MODEL LF755KB
4 PORT RS422 PCI EXPRESS
SMPTE INTERFACE
(LOW / STANDARD HEIGHT)
SERIAL I/O CARD
INSTALLATION
MANUAL
HIGH-PERFORMANCE UART FAMILY
This document describes the installation and use of the
Axxon Computer Corporation 4 Port RS422 SMPTE Interface PCI Express (PCIe) Bus
Adapter.
Release Version 1.0 (11 March 2008)
Advertisement
Table of Contents
Summary of Contents for Axxon LF755KB
- Page 1 (LOW / STANDARD HEIGHT) SERIAL I/O CARD INSTALLATION MANUAL HIGH-PERFORMANCE UART FAMILY This document describes the installation and use of the Axxon Computer Corporation 4 Port RS422 SMPTE Interface PCI Express (PCIe) Bus Adapter. Release Version 1.0 (11 March 2008)
-
Page 2: Table Of Contents
V1.0 1 INTRODUCTION Thank you for choosing the Axxon line of high performance I/O cards. Please take a few moments to read through this documentation. Device drivers and utilities for this Axxon MAP/950 product are supplied for functionality under Windows 9x, ME, XP (32/64 bit), NT4, 2000, 2003, Vista (32/64 bit), Linux (32/64 bit), OS/2, QNX , SCO Unix operating systems. -
Page 3: Overview And Installation
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 4 OVERVIEW and INSTALLATION 4.1 PCI Express (PCIe) 4 Port RS422 SMPTE Interface I/O Card Overview Axxon manufactures a variety of serial port products based on the enhanced Oxford Semiconductor 16C950 UART. - Page 4 MAP/950 product. Design Details Axxon is the first and leading manufacturer of PCI Express I/O adapter cards. This design is based on a very mature product foundation of volume shipments to key OEMs worldwide and over 3 years of PCIe design experience.
- Page 5 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 PLX PCIe Bridge controller PEX8111-BB http://www.plxtech.com Oxford OXCB950 Enhanced PCI Uart http://www.oxsemi.com HD44 Female Connector Details Tyco part # 5748482-5 (RoHS & Pb-free) has been applied as the HD44 Female connector in this product design.
- Page 6 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 RS422 SMPTE DB9 Female Pinout Master Mode (DTE / Master / Controller) (GREEN Led is lit) Pin_2 = RX- Pin_3 = TX+...
- Page 7 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Mode Configuration This adapter card is software configurable to either MASTER (DTE) or SLAVE (DCE) modes of operation. The current configuration software is provided in a DOS coded program and available through a no-charge ISO download.
-
Page 8: Port Rs422 Pci Expres I/O Card
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 The options available through the configuration program are copied below. LF755KB SMPTE 4 Port RS422 PCI Express I/O Card EE Configurator for DOS v0.2 ============================================================================ (c) 2008, Axxon (OEM) <<... - Page 9 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Windows Device Drivers for Model # LF755KB RS422 SMPTE PCI Express (PCIe) I/O Card A variety of device driver options are available for this flexible adapter card.
- Page 10 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Typical Ports Environment for a 4 Port PCIe SMPTE Installation with Oxford Device Drivers (example only) COM5 : P1, COM6 : P2, COM7 : P3, COM8 : P4 Timing Background The serial ports found on the IBM personal computer have historical evolved around a clock source of 1.8432 MHZ...
- Page 11 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Driver Removal Procedure Please review this document on how to remove a device driver from the Oxford serial port drivers your system: http://www.softio.com/oxan22.pdf...
- Page 12 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 To configure the clock source when using the Oxford enhanced device drivers please review the following GUI property sheet: 1) Select the DATA RATE tab.
- Page 13 Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Quad Speed The Quad Speed option will force any host application software’s baud rate to be multiplied by a factor of 4 (Four).
-
Page 14: Windows Nt4 Driver For Map/950
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 4.1.2 Windows NT4 driver for MAP/950 Overview The Windows NT4 driver creates a Device Object for each port, and registers this with the operating system. The serial port driver enables the following 16C95x features: •... -
Page 15: Using The Serial Driver
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 5 USING THE SERIAL DRIVER The serial drivers for Windows make use of a number of enhanced 95x UART features, and are highly configurable. -
Page 16: Linux Configuration
# of serial ports to be larger than the default value of 4. The Grub loader may be used to expand this value at boot time. Please contact Axxon technical support for assistance if the adapter card is not PnP supported for your Linux distribution. -
Page 17: Technical Details Of Hardware And Software Design
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 6.0 Technical Details of Hardware and Software Design This part of the documentation will discuss the low level hardware and software design for developers interested in creating their own software interface to configure this adapter card. -
Page 18: Non-Volatile Mode Configuration
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Using the above details, here are a few examples on using DOS DEBUG to manually configure a Port mode. DEBUG <ENTER> -o B404 0a ; configure Port 2 and 1 to SLAVE (DCE) mode since the MIO registers are ‘00’... -
Page 19: Contact Information
Installation Guide for Axxon LF755KB PCI Express (PCIe) 4 Port RS422 SMPTE I/O Card (Low/Standard Height Mounting) V1.0 Development Suggestions 1) Do review the Oxford OXCB950 UART documentation available through Axxon and also the following website: http://www.oxsemi.com 2) Do note the EEPROM write delays required for a valid save. That is, methods including nested loops for delays can be critical and cause an invalid write value to be saved as the host CPU system is ran at higher speeds.
