Touch Dynamic QS 300 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
VERSION V1.1 March 2011
QS 300
Hardware
System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QS 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Touch Dynamic QS 300

  • Page 1 USER MANUAL VERSION V1.1 March 2011 QS 300 Hardware System...

  • Page 2: Important Safety Instructions

    Copyright 2011 All Rights Reserved Manual Version 1.1 Part Number: 3LMPP7950110 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Caution On Lithium Batteries

    CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 4 LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.

  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release 2010 January • B78 motherboard updated to V2.4 • B98 motherboard updated to V1.1 2011 March • C48 V2.1 motherboard added • pSSD card replacement added...

  • Page 6: Table Of Contents

    Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........2 2. System View ......3 2-1. Front View ...............3 2-2. Side View ..............3 2-3. Rear View with stand ..........4 2-4. Rear View without wall mount bracket .....4 2-5.
  • Page 7 4-6. CF Card Replacement ..........15 4-6-1. On a Fan System ............ 15 4-6-2. On a Fanless System ..........15 4-7. pSSD Card Replacement ........16 4-7-1. On a Fan System ............ 16 4-7-2. On a Fanless System ..........16 4-3. Cash Drawer Installation ........17 4-3-1.

  • Page 8: Packing List

    Packing List 111. Standard Accessories System (with stand) Driver bank Power adapter Power cord RJ45-DB9 cable (x2)

  • Page 9: Optional Accessories

    112. Optional Accessories Metal MSR Metal VFD Wall-mount Kit CF Card Adapter Board pSSD Card module WLAN Card (with external antenna) pSSD Card...

  • Page 10: System View

    System View 211. Front View 212. Side View Fanless System Fan System Item No. Description Touch Screen MSR Module (Optional) External Antenna (Optional) Hinge Cover for stand installation Stand...

  • Page 11: Rear View With Stand

    213. Rear View with stand Fan System Fanless System 214. Rear View without wall mount bracket Fan System Fanless System Item No. Description VFD (Optional) HDD Door for fan system Ventilation for fan system Cable management outlet VESA hinge bracket I/O ports cover...

  • Page 12: I/O Ports View

    215. I/O Ports View Fan System d e f g Fanless System d e f g Item No. Description Parallel USB x 4 COM 1, 2, 3, 4 (from right to left) Line-out MIC-in Cash Drawer (12V or 19V, can support 24V) Power Switch DC-In PS/2...

  • Page 13: System Dimension

    216. System Dimension 15" System 17" System 411 mm 386 mm 220 mm 220 mm 80 ° 80 ° 250 mm 250 mm...

  • Page 14: System Assembly

    System Assembly To remove and replace the HDD, please follow below steps. The procedures may be different depending on the fan or fanless system being installed. 311. HDD replacement for fan system Turn to the rear side of the system. Loosen the screw (x1) securing the HDD door at the rear cover of the system.

  • Page 15: Ram Replacement

    313. RAM Replacement Please open the rear cover (see Chapter 3-1 or 3-2) first then remove and replace the RAM module. You can refer to the motherboard layout to find the memory compartment. (See chapter 6-1, 6-2, 6-3, 6-4 for different motherboard) Removing a RAM module Unfasten the screws (x17) of the rear cover to access the...

  • Page 16: Power Adapter Replacement

    314. Power Adapter Replacement Find the power bracket in the bottom of the stand and disconnect the power cable from the adapter. Loosen the screws (x2) and separate the power bracket from the stand. Disconnect the other end of the power adapter from the connector on the I/O panel.

  • Page 17: Peripheral Installation

    Peripheral Installation 411. MSR Installation 1. Connect the MSR module into the system and fasten the screws (x2). 2. Connect the PS/2 Connector into the PS/2 port on the I/O panel. Note: the PS/2 port locates in different places on the I/O panel according to the fan or fanless system being installed.

  • Page 18: Wall Mount Kit Assembly

    413. Wall Mount Kit Assembly Accessories items a. Metal bracket with thumb screw b. Screw x 1 c. Wall mount bracket Fix the metal bracket (a) to the VESA bracket and the display with the screw (b) (x1). Align the tear drop holes of the wall mount bracket (c) into the 4 VESA bracket screws.

  • Page 19: Desktop Stand Assembly

    414. Desktop Stand Assembly Accessories items a. VESA bracket b. Stand bracket c. Stand d. Hinge cover x2 e. Screws for both sides of stand x6 f. Screws for VESA bracket x 4 VESA bracket assembly Align the standard VESA mounting holes of the VESA bracket (a) and the display and fix them with the screws provided (f) (x4).

