Summary of Contents for DFx Technology InnEnergy
- Page 1 Finalist 2008 ® InnEnergy Instruction Manual www.dfxtech.co.uk/energy...
-
Page 2: Table Of Contents
Index 1. Welcome…………………………………………………………………..…... InnEnergy Schematic................2. Important Information………...………………………………………..…..3. Specifications…………………………………………………………..……... 4. Key Benefits…………………………………………………………..………. 4.1 InnEnergy ® Device Features........... 4.2 Information Displayed............... 5. How it works……………………………………………………………….…. 5.1 Teach/Learn Cycle..............5.2 Optimisation Mode..............5.3 Normal Operation..............5.4 Power Interrupt (Teach Mode/ Normal Operation).... -
Page 3: Welcome
15.2 Blank Table…………………………......... 1. Welcome! Hello! Thank you and congratulations for purchasing your new InnEnergy ® energy saving device! In just a few moments you will be ready to reduce your carbon foot- print and your energy bills by up to 35%. Individual savings do vary, so to maximise your energy savings please read these instructions carefully before installing the device.Don’t forget to check out our latest energy saving devices (including 2eRT) -
Page 4: Important Information
The maximum output current is 13A. The InnEnergy® device is suitable for indoor use only. To prevent fire or shock hazard, do not expose the InnEnergy® device to rain or moisture. To avoid electrical shock do not open the device. -
Page 5: Information Displayed
Energy saved since installation or selected time period 5. How it works The InnEnergy® device optimises your energy savings using a three-stage proc- ess. First, the InnEnergy® device ‘learns’, then it ‘optimises’ and finally it enters the ‘Normal Operation’ mode. 5.1 Teach/Learn Cycle When first installed, the InnEnergy®... -
Page 6: Optimisation Mode
Should the power supply to the InnEnergy® device be interrupted for more than 3 hours whilst the InnEnergy® device is in ‘Teach Mode’, the ‘Teach Mode’ will fail and the process will be automatically restarted. ‘Power Interrupt’ will be briefly displayed on the screen. -
Page 7: Energy Monitoring/Saving Features
Python Refresh: With this function enabled, even if the cooler has been turned off by the InnEnergy® device to save energy, the cooler will be periodically switched on to allow for the recirculation of cooling water in the python. See section 11. for more details of how to use this feature. -
Page 8: Voltage/Current Meter
(button 4) the Power Factor (PF) is displayed. By pressing on the ‘VA’ button (but- ton 5) the true power that is currently being measured by the InnEnergy® device is displayed. When the true power is displayed, the ‘VA’ button changes into the ‘W’... - Page 9 The InnEnergy® device allows different trading hours to be set for each day of the week (7 days). So, for example, if the establishment opens between 11:00 – 23:00 on a Monday, but between 11:00 –...
- Page 10 (button 4) to display the ‘Trading Hours’ data input screen. Trading hours are programmed into the InnEnergy® device according to day. To select the day for which trading hours need to be set press the DAY button (button 3) until the name of the correct day is displayed in the middle of the screen.
- Page 11 Opening and closing hours should be set in chronological order. The table found in section 15.2 may be useful when programming trading hours into the InnEnergy® device. An example of how the table may be used is also shown. Please Note: If your establishment’s trading hours are likely to fluctuate slightly it is advisable to adjust the trading times to accommodate this.
-
Page 12: Reset
ING: Resetting the InnEnergy® device removes ALL savings history/electricity costs and ‘Python Refersh’/ ’Daylight Saving’ settings. Custom trading hours will not be re-set. The InnEnergy® device will need to be re-programmed with clock settings/electricity costs and ‘Python Refersh’/’Daylight Saving’ settings etc.. 8. Leap Year/Daylight Saving The InnEnergy®... -
Page 13: Programming (Date/Time/Trading Hours/Electricity Cost)
10. Line Cleaning Mode In ‘Line Clean Mode’, the InnEnergy® device will switch off the cooler for 2 hours to allow cleaning (or until this mode is cancelled by the user). After this, normal operation will continue. -
Page 14: Trading Hours Set
Check to make sure that you have programmed the trading hours correctly. Failing this, make sure that the InnEnergy® device is not in ‘Line Clean Mode’ and does not have the ‘Override’ function enabled, as there functions will override any trad- ing hours that have been programmed. - Page 16 ® InnEnergy Instruction Manual DFx Technology Ltd., Unit 8B Witan Park, Avenue Two, Station Lane, Witney, Oxfordshire, OX28 4FH Tel: 01993 705151 Fax: 01993 705551 www.dfxtech.co.uk/cooler 660-021-02...
