Summary of Contents for Ultracker UN6504E

  • Page 1 INSIDE THE Instruction Manual Product Overview HDD Installation Basic Operations Main Menu Network Access WEB UI Operations Mobile Connectivity Specifications...
  • Page 2: Warning

    Introduction: This manual is for the users who attempt to use H.264 Network Video Recorder (NVR). It expresses installation guide, connecting to peripherals, and GUI operations. Please familiarize yourself with the contents in this manual before using the NVR. Make sure that you have referred to an expert when operating the outer case for repair or installing HDD.
  • Page 3: Table Of Contents

    : ............................2 ARNING PRODUCT OVERVIEW .........................5 Package contents ..........................5 Front Panel ............................5 Rear Panel ............................5 HDD INSTALLATION ..........................6 HDD new installation ........................6 Replacing the Hard drive.........................8 BASIC OPERATIONS .......................... 10 Display Screen ..........................10 Display Mode ..........................11 Flexible Camera Assignment ......................11 Flexible Camera Assignment ......................11 Playback ............................12 Event List ............................14...
  • Page 4 ............................45 NSTALLING ............................45 DDING DEVICE .............................46 .............................. 47 LAYBACK ANDROID VERSION .......................... 49 ............................49 NSTALLING ............................49 DDING DEVICE .............................50 ..............................50 LAYBACK SPECIFICATIONS ..........................52 APPENDIX: NVR AND CAMERA CONNECTION................... 53 PORT ..............................53 LAN 1~ LAN 4:.............................53 :............................53 PORT CONNECTION TYPE........................... 54 :..........................54 CONNECTION TCP/IP C...
  • Page 5: Product Overview

    Product Overview Package contents USB mouse Power adaptor Screws pack Product CD Quick Connection Guide *The actual items maybe different from the picture shown Front Panel LED indicator Front USB ports (2): For USB mouse control/ USB backup/ Firmware update Rear Panel Power: DC12V LAN: RJ-45...
  • Page 6: Hdd Installation

    HDD Installation HDD new installation Step 1: Remove the Screws from the rear panel and side panel of the housing. Step 2: Gently slide the cover away from the rear panel and lift it. Step 3: Carefully place the HDD at the upper right side and slide it to plug into the connector properly. HDD Connector...
  • Page 7 Step 4: With your hand supporting the HDD and turn the unit upside down and secure the HDD from the bottom of case with 4 screws. Step 5: Screw the cover back, replacing the screws on the side panel(x4) and rear panel(x1). NOTE: The new HDD must be formatted in order to work properly in system.
  • Page 8: Replacing The Hard Drive

    Replacing the Hard drive Make sure the NVR power is off and power cable has been disconnected before changing the hard drive. Step 1: Remove the screws from the rear panel and side panels of the housing. Step 2: Gently slide the cover away from the rear panel and lift off. Step 3: With your hand supporting the HDD when turn unit upside down, remove 4 screws from the bottom of case.
  • Page 9 Step 4: Gently slide the hard drive from the connector properly. HDD Connector Step 5: Install new HDD. Step 6: Screw the cover back on the side panel (x4) and rear panel (x1). NOTE: After replacing the HDD, the new HDD must be formatted in order to work properly in system. To connect cameras to NVR, please refer to Appendix: NVR and camera connection.
  • Page 10: Basic Operations

    Basic Operations Display Screen 4-Channel 8-Channel HDD Status: displays the percentage of recording space consumed on the hard disk and the size of the installed hard drive. Camera Status: 4/8 channel: displays channels on the system. The red light will flash to indicate recording is in progress.
  • Page 11: Display Mode

    Display Mode Left-click on the icon to open the Split-Screen selector and choose the display mode you want Flexible Camera Assignment You can re-assign the channels to different camera. For example, you can duplicate the video feed from channel 1 onto channel 2. This is useful if you wish to re-arrange the position of each channel.
  • Page 12: Playback