  • Page 20: Wireless Lan Installation

    415. Wireless LAN Installation 41511. On a Fan System Disconnect the HDD cable from the system first (see Chapter 3-1). Loosen the screws (x17) to remove the rear cover (a). Assemble the antenna cable (b) by fasten the nut, washer and the coaxial cable as picture shown.

  • Page 21: On A Fanless System

    41512. On a Fanless System To install the external antenna and the wireless LAN card for fanless System, please see below pictures and instructions. Open the rear cover by removing the screws (x17) Fix the antenna mounting bracket (b) with the screw (x1) onto the LCD chassis under the rear cover.

  • Page 22: Cf Card Replacement

    416. CF Card Replacement If your system equipped with CF Card instead of hard drive disk as storage device, please follow below steps to replace the CF card. 41611. On a Fan System Turn to the rear side and open the HDD door on a fan system (see Chapter 3-1) Replace the CF Card as right picture...

  • Page 23: Pssd Card Replacement

    417. pSSD Card Replacement If your system equipped with pSSD Card instead of hard drive disk as storage device, please follow below steps to replace the SSD card. 41711. On a Fan System 1. Fasten the screw(x4) on the rear side of the pSSD holder bracket to fix the pSSD card.

  • Page 24: Cash Drawer Installation

    413. Cash Drawer Installation 41311. For B78 motherboard You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 25 Bit 7: Reserved. Bit 6: Reserved. Bit 5: Reserved. Bit 4: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer. = 0: the Cash Drawer opened. Bit 3: Reserved. Bit 2: Cash Drawer “DOUT bit0” pin output control. = 1: Opening the Cash Drawer = 0: Allow closing the Cash Drawer Bit 1: Cash Drawer “DOUT bit1”...

  • Page 26: For B68/B98/C48 Motherboard

    41312. For B68/B98/C48 motherboard You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Below cash drawer installation is applicable for B68, B98 and C48 motherboard. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1...
  • Page 27 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 28: Specification

    Specification Motherboard Fan/Fanless Fanless Fanless Fanless Intel Celeron Intel Celeron Intel Pineview Intel Atom N270 Intel Celeron M 1.86GHz / M 1.5GHz / D525 dual core CPU Support processors 1.6G M ULV 1.0GHz Core duo 2.0GHz / 1.8G L2 1M, Pentium M (BGA) (BGA)
  • Page 29 Motherboard LAN (10 /100 / 1000) 1 x RJ45 DC Jack Cash Drawer Port 1 x RJ 11 (12V /19V) Audio Jack 1 x Line-out, 1 x Mic-in Audio Built in Speaker 2x2W 2x2W Power Power Adapter 19V, 90W Control Power Button Peripheral Metal MSR...

  • Page 30: Jumper Setting

    Jumper Setting 611. B68 Motherboard 61111. Motherboard Layout JP11 Version: B68 v1.0...

  • Page 31: Connectors & Functions

    61112. Connectors & Functions Connector Purpose BAT1 CMOS Battery Base ( Use CR2023) Power On Button Touch Sensor Power LED SATA1 HDD Power Connector SATA2 HDD Power Connector LCD Interface Connector IrDA Connector For External Touch Connector Inverter Connector CN10 Card Reader Connector CN11 Line Out...
  • Page 32 Connector Purpose Power On Bottom CRT Connector Power Option for COM3/COM4 2nd Display Power COM2 Connector COM2(RS232/422/485) Setting LCD ID Setting RTC Reset AT Function JP11 Cash Drawer Power Setting (+12V,+19V) JP12 Hardware Reset...

  • Page 33: Jumper Setting

    61113. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 5 7 9 11 ▲RS232 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 &...
  • Page 34 Cash Drawer Power Setting Function JP11 +12V ▲+19V (for 24V Cash Drawer) Power Mode Setting Function ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset VGA Power Setting Function ▲No Power +12V ▲ = Manufacturer Default Setting...
  • Page 35 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel LVDS 1366 x 768 Single Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 800 x 600 Single...

