input Socket The RPS requires a 100-240 VAC, 50-60 Hz AC power source. For more information on the RPS power input, how to connect it, and how to power-on the RPS, see “Connecting the RPS to a Switch and AC Power Source”...
  • Page 12: Key Technical Specifications

    Chapter 1 | RPS Description and Specifications Key Technical Specifications Key Technical Specifications The following table contains key system specifications for the RPS. Table 1: Key Technical Specifications Item Specification Ports Single Female DB-25 DC Output Port LEDs Sys, PoE Weight 3.9 kg (8.6 lb) Size...
  • Page 13: Installing The Rps

    Installing the RPS The RPS is designed to be installed in a standard 19-inch equipment rack. Before continuing with the RPS installation, first review the general guidelines and RPS cooling requirements in this chapter. This chapter includes these sections: ◆ “Package Contents”...
  • Page 14: Package Contents

    After unpacking the RPS, check the contents to be sure you have received all the components. ◆ RPS900W Redundant Power Supply ◆ Rack Mounting Kit — Contains two mounting brackets and eight screws for attaching the brackets to the RPS.
  • Page 15: How To Install The Rps In A Rack

    Chapter 2 | Installing the RPS How to Install the RPS in a Rack How to Install the RPS in a Rack When rack mounting the RPS, pay particular attention to the following factors: ◆ Rack Types: You can use any standard EIA 19-inch equipment rack with either two or four posts.
  • Page 16 Chapter 2 | Installing the RPS How to Install the RPS in a Rack Rack-Mount Procedure To rack mount the RPS, follow these steps: Attach the brackets to the RPS using the screws provided in the Rack Mounting Kit. Figure 4: Attaching the Extension Brackets Rack Mounting Bracket Bracket Screws Following your rack plan, mark the holes in the rack where the RPS will be...
  • Page 17: How To Install The Rps On A Shelf Or Desktop

    Chapter 2 | Installing the RPS How to Install the RPS on a Shelf or Desktop Figure 5: Installing the RPS in a Rack Rack Mounting Screws Go to “Grounding the Chassis” on page How to Install the RPS on a Shelf or Desktop The RPS can be installed on any flat surface such as a desktop or shelf.
  • Page 18: Rps Cooling Requirements

    Chapter 2 | Installing the RPS RPS Cooling Requirements Figure 6: Attaching the Adhesive Feet Adhesive foot pad Set the device on a flat surface near an AC power source and near enough to the switch so that the DC power cable will reach. Make sure there are at least two inches of space on all sides for proper airflow.
  • Page 19 Chapter 2 | Installing the RPS RPS Cooling Requirements Figure 7: RPS Cooling Warm Air Cool Air Rack Cooling When mounting the RPS in an enclosed rack or cabinet, be sure to check the following guidelines to prevent overheating: ◆ Make sure that enough cool air can flow into the enclosure for the equipment it contains.
  • Page 20: Grounding The Chassis

    Chapter 2 | Installing the RPS Grounding the Chassis Grounding the Chassis The rear panel of the RPS chassis includes a dual-screw grounding terminal. It must be connected to ground to ensure proper operation and to meet electromagnetic interference (EMI) and safety requirements. Figure 8: Grounding Terminal Grounding Wire Dual-Screw Grounding Terminal...
  • Page 21: Connecting The Rps To A Switch And Ac Power Source

    Chapter 2 | Installing the RPS Connecting the RPS to a Switch and AC Power Source Caution: The earth connection must not be removed unless all supply connections have been disconnected. Go to “Connecting the RPS to a Switch and AC Power Source” on page 21. Connecting the RPS to a Switch and AC Power Source The RPS is shipped with a custom DC power cable that you must use to connect the RPS to a switch.
  • Page 22 Chapter 2 | Installing the RPS Connecting the RPS to a Switch and AC Power Source Connect the DB-25 male end to the DC output connector on the RPS. Connect one end of the AC cord to the AC socket on the RPS, and the other end to a grounded power outlet.
  • Page 23: Understanding The Sys And Poe Leds

    Chapter 2 | Installing the RPS Understanding the SYS and PoE LEDs Table 2: AC Power Supply Specifications Item Description AC Input AC 100-240 V, 50-60 Hz, 12 A @ 100 VAC, 6 A @ 240 VAC Power Supply 100-240 VAC, 50-60 Hz, auto-sensing Maximum Power Output 11.3 VDC: 126 W 53.8 VDC: 780 W...
  • Page 24 Chapter 2 | Installing the RPS Understanding the SYS and PoE LEDs Table 3: SYS and PoE LEDs Condition Status On Green The RPS 11.3 VDC output voltage is within specifications. The RPS 11.3 VDC output voltage is outside specifications or has failed.
  • Page 25: Troubleshooting

    Troubleshooting Diagnosing LED Indicators Table 1: Troubleshooting Chart Symptom Action ◆ Sys LED is Off Confirm the DC power cable is installed correctly and there is no apparent damage to it; if so, replace it. ◆ Confirm the AC power source is within the specified requirements; if not, connect the RPS to another AC power outlet which provides the correct power specification.
  • Page 26: A Troubleshooting

    Appendix A | Troubleshooting Installation – 26 –...
  • Page 28 Declaration of Conformity (DoC) can be obtained from www.edge-core.com -> support -> download -> declarations & certifications RPS900W E102013-CS-R01 150200000812A...
