- Page 1 GSM/GPS ALARM CAT-1X ’ USER S GUIDE RACKING Multi-application Satellite Tracking Wireless Sensor Connection...
-
Page 2: Table Of Contents
2.4 Transmitter Operation ..........................6 2.5 How to configure device (Configuration) ....................7 2.6 I/O Introduction and Definition ......................9 2.7How to insert Simcard to Cat-1X ......................10 3. Functions and Operation: ........................10 3.1 Arm/Disarm ............................11 3.2 Alarm Alert functions .......................... 11 ... -
Page 3: 1-Introduction
1-Introduction: CAT-1X is a GSM/GPRS/GPS alarm tracking box for multi applications. This small unit is equipped with Quad Bands GSM/GPRS module, Hi-sensitivity GPS receiver and 3D Accelerometer. It’s also can be connected with optional wireless/wired accessories like PIR senor, Doppler... -
Page 4: Typical Application
Motor Homes • Boats & Yacht 1.4-Package Contents: 1.4.1Standard Package Contents CAT-1X GPS Alarm Tracker x 1PC GSM Antenna x 1PC GPS Antenna x 1PC 14Pin Power+I/O Wire harness x 1PC Panic Button x 1PC Engine Cut-off Relay x 1PC Microphone x 1PC 1.4.2 Optional Accessories... -
Page 5: 2-Knowlege Before Usage
2-Knowlege Before Usage: 2.1- How it works? The CAT-1X mainframe works as a host box with multi input/outputs. The mainframe will process to get GPS location and various working status from inputs and wireless sensors, and then send those information to preset Phone Numbers or IP/Port Server via GSM network. -
Page 6: Power Supply
2.3 Power Supply 2.3.1 External Power and Internal Power CAT-1X works with two power supply mode: External Power and Internal Battery. It's working normally with external power supply range from 9-36V DC. When the external power is disconnected or with low voltage output, device will switch to work on internal battery automatically. And it also will send"... -
Page 7: How To Configure Device (Configuration)
For other wireless sensor, like Door/window contact, Smoke and gas detectors follow the same process to integrate them to system.\ 2.5 How to configure device (Configuration) Cat-1X box support configuration via SMS commands and also via PC program tool(Configurator) via connect Cat-1X with PC through USB cable. 2.5.1 Configure by SMS commands:... - Page 8 2.5.2 Configure by PC tool “ Configurator”: 1. Connect Cat-1X with PC via USB cable: 2.Install CP2102 USB-Serial Driver: 8 / 20...
-
Page 9: I/O Introduction And Definition
3. Run Cat-1X configurator.exe and get into following interface: 2.6 I/O Introduction and Definition 1. Main I/O ports Introduction: 9 / 20... -
Page 10: How To Insert Simcard To Cat-1X
Door Status( =0V: Open) Digtal Input Orange/White Panic Button(=0V:effective) Blue/White ShortCall(=0V, Effective) Black/White LED - Arm/Disarm Status LED Yellow/White LED + Orange Mic+ Microphone Balck/White Mic- Green/White Speaker + 3W Speaker Black/White Speaker - 2.7How to insert Simcard to Cat-1X 10 / 20... -
Page 11: Functions And Operation
If in Armed status, the system was disarmed, and get no Door open or Ignition status operation within 60Seconds, system will automatic arm once. Cat-1X system allow user to enable/disarm Re-arm function according user’s usage habit. Re-Arm function Enable/Disarm Method:... -
Page 12: Remote Stop Oil/Power Supply For Engine (Immobilizer)
In Armed status, the system will keep Oil/Power supply in locked status. This is to protect burglar ignore alarm alerts and start vehicle to drive away. This function is default as Disabled. If the user want to activate this function, can use SMS command sent CAT-1X inserted SIMCARD number to switch on and off this feature. -
Page 13: Shock Alert ,Crash Accident Alert And Crash Accident Data Logger
*1234*N# <Switch Off Shocking Alarm> 2. Accident Alert for A/B/C Numbers By configure Cat-1X installation position and X,Y,Z axils value to setup the accident alert value limit as trigger conditions. Cat-1X provides two ways to configure: Configure By SMS commands *1234*CS*m,x.x,y.y,z.z#... - Page 14 3. Crash accident data logger for before/After 15Seconds in accident time Cat-1X will record recent 3Times Accident G varies truth in memory. And allow user to load out via USB connection through the Configurator program. And recover back all details information via chart.
-
Page 15: Voice Listen-In
3.6 Voice Listen-in Call Center Number D and SMS center Service No. G call Cat-1X, the system will put through to Voice Listen-in mode directly. CAT-1X also provide other two methods to start Voice listen-in Operation: 1. By SMS command with correct password to Cat-1X box to get re-call back *1234*VMxxxxxxxx# <xxxxxxx is call back phone No. - Page 16 2.Speed Over alert: After speed limit is break, the vehicle is not slow down to under limit within a configured time period, the CAT-1X will drive the siren sounding until the speed slow down to under limit. At the same time, CAT-1X will activate the “immobilizer”...
-
Page 17: Emergency Medical/Information Call To Center( Two Way Intercom)
3.12.3 GEO Fencing Management CAT-1X maximum allows user to create 25 GEO fencing areas. And the area shape can be circular or rectangular. Considered text message only can contain 140Bytes text, so user need to create multi-areas with more than one text message command. -
Page 18: Remote Door Lock/Unlock
By Configurator program or SMS commands, user can configure one Call center Voice service Number D in Cat-1X. After the short call button was pressed, the CAT-1X will start to call this D number and connect to talk with Call center support People. -
Page 19: Daily Travel Mileage Sms Report To Driver ( A Authorization Phone No.)
Default setting is all defense area in ON status. How to program sensor to CAT-1X Box? CAT-1X allow user to do sensor code programming via two methods: SMS Command and override via Panic button + ACC ON/Off switch. 1. Override via panic button and ACC status: 2.4.2 Transmitter and wireless sensor Program to Cat-1X box... -
Page 20: Ota Firmware
Note: Please configure CAT-1X Time zone to be your local time before you setup this. 3.20 OTA firmware CAT-1X supports firmware upgrading via GPRS. To use this function, you have to enable GPRS connection on the CAT-1X command. Firmware Upgrading SMS command is: *password*UPGRADE:xxx.xxx.xxx.xxx,9200,CAT1XV1.0.1.bin#...