    NOTE: The NVR continues to record the designated channel even if you re-assign camera positions. Playback Click the icon to enter playback mode. The timestamp appears in the bottom-right corner of the screen indicates the playback time.
  • Page 13 Split mode Arrow keys: day/time selector Playback / Pause Event List Show / hide OSD Screenshot Click the numerals to select date / hour / minute / second or frame and adjust them by rolling up and down the mouse. Playback Mark: Click the bar to mark the timing of important video when searching playback data, the orange cursor will be shown in the center of the bar.
  • Page 14: Event List

    Auxiliary Search Cursors: This smart search design allows you to search data quicker and easier, meanwhile, the colorful cursors are helpful to diagnose the happened events. For Example: Below picture shows many events happened, you can click the numerals of data/time/frame and “roll up or down”...
  • Page 15: Event Details

    Click the icon to play / pause the selected events. Click the icon to delete the selected events. Click the icon or right click the mouse to exit and go back to the previous page. Event Filter: To search events by channel or event filters. 1.
  • Page 16: Screenshot Function

    In the column of filter, it will show the filter icons in different colors, you can easily search the events. When the cursor is moved to one of the events, the background will be changed to the beginning of the event. Screenshot Function Format the USB flash drive by NVR before using it for backup video, upgrade firmware or take screenshots.
  • Page 17: Main Menu

    Main Menu If you set “Password Enable” as , the NVR will request at least ID:2, default password 2222 to enter the menu. Click this icon to enter main menu. IP Camera Setup Main Menu →IP cam Setup Select certain IP cam and enter, it can set following items:...
  • Page 18: Connection Settings

    Title The title name of this channel. Click to change by virtual keyboard. Connection Settings Connection Type: Select P2P(direct connection), TCP/IP(IP conncetion) or Disable. Device Address: Set IP address of the connection (For TCP/IP connection) Port: Set port number of the connection (For TCP/IP connection) Username: User name to access camera.
  • Page 19 Saturation: Adjust image saturation. Sharpness: Adjust image Sharpness. Video Orientation: Choose Mirror, Flip, or Mirror + Flip for image. Advanced Setup: Setup AC frequency, Shutter Speed, Digital Gain, Exposure Level, Day / Night Threshold and Day / Night Mode. Image Quality: Adjust RGB gain, and enable / disable AWB and DWDR function. Video: This section offers active bit rate control for user to set different bit-rate for different situations.
  • Page 20: Setup

    Gateway DNS Server Enable DHCP HTTP Port Camera Information This page shows camera information including OS version, S/N, MAC, and IP address. Setup Main Menu Setup Maintenance: the NVR settings can be perfromed with the below 3 types of acti. Load Factory Default: restore all NVR settings to the default Backup Settings (to USB): store the current NVR settings, so it can be applied to another unit of NVR.
  • Page 21: Fan Speed

    Restore Settings (from USB): restore settings based on the stored backup settings Language: The NVR supports 21 version of OSD language: English, Spanish, French, Italian, Russian, Danish, Swedish, Finnish, Czech, Dutch, Deutsch, Polish, Hebrew, T-Chinese, S-Chinese, Japanese, Thai, Vietnamese, Korean, Turkish and Portuguese. Fan Speed: The lower the fan speed, the quieter the fan sound, but the higher the HDD temperature, vice versa.
  • Page 22 User Password (ID:1): User of ID:1 is able to view playback and event list. (Default password: 1111) Operator Password (ID: 2): User of ID:2 is able to enter main menu. (Default password: 2222) Admin Password (ID:3): User of ID:3 is able to manage NVR & LAN password. (Default password:3333) Information: You are able to check the NVR information including software, hardware, start / stop recording...
  • Page 23: Record

    Record Main Menu → Record Video Information: You can choose one of the cameras to see the video size at each hour. Bit rate Information: You can choose one of the cameras to see the bit rate size at each hour. Recording Schedule: You can choose one of the cameras to setup recording schedule.
  • Page 24: Alarm

    HDD Information: You can view internal HDD and external HDD info. in this page. Record Mode External HDD Mode Click to select one of the following: Extended REC: NVR recording data into internal HDD first, when it record to 100%, it’ll record to external HDD.
  • Page 25: Usb Device

