GSL SWB1000-12 Operating Instructions

Model:
SWB1000-12, SWB1000-24
SWB1800-12, SWB1800-24
SWB2500-12, SWB2500-24

Features include:

• Microprocessor-based design with accurate and stable frequency • Capable of driving inductive loads, i.e. electric
tools and appliances • Low Battery Shut Down • Input voltage (12V Models 10-15VDC) (24V Models 21-30VDC) •
Output Voltage 235-245VAC, Pure Sine Wave @ 50Hz
• Low harmonic distortion (3%≤) • Compact, rugged and designed with (82-85%≥) efficient • Aluminium chassis for
harsh environments and easily mounted

Safety Instructions:

WARNING! - Professional electrical / renewable energy installer should perform the installation, as dangerous
voltages can be present. Before installing and using your inverter, read the Installation Instructions!

Explosive Gas Precautions:

This equipment contains components that can produce arcs or sparks. To prevent fire or explosion do not install in
compartments containing batteries or flammable materials, or in locations that require ignition-protected equipment.
This includes any space containing petrol-powered machinery, fuel tanks, joints or other connections between
components of the fuel system.

Precautions When Working With Batteries:

• If battery acid contacts skin or clothing, wash immediately with soap and water. If acid gets into eyes, immediately
flood eyes with running cold water for at least 20 minutes and get medical attention immediately. NEVER smoke,
allow a spark or flame in the vicinity of batteries or engine. Do not drop a metal tool on the battery as the resulting
spark or short-circuit of the battery may cause an explosion.
• Remove personal metal items such as rings, bracelets, necklaces, and watches when working with a lead-acid
battery. A lead-acid battery produces a short-circuit current, high enough to weld a ring or similar metal, causing a
severe burn.
WARNING! - Shock Hazard! Before proceeding further, ensure that the Inverter is NOT connected to any
Batteries, and that all wiring is disconnected from any electrical Sources. Do not connect the 0utput Terminals of
the Inverter to an incoming AC sources.
Before installing your inverter, please make sure that you have appropriately sized batteries. A battery that is too
small in capacity will not allow the inverter to perform to its full specification. The DC cabling must be connected to
the correct polarity terminals of the battery bank. (Red = Positive, Black = Negative).
DO NOT extend the DC cable length to the inverter unless you are prepared to increase the diameter of the cable. If
this is necessary consult your supplier or installer for advice.
WARNING! - Reverse polarity connection will blow the internal fuse and may damage the inverter permanently.
240VAC Sine Wave Power Inverter
Please read these instructions before use
Unit 2, 110 Station Rd, Seven Hills ,NSW, 2147, Australia
Traveller Series
Operating Instructions
Page 1 of 4
SWB240R-R2
