Climax CL-DR-GSM Installation Manual

1

1. Screw holes

2. Antenna
3. SMA connector
4. Address/mode selector switch
5. Input connector
6. Output connector
7. Channel LED
8. RS-485 jack
9. Status LEDs
10. RS-232 jack
11. Rail moun ng clips
12. Power input jack
13. Control bu on

14. Voice pins

1
14
13
12
11

Change Module Address

The module address can be set from 0 to 31 by means of a dip switch called "address/mode selector
switch". Before changing module address the main power must be disconnected. The address must
be defined in binary. For instance to set address "21", the dip switch must be as below:
Never set the address "0" and "1" as "0" is not valid in C-Bus protocol and "1" is always
dedicated for GatewayPro module.
Check all C-Bus module addresses to avoid repe

Switching between Direct Mode and Network Mode

To set the module in direct mode slip bu on #7 to "up" posi on or slide it "down" to set the module
in network mode.
ON ON
1 2 3 4 5 6 7 1 2 3 4 5 6 7
3
ve address alloca on.
4
INSTALLATION GUIDE
2
3
4
5
6
1
Input Voltage
Input Current
I/O Connec ons
1
7
8
9
Antenna Type
10
3
1 2
version 1.0.1
GSM Modem
(CL-DR-GSM)
18V-24V DC (24V DC is recommended)
100mA (for 24V DC)
C-Bus 2 X RJ45
RS-232
1 X RJ45
(Direct Mode)
1 X relay channel-8A per channel (rising-cage 5mm screw terminals)
Output
Audio output
1 X digital dry contact input (rising-cage 5mm screw terminals)
Input
Audio input
1 X 4dBi detachable omni-direc onal (RP-SMA)
1

Rail Mounting

GSM Modem is designed to be installed
wide DIN rail (EN 50022, BS 5584).
Hook the module from the top, pull down the r
clips, push the module to the rail and release the r ail
moun ng clips.

Screw Mounting

Screw the module to any surface through 4 corner screw
holes.
2
on a standard 35 mm
ail moun ng