    Video loss response time can be set from 0,3,5,10,30, 60,120,180 seconds to infinite. Alarm full screen: Enable: Screen will pop out when alarm/ motion are triggered. Disable: Screen will not pop out when alarm/ motion are triggered. USB Device Main Menu → USB Device To format USB flash drive by the NVR before using it for backup video upgrade OS.
  • Page 26 NOTE : One USB flash drive can save maximum 16 files. Each file is up to 1GB or 30 minutes. Save To Device: Insert USB flash drive into the NVR, it will show “USB Check OK!” on the screen Click “Save to Device” to backup the video to USB flash drive, it will start storing the backup file. The file will be named by Start Time as “Ch_YYYYMMDDhhmmss.mov”...
  • Page 27: Lan

    Format Device: Insert a USB flash drive to format it. WARING: All the data will be deleted once the USB drive is formatted. Firmware Update: Before firmware update process, please be sure to save firmware to USB flash and insert it to NVR.
  • Page 28: Lan Password

    LAN Password: Only the users of “ID: admin”(default password : 3333) are able to manage LAN passwords Click the numerals to set password. User Password (ID: user): User of ID:user is able to view remote live only. (Default password: 1111) Operator Password (ID: operator): User of ID:operator is able to view remote live, playback and backup.
  • Page 29: Network Access

    Network Access System Requirements Description Requirement PC-Intel Pentium 4 3.0GHz or above Mac-Intel Pentium Core Duo, 1.66 GHz or above Windows XP/ Vista/ 7 Operating System Apple OSX 10.5 or above 128 MB RAM Memory 16 MB of video memory Video 10/100 Base T Network Network (LAN)
  • Page 30 NVR: 192.168.0.90) Discovering devices by search tool The discovery tool is provided for searching Ultracker network video devices in a network. When NVR device is correctly installed in a network, it can be searched by the tool. The steps of applying this search tool are as below.
  • Page 31 Step 2: Check the box to select a camera device from the list. The following operations will be applied on it. Step 3: The selected NVR may have been assigned a valid IP address via DHCP server. It can also be manually given an IP address.
  • Page 32 Right-click on the device and select “Properties”, the pop-up window shows all the information related to the device, including the web access info. Use the web address to connect to the NVR. Or simply double-click on the selected device, which gets immediately access to the NVR webpage.
  • Page 33 NOTE: If there is not any prompt message or ActiveX cannot be installed at all, please follow the steps below to change the IE security level and settings. 1. Click “Internet Option” in the “Tools” menu of IE. 2. Select the “Security” Tab and click “Site” button for Trusted Sites.
  • Page 34 3. Input the IP address of the NVR, uncheck “Require server verification (https:) for all sites in this zone”, click Add, and click “Close”. 4. Set the Security Level to “Low”, and click “Apply”. 5. Log in the NVR by IE browser and install. Click “Yes” to enable ActiveX control.
  • Page 35 Enter ID and Password to login. The IE browser can then display the web UI of the NVR and the live video of the managed cameras as below.
  • Page 36: Web Ui Operations

    Web UI Operations Live Viewing Click this button for live mode. Click this button to view in single channel Click this button to view in Quad mode Click this button to view in 9-split mode. Drag & Drop (or tick/untick) the selected camera from the list to the viewer channel. View in video image as1600*1200.
  • Page 37 View in video image as 640*400. Switch automatically to HD or SD resolution when viewing in shingle channel or multi channel mode respectively. Press this button to capture current live image. Press this button to record image to PC. Press this button to digital zoom in single channel. Press this button to enlarge image to full screen, press keyboard “Esc”...
  • Page 38: Playback

    Playback Click this button for playback mode. Playback mode by Date/Time Playback model by event Click this button for remote backup NOTE: Only operator and admin are able to enter playback mode Playback by Date/Time: Select the channel you would like to playback Click to open a pop-up calendar to select the date and time.
  • Page 39 Click to control playback rewind, pause, play and fast-forward.
  • Page 40 Playback by Event: You can search events by “Motion” “Sensor’ and “All” Or click to open a pop-up calendar to select the date and time. Press this button to search event list Backup: Select a time period that will be exported as a video footage. 1.
  • Page 41: Setup

