- Page 1 Buddy BX2 User’s Manual User Manual rev.01 TTI Tracking Technology Inc. (Rev.1)
- Page 2 Before you use Thank you for purchasing Buddy BX2. This manual explains how to Install and use the device. Please read the information below before using the device to avoid the discomfort in using the device. Notice Please understand there might be some error in describing and editing this manual.
-
Page 3: Table Of Contents
Caution to SD the card 6. Description of Product usage 1. About Product 7. Install the viewer program in PC 2. Configuration of product 8. Menu 3. Name of each part 9. How to upgrade 4. Specification TTI Tracking Technology Inc. (Rev.1) -
Page 4: Caution For The Safety
11.7V to protect the battery of used for the long time. When GPS signal is locked, it is to the car. When 13V power comes, the normal operation be automatically set by the live time. restarts. TTI Tracking Technology Inc. (Rev.1) -
Page 5: Caution To Sd The Card
3 to 5 minutes or more after the first time, or insert the SD memory format create a file system check and SD memory recording begins. If SD card is removed on creating data, the record operation cannot be made. TTI Tracking Technology Inc. (Rev.1) -
Page 6: About Product
Transfer one image per each event through Wi-Fi to PC server. Wi-Fi Smart High bright security LED Security Support constant power discharge protection Smart function Saving Power Off-11.7V, Power On – 13V TTI Tracking Technology Inc. (Rev.1) -
Page 7: Configuration Of Product
Configuration of the product TTI Tracking Technology Inc. (Rev.1) -
Page 8: Name Of Each Part
Name of Each part TTI Tracking Technology Inc. (Rev.1) -
Page 9: Specification
Internal view camera : About 130° wide angle lens Viewer Windows XP/ VISTA/ 7/ 8-32Bit/ 64Bit Power DC 12V ~ 24V Operation temperature -20°~60°C(Storage temperature: -20° ~ 90°C) Humidity 10~95% Weight 150g Dimension (W x D x H) 64(W) x 112(D) x 47.2(H)mm TTI Tracking Technology Inc. (Rev.1) -
Page 10: Installing The Product
Please preferably install this device away from other electronic products such as navigation. Installation First, please make the position on the front of rearview mirror and set the device on the middle of top of location windshield by the camera with keeping it horizontally. TTI Tracking Technology Inc. (Rev.1) - Page 11 TTI Tracking Technology Inc. (Rev.1)
- Page 12 3 to 5 minutes or more after the first time, or insert the SD memory format create a file system check and SD memory recording begin When “Recording starts” voice guide comes up, the device starts recording. TTI Tracking Technology Inc. (Rev.1)
-
Page 13: Description Of Product Usage
When the device is disconnected with the power, REC LED powers off. GPS LED starts flickering then if 3D reception status comes, GPS LED keeps bright. Emergency When the emergency button shortly pressed, “emergency” recording starts. TTI Tracking Technology Inc. (Rev.1) - Page 14 If the motion is detected in 3 meter in front of the vehicle in the parking mode, motion mode recording Motion is to start.(This can be influenced with the circumstance and light). After the end of the motion recording, the parking mode restart. TTI Tracking Technology Inc. (Rev.1)
- Page 15 Reboot because of the damaged SD card. Please replace the SD card if this occurrence continues. Normal FW update Firmware update in process, please do not power off. Fail updating FW Firmware update process has been terminated. TTI Tracking Technology Inc. (Rev.1)
-
Page 16: Install The Viewer Program In Pc
3~5minutes to create the data file system(after normal booting with flickering all LEDs, recording start with turning on REC LED). ④ Please take out SD card and insert it in PC. ⑤ Please execute “Viewer.exe” file in PC. ⑥ Please click “Yes(Y)” in “User account control” menu. TTI Tracking Technology Inc. (Rev.1) - Page 17 ⑧ If the network is connected, “the latest version confirmation” window about the firmware and viewer program pops up. If you want to upgrade them, please click ”Upgrade”. If the network is not connected, Buddy BX2 viewer program runs. TTI Tracking Technology Inc. (Rev.1)
- Page 18 ⑨ When the installation is completed, Buddy BX2 viewer program automatically runs and Buddy BX2 viewer program icon is to be created on ⑩ Open a file- when you click “Open” in the viewer, please choose one removal Disk then click “confirm”...
-
Page 19: Menu
Switching screen, volume Black white screen Speed (only case that a GPS is Play list connected) E-Google map on GPS signal internet bar(only case that (only case that a a GPS connected) GPS connected). G-sensor graph TTI Tracking Technology Inc. (Rev.1) - Page 20 SD card. Standard time zone : Setting the appropriate time for each country Auto Reboot -Set the auto reboot once daily for keeping the stable operation Km/Miles- Choose Kilometers or Miles on viewer. TTI Tracking Technology Inc. (Rev.1)
- Page 21 Caution If the device is powered on after changing the proportion of event folder, SD card is always formatted automatically. Please note this point and please back up the important recorded data in advance. TTI Tracking Technology Inc. (Rev.1)
- Page 22 This menu is for the private information. Please keep this information from the disclosure. In case of forgetting the password, you never log and watch the recorded data at all in the viewer program. TTI Tracking Technology Inc. (Rev.1)
- Page 23 The speed of the SD card declines significantly when used for a long period of time. The management of SD card is important. Check and format the SD card once every a week . TTI Tracking Technology Inc. (Rev.1)
- Page 24 SD card into PC then make progress for upgrading the firmware. In case that the latest firmware is downloaded without SD card, please copy and paste the downloaded file in the “update” folder of SD card used in the device. TTI Tracking Technology Inc. (Rev.1)
- Page 25 AVI file can be played in the Windows Media Player and other AV media player. c. JDR backup file can played back only in Buddy BX2 viewer program. d. Image backup file can be showed in the image viewer or the paint program.
- Page 26 On the play screen, click the right button of the mouse on the position to make the zoom. You can move everywhere for the zoom after pressing the button of the mouse. Press Magnification the right mouse to remove the Magnification function. TTI Tracking Technology Inc. (Rev.1)
- Page 27 Click ‘Panorama’ icon as above to start. 16 divided screens will show up, each screen shows individual frame in sequence. Double click on one screen to show full screen. Thumbnail To cancel Panorama mode, click Restore screen button as red marked. TTI Tracking Technology Inc. (Rev.1)
- Page 28 In playing back the data, time, date and speed shows up in the bottom left of the video screen. Notation about time and date is applied to all the back-up file. TTI Tracking Technology Inc. (Rev.1)
- Page 29 Update(firmware update folder) firmware is being automatically proceeding. . Caution - Freely deleting and formatting files in SD card are strictly prohibited. - Please back up the important recorded data in the PC. TTI Tracking Technology Inc. (Rev.1)
-
Page 30: How To Upgrade
If you press “Upgrade” button in “the latest version” menu, the upgrade file is automatically copied into the “update” folder of the SD card. ④ The process after ③ is same with the manual upgrading process. TTI Tracking Technology Inc. (Rev.1) - Page 31 - Network Key : Set a password of wireless AP - Auth Mode : Set a auth mode of AP. Choose one among OPEN, WPAPSK and WPA2PSK. - Encryption Type: Choose one among TKIP and AES. TTI Tracking Technology Inc. (Rev.1)
