Phat Noise
Digital Media Player
Installation Instructions
000 057 1 10
Description
Passat Sedan/Wagon
Golf/GTI
Jetta Wagon
PhatNoise
Revision 1
06-23-03
Page 1
Installation
Page 6
Set up & Testing
Page 32
Appendix A Template
Page 9
Appendix B Troubleshooting guide
Page 12
Appendix C Quick Reference
Application
98>
99.5>
01>
Advertisement
Related Manuals for PhatNoise 000 057 110
Summary of Contents for PhatNoise 000 057 110
- Page 1 Part Number 000 057 1 10 Description Application Fitment Passat Sedan/Wagon 98> Golf/GTI 99.5> Jetta Wagon 01> Supplier PhatNoise Revision 1 Published date: 06-23-03 Sections: Page 1 Installation Page 6 Set up & Testing Page 32 Appendix A Template Page 9...
- Page 2 Part Number: 000 057 1 10 Fitments: Passat Sedan/Wagon 98> Description: Digital Media Player Golf/GTI 99.5> Jetta Wagon 01> Supplier: PhatNoise Tools Required for Phat Noise Digital Music Player Installations Blade Phillips Scratch Socket 10mm Screwdriver Screwdriver Wrench Socket 3mm Allen Wrench...
- Page 3 01> Supplier: PhatNoise 000 057 1 10 Phat Noise Digital Media Player Installation Kits DMS CARTRIDGE 000 051 277 PHATNOISE DIGITAL MEDIA PLAYER UNIT 000 057 1 1 1 INTERFACE WIRE LEAD 000 051 592 ZVW 269 300 4mm Bracket...
- Page 4 Golf/GTI 99.5> Digital Media Player Jetta Wagon 01> Supplier: PhatNoise PhatNoise Digital Media Player Installation Kit–Wiring Step#02 Step#01 Remove driver’s side rear compartment cargo Carefully remove trunk liner fasteners and hook (if applicable). attachments along the driver’s side. (Allow enough room to punch holes and install bolts behind the liner material).
- Page 5 Digital Media Player Jetta Wagon 01> Supplier: PhatNoise PhatNoise Digital Media Player Installation Kit–Wiring Step#05 Step#06 Route the interface wire lead behind the liner Route the interface wire lead behind the liner- to where the Phatbox will be installed. Loop back to where the Phatbox will be installed.
- Page 6 Template aligned on suspension raised liner area. Step#07 In Appendix A you will find a full sized template for use in locating the holes to attach the PhatNoise brackets. Carefully position the template, aligning the template horizontally and vertically. Attention! See Step #08 for template alignment considerations.
- Page 7 Golf/GTI 99.5> Digital Media Player Jetta Wagon 01> Supplier: PhatNoise PhatNoise Digital Media Player–Mounting. 10mm Step#10 Step#1 1 The installation brackets are installed on Rear view. Do not torque–material may tear. the trunk liner material in the left rear suspension area. Do not torque–material may tear.
- Page 8 Passat Sedan/Wagon 98> Description: Golf/GTI 99.5> Digital Media Player Jetta Wagon 01> Supplier: PhatNoise PhatNoise Digital Media Player–Mounting. Completed Wagon installation. Step#14 Install the four bracket screws. Replace the liner, trunk carpeting, and access door. Completed sedan/hatchback installation. Page 7 of 15...
-
Page 9: Installation Instructions
Description Digital Media Player Installation Instructions– Set-up and testing Part Number 000 057 1 10 Description Application Fitment New Beetle Sedan 98>03.5 Supplier PhatNoise™ / Votex GmbH Revision 1 Published date: 06-23-03 Page 8 of 15... - Page 10 You will only need to configure the PhatBox again if: • The firmware is reprogrammed. • The PhatBox loses power, e.g. PhatNoise interface cable becomes unplugged, or car battery loses power. 7. Appendix B of this installation guide contains some troubleshooting tips. You may also consult the “Appendix B”...
- Page 11 Jetta Wagon 01> Supplier: PhatNoise PhatNoise Digital Media Player–Set-up and testing. Starting the PhatBox The PhatBox is available through the CD mode of the radio. The unit powers on and off automatically, and resumes where you last left playback. To begin playback: 1.
-
Page 12: Appendix A.-Bracket Template
Appendix A.–Bracket template. 1 3/4” 1 3/4” Bracket Template 8 1/2” Printer settings vary by computer. Please check your measurements before use. 1 3/4” 1 3/4” Page 1 1 of 15... -
Page 13: Appendix B-Troubleshooting
1 5 seconds, then turns off...this cycle repeats continuously. File(s) on your cartridge may be corrupt. Run the PhatNoise DMS Doctor on your computer and follow the recommendations. The green light blinks at You have updated the firmware on the DMS cartridge and the a steady rate for longer PhatBox is reprogramming itself. - Page 14 Digital Media Player Jetta Wagon 01> Supplier: PhatNoise Appendix B–Troubleshooting Note: Check “Appendix B” in PhatNoise Owner’s Manual for more troubleshooting information. General Cases: Problem Cause/Solution No Sound. - Adjust the volume of the head unit. - Make sure the PhatBox cable is correctly connected to the head unit.
- Page 15 Digital Media Player Jetta Wagon 01> Supplier: PhatNoise Appendix B–Troubleshooting Note: Check “Appendix B” in PhatNoise Owner’s Manual for additional troubleshooting information. Problem Cause/Solution WMA files are not playing Some software such as Windows Media Player features copy in the PhatBox protection in their WMA encoding tools.
-
Page 16: Appendix C-Phatbox User's Quick Reference
000 057 1 10 Fitments: Passat Sedan/Wagon 98> Description: Golf/GTI 99.5> Digital Media Player Jetta Wagon 01> Supplier: PhatNoise Appendix C–PhatBox user’s quick reference Current Mode Current Track/Item Random Start Digital Media Player New Beetle with cassette player Backward Seek...
