CONTENTS IMPORTANT WARNINGS ........3 1. THE PRODUCT ........3 2. APPLICATION ........3 3. TECHNICAL DESCRIPTION OF THE PRODUCT ........3 4. SAFETY PRECAUTIONS ........4 5. STORAGE AND TRANSPORT ........4 6. SPECIFICATIONS ........5 7. OPERATING PRINCIPLE ........ -
Page 3: Important Warnings
Dear Customer, thank you for purchasing the ATW-MINI Heat Pump. We believe you will be satisfied with this product and that this product will bring comfort into your home. As this product is a complex appliance, pay high attention to this User Guide. This guide will make you completely familiar with the product application, placing, construction and will provide you with other necessary information. -
Page 4: Safety Precautions
• Maximum humidity 90% The outdoor unit must be stored and transported in vertical position and in the original box. If necessary, protect the fragile parts (e.g. exchanger). ATW-MINI indoor unit: • Dust/free, non-agressive environment • Temperature +5°C to +45°C... -
Page 5: Specifications
6. SPECIFICATIONS Comfort High Power Series Mini Mini Mini Mini Mini Mini Mini Mini Type 11 HP 14 HP 16 HP 11,1 11,2 Heating capacity 1,22 2,67 4,05 2,55 3,22 3,72 Input power +7°C / +35°C floor heating 4,15 3,95 4,35 4,06 11,2... -
Page 6: Operating Principle
DIMENSIONS 7. OPERATING PRINCIPLE The heat pump appliance is used to acquire low-temperature energy from the selected source and its transfer to higher temperature level. The air to water heat pump extracts heat from the ambient air. The core of the heat pump serves as an efficient compressor through which the refrigerant is compressed and then expanded in a hermetically closed circuit. -
Page 7: Installation And Positioning
8. INSTALLATION AND POSITIONING The installation must be performed by a professional company authorized by the manufacturer. Do not install the appliance by yourself. The appliance might get damaged and people injured. It is possible to suspend the indoor unit on the wall. It has to be placed in the room in a way that enables the access for service and maintenance (see the illustration under). -
Page 8: Connection Of Regfrigerant Circuit
9. CONNECTION OF THE REFRIGERANT CIRCUIT The heat pump refrigerant circuit connection must be performed by an authorized installation company or a company certified or trained in air-conditioning and refrigeration services. Do not connect the refrigerant circuit by yourself. There is a serious danger of injury from refrigerant. - Page 9 10.2. SETTINGS The Settings menu is divided into two rows of icons. The top row icons are used for the control of the UTI-INV module (mode, equitherm regulation, HDW etc.), the bottom row icons are used to set the UTI-IQCP control panel (language, time, network connection etc.).
- Page 10 10.2.2 Parameters settings The menu with a number of parameters that can be viewed, and modified, if necessary. The current value of the parameter is displayed. If the parameter is user-editable, a box labelled „New” is displayed. Parameters in view mode: Moving up and down Current value between parameters...
- Page 11 10.2.3 Temperature List of other temperature sensors that are not shown on the main screen. The exchanger temperature and the required temperature are displayed. The E, F and G sensors are displyed - these values are only informative and do not affect the regulation.
- Page 12 10.2.6 Language setting The UTI-IQCP control panel offers three language versions. When you select the language, the user interface will switch to that language. By pressing the Back button, the setting will be saved and the screen will return to the Settings menu.
- Page 13 10.2.9 Network setting It is possible to set the IP address, subnet mask and gateway of the network so that the devices can be connected to the network. If the installation permits, it is possible to activate the DHCP server. DHCP deactivated: DHCP activated: Note: If you don’t know what value to set, do not make any changes, or connect the panel to the network.
- Page 14 10.2.11 Factory settings If the panel is not responding, or you have made a setting that led to a non-standard function, it is possible revert the panel to its factory settings: 1. Press the button on the panel for more than 10 seconds. (Note: the button may not be accessible when the panel is installed in a unit.) 2.
- Page 15 The settings menu is divided into two rows of icons. The top row icons are used for the control of the UTI-INV module (mode, equitherm regulation, HDW etc.), the bottom row icons are used to set the UTI-IQCP control panel (language, time, network connection etc.).
-
Page 16: Maintenance
11. MAINTENANCE Due to its design the heat pump is very easy to maintain. Basic maintenance is performed by the servicing organization once a year. During this regular maintenance, all important elements of the heat pump are checked. Special attention is paid to the correct volume of refrigerant in the circuit and a proper operation of the refrigerant circuit. -
Page 17: Refrigerant Circuit
REFRIGERANT CIRCUIT Models: High Power Outdoor unit Indoor unit Flow sensor Filter Control valve Heating 4-way Pressure sensor water valve sensor Accumulator Exchanger Heating emitter Injection expansion valve Plate heat exchanger Solenoid valve Filter Compressor with injection port Circulation Injection pump Expansion valve circuit... -
Page 18: Dimensions
WIRING Outdoor unit terminal Terminal XL XN XC Power supply 4x 1,5 Cu mm Connecting cable Outdoor unit ETS sensors: A - exchanger C - heating water H - outdoor (or B indoor) air Circulation pump light blue light blue brown brown brown...