  • Page 36: B78 Motherboard

    612. B78 Motherboard 61211. Motherboard Layout JP10 JP14 JP13 Version: B78 v2.4...

  • Page 37: Connectors & Functions

    61212. Connectors & Functions Connector Function BAT1 CMOS Battery Base ( Use CR2023) Audio Line Out Audio MIC In Internal Power Switch Speaker & MIC Connector CD-IN Connector CN11 Power Connector For 3.5" HDD CN13 COM5 for Touch CN15 CPU FAN Connector CN16 Hardware Reset CN18...

  • Page 38: Jumper Setting

    61213. Jumper Setting COM2 RS232/485/422 Setting Function JP10 5 7 9 5 7 9 ▲RS232 8 10 6 8 10 5 7 9 11 5 7 9 RS485 6 8 10 12 8 10 5 7 9 11 5 7 9 RS422 8 10 COM3 &...
  • Page 39 Cash Drawer Power Setting Function +12V ▲+19V (for 24V Cash Drawer) Power Mode Setting Function ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset USB Path Setting Function JP14 ▲To Docking To Motherboard System Indicator Function Function JP13 ▲Disable Enable...
  • Page 40 LCD ID Setting LVDS Panel# Resolution Bits Channel 640 x 480 Single 800 x 600 Single 1024 x 768 Single 1280 x 1024 Dual 1024 x 768 Single 800 x 600 Single 800 x 600 Single 800 x 600 Single 1024 x 768 Single 1440 x 900...

  • Page 41: B98 Motherboard

    613. B98 Motherboard 61311. Motherboard Layout JP13 Version: B98 v1.1...

  • Page 42: Connectors & Functions

    61312. Connectors & Functions Connector Purpose BAT3 CMOS Battery Base (Use CR2023) Audio Line Out MIC In Internal Power On Switch Connector Speaker & MIC Connector Internal LAN LED CN11 CD-IN / Line-In Connector CN12 LCD Interface Connector CN13 IrDA Connector CN14 Inverter Connector CN15...

  • Page 43: Jumper Setting

    61313. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 11 5 7 9 ▲RS232 6 8 10 12 6 8 10 5 7 9 5 7 9 RS485 8 10 6 8 10 5 7 9 11 5 7 9 RS422 8 10 COM3 &...
  • Page 44 Cash Drawer Power Setting Function +12V ▲+19V (for 24V Cash Drawer) Power Mode Setting Function JP11 ▲ATX Power AT Power CMOS Operation Mode Function ▲CMOS Normal CMOS Reset System Indicator Function JP12 ▲Disable Enable ▲ = Manufacturer Default Setting...
  • Page 45 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 1366 x 768 Single Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 800 x 600 Single...

  • Page 46: C48 Motherboard

    614. C48 Motherboard 61411. Motherboard Layout PWR1 MINI_PCIE JP12 JP12 CN24 CN23 RJ45_2 JP10 JP10 JP19 JP19 CN22 RJ11_1 CN21 CN15 CN20 CN17 CN18 CN19 SKT1 JP14 JP14 CN16 CN14 CN13 CN27 CN31 SATA2 JP18 JP20 JP20 JP18 RJ45_1 CN11 CN26 SATA1 USB2...
  • Page 47 DDR3_A2 Version: C48 v2.1 BUTTOM LAYER...

  • Page 48: Connectors & Functions

    61412. Connectors & Functions Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN17 CD IN CN18 MIC IN CN19 Power LED CN20/JP10...

  • Page 49: Jumper Setting

    61413. Jumper Setting COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 Cash Drawer Power Setting...
  • Page 50 System Indicator Function JP10 ▲Disable Enable Inverter Selection Function JP14 ▲ CCFL CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’.
  • Page 51 COM3 & COM4 Power Setting COM3 and COM4 can be set to provide power to your serial device. The voltage can be set to +5V or 12V by setting jumper JP18 on the mother- board. When enabled, the power is available on pin 10 of the RJ45 serial con- nector.
  • Page 52 LCD ID Setting Several configurations are applied to different sizes of panel. Please refer to the followings to complete relevant settings. LVDS Resolution Output Interface Bits Channel 800 x 600 Single 1024 x 768 Single 1366 x 768 Single 1st: LCD Panel 800 x 600 Single 2nd: VGA port...
  • Page 53 4. To switch on the power, select "+12V". Save the change by pressing F10. LCD Brightness Control Setting Please note Brightness Control can only be set by setting jumper JP14 for CCFL on the motherboard C48 V2.1. By default, the inverter is CCFL on the motherboard jumper setting.

  • Page 54: Appendix: Drivers Installation

    Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.

Table of Contents
