WellionVet Gluco Calea Owner's Manual

Hide thumbs Also See for Gluco Calea:
Table of Contents

Advertisement

Quick Links

OWNERS GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gluco Calea and is the answer not in the manual?

Questions and answers

Related Manuals for WellionVet Gluco Calea

Summary of Contents for WellionVet Gluco Calea

  • Page 1 OWNERS GUIDE...
  • Page 3 Dear WellionVet GLUCO CALEA Owner, Thank you for choosing the WellionVet GLUCO CALEA Blood Glucose Monitor System that will help you moni- toring the blood sugar levels of your pet. We designed the WellionVet GLUCO CALEA Blood Glucose Monitoring System to be accurate and easy to use.
  • Page 4 But this is not the same value as it would be for your cat, dog or horse - to receive an accurate value for your pet you must use a blood glucose meter developed especially for animals. Your WellionVet GLUCO CALEA meter is calibrated especially for the blood of cats, dogs and horses.
  • Page 5 Testing your pet‘s blood glucose at home will help to improve the diabetes therapy. WellionVet GLUCO CALEA Human meter pet meter Human accurate blood glucose result precise can show a false, low result blood glucose result when coded for cat...
  • Page 6 When your pet is relaxed and able to follow its routine, the measured blood glucose results will be more accurate. Your veterinarian can use the consistent data of the measurements at home together with the measurements in the vet clinic to optimise the treatment of your pet.
  • Page 7 WELLIONVET GLUCO CALEA BLOOD GLUCOSE KIT The WellionVet GLUCO CALEA Blood Glucose Monitoring System kit includes the following items: WellionVet GLUCO CALEA blood glucose meter Wellion Lancing device 10 Wellion Lancets Compact Pouch User guide WellionVet GLUCO CALEA test strips can be purchased separately.
  • Page 8 The WellionVet GLUCO CALEA meter Test Strip Port Insert test strip to turn on the meter. Light button Strip Ejection Press the button to button turn on the back- To eject the light. used strip slide/move the button Display Shows...
  • Page 9 The WellionVet GLUCO CALEA meter display Date MEM symbol Time Code symbol Shown while Appears with scrolling the code of the through test strips used. memory mode Warning symbol Alarm Clock Indicates that Icon glucose Indicates that result is out of...
  • Page 10 The little window allows you to check if there is enough blood sipped into the test strip. The WellionVet GLUCO CALEA Test Strips are glucose specific, biosensor-based test strips that can test glucose in capillary whole blood of animals (cats, dogs and horses) in only a few seconds and require a very little blood sample.
  • Page 11 IMPORTANT: Be sure to use only the WellionVet GLUCO CALEA Blood Glucose Test Strip with the WellionVet GLUCO CALEA Blood Glucose Meter. The WellionVet GLUCO CALEA Blood Glucose Test Strips are sensitive to moisture and light, it is important to close the vial cap of the test strip bottle tightly after every use.

  • Page 12: Coding The Meter

    WellionVet GLUCO CALEA test strip to start with the measure- ment. PERFORMING A BLOOD GLUCOSE TEST Take a WellionVet GLUCO CALEA Test Strip out from the test strip bottle and close the bottle immediately. Insert the WellionVet GLUCO CALEA test strip into the strip port.
  • Page 13 Approach the test strip to the blood drop and touch it in a right angle. Blood is automatically drawn into the test strip. Let the test strip sip in blood until the white circle in the control window is surrounded with blood - see illustration.
  • Page 14 IMPORTANT: Check the expiration date printed on the test strip bottle and its package. Do not use expired test strips. Use each test strip immediately after removing it from the bottle. Do not use wet or damaged test strips. Keep away from direct sunlight and heat. Store the test strip bottle in a dry, cool place.
  • Page 15 Sometimes it is useful to puncture twice very nearby to form one blood drop out of the punctures. It is important to motivate the animals by means of positive reinforcement like: Perform the blood glucose testing under calm and relaxed conditions Feed a “Goodie”...
  • Page 16 VIEWING THE METER MEMORY Press the M button once to turn on the WellionVet GLUCO CALEA meter. Date and time will appear first. By pressing the S button the meter will show “7-day-average”, “14-day-average”, and “30-day-average” and then continue with the most recent test result. If it has 14-day average result, it will show under the screen at the same time.

  • Page 17: Changing The Battery

    SETTING YOUR WELLIONVET GLUCO CALEA METER Changing the Battery Remove the battery cover and insert new battery according to the direction found on inside the battery compartment. Slide the battery cover back into place. Current date and time information will be memorised by the meter for approximately 1 minute.

  • Page 18: Setting The Alarm

    Setting the alarm Press the M button to set Alarm No 1. Press the S button to change the hour, to confirm your setting press the M button. Then press the S button to change the minutes, to confirm your choice press the M button. To move on to set Alarm No 2 press again the M button.

  • Page 19: Cleaning The Meter

    CARE OF THE METER Taking care for your WellionVet GLUCO CALEA Meter is easy. Follow these simple guidelines to keep your meter working properly. Cleaning the Meter cloth dampened with a mild detergent. Meter. Never immerse the meter or hold it under running...

  • Page 21: Display Messages

    DISPLAY MESSAGES Display What it means What to do Meter is ready to make Apply blood sample a measurement to test strip Test result is higher Wash and dry the than 600 mg/dL puncture site and (33,3 mmol/L) repeat the test using a new test strip.
  • Page 22 Battery is low, meter Change the battery will allow about 50 more measurements Battery is too low for further measurements This warning will Insert correct code appear if the meter chip for your pet: has not been encoded. cat = green, dog = blue, horse = red If the Meter display...
  • Page 23 Problem with test strip Try again with new test strip Problem with meter Check the meter again with the Code Chip. If the problem persists, contact Customer Service for help. Problem with coding Compare the code of the meter number on the display with the code number on the test strip vial you are using...

  • Page 24: Specifications

    SPECIFICATIONS Test Strips: WellionVet GLUCO CALEA Blood Glucose Test Strips and WellionVet GLUCO CALEA code chips Test Range: 20-600 mg/dL (1,1 - 33,3 mmol/L) Calibration: Plasma Test Time: 5 seconds Sample Size: 0,5 microliter Hematocrit Range: 35 - 55% Display Type:...
  • Page 25 For additional information, refer to the WellionVet GLUCO CALEA Test Strip insert. SYMBOLS (EXP) Expiration date (use by last day of month) (LOT) Batch Code C ˚ Temperature Limitations C ˚ F ˚ F ˚ Consult Instructions for Use Caution, consult accompanying documents...

  • Page 26: Manufacturer's Warranty

    MANUFACTURER‘S WARRANTY The producer warrants the WellionVet GLUCO CALEA blood glucose meter against defects in materials and workman- ship for a period of two years from the date of purchase. The warranty does not apply if the instrument has been misused, poorly maintained or is tampered with.
  • Page 28 Your AUSTRIAN diabetes brand MED TRUST Handelsges.m.b.H. Gewerbepark 10 7221 Marz AUSTRIA www.medtrust.at wwww.wellion.at...