    Setup Click this button for full remote setup mode Press this button for following setting: Press this button for following setting Press this button for following setting:...
  • Page 42 Press this button for following setting: Press this button for following setting: Press this button for IP, E-mail, PPPoE, DDNS setting:...
  • Page 43 Press this button for following setting: Press this button for following setting: Press this button for following setting:...
  • Page 44: Log

    Click this button for log mode. Press this button for system info. Press this button for network info. Press this button for online user info.
  • Page 45: Mobile Connectivity

    Mobile Connectivity You can remotely view camera streams from your NVR on your iPhone™, iPad, Android Devices. Compatible Mobile Viewing Devices iOS Devices Android Devices. iOS version Installing Search “MobileViewHD2” on APP store and click the Install button to install the software.
  • Page 46: Live View

    Input the following items to add the device. NAME: The name of this device. IP / DDNS: The IP address or DDNS domain name of the NVR. Port: The port number of the NVR. (Default port number is 80) Account: The user name to log into the NVR. (Default user is “admin”) Password: The password to log into the NVR.
  • Page 47: Playback

    Click to select device. Slide on the screen to go to the next / previous channel. Click to view all 8 channels at the same time. Click to jump to certain channel. Playback Click to view recorded video.
  • Page 48 Click to select device. Click on the displayed time to show the calendar. Select date on the calendar, and slide the time bar or adjust the clock to select time. Click to start playback. Use the control buttons to play recorded viedeo. : Play : Pause : FF...
  • Page 49: Android Version

    Android version Installing Search “MobileViewHD2” on APP store and click the Install button to install the software. After finishing installation, the APP icon will appear on your iOS device. Adding device For the first time to use MobileViewHD, click to enter the device list. Click the on the upper right and a page for inputting NVR information would appear.
  • Page 50: Live View

    To delete the device, long press on the device list to show the Delete Item options. Live View After the device is successfully added, click the button to view the channels of the NVR. Click to select device. Slide on the screen to go to the next / previous channel. Click to view all 8 channels at the same time.
  • Page 51 Click to select device. Click on the displayed time to show the calendar. Select date on the calendar, and slide the time bar or adjust the clock to select time. Click to start playback. Use the control buttons to play recorded viedeo. : Play : Pause : FF...
  • Page 52: Specifications

    Specifications SYSTEM PLAYBACK Operating System Linux (embedded) Channels Max. 8Ch Simultaneous View, Record, Playback, Single Frame, Forward / Rewind Pentaplex Playback Speed Backup & Remote Monitoring (x5, x15, x60) Number of Channels 4 + 4 Channels Search By time or event INPUTS / OUTPUTS Log Search Yes (max.
  • Page 53: Appendix: Nvr And Camera Connection

    Appendix: NVR and camera connection Port There are 2 ways for the NVR to connect IP cameras. One is direct POE connection from LAN 1~LAN4. The other is network connection from the LAN port. LAN 1~ LAN 4: 24V POE power supply. Connect to camera directly.
  • Page 54: Connection Type

    Connection Type There are 2 types of connection for NVR to connect the cameras: P2P and TCP/IP. It can be set in the “Connection Settings” from “Camera” in the main menu or the “Camera List” button in the bottom. P2P connection: No need to set IP connection settings.
  • Page 55: Channel 1~4

    Channel 1~4: Directly connect to LAN 1~LAN 4. While using P2P connection, the channel will connect to the camera on certain number of LAN. (Channel 1 to LAN 1, channel 2 to LAN2…etc.) While using TCP/IP connection, the channel will connect to certain camera in the network following the IP setting.
  • Page 56: Nvr With 8 Cameras (P2P)

    NVR with 8 cameras (P2P) In the case of NVR with 8 cameras, use LAN 1~4 to connect 4 cameras, and use a switch/router to connect the other 4 cameras through LAN port. Connect 4 cameras to LAN 1~4. Plug power to the other 4 cameras and connect them to a switch/router. Connect NVR to the switch/router.
  • Page 57: Nvr With 8 Cameras (P2P + Tcp/Ip)

    NVR with 8 cameras (P2P + TCP/IP) In the case of over 4 cameras are in the network, and the user wants to assign certain 4 cameras to the NVR, use P2P connection for the 4 cameras on LAN 1~4, and TCP/IP connection for the other 4 cameras in the network.
