Dakota OverView DMOV-7MQ-C2 User Manual

Quad view monitoring system

Advertisement

Quick Links

TROUBLESHOOTING

Problem
No picture, no sound
Improper connection with 12v power adapter. Use of
unauthorized power supply. Power Switch is on OFF
position
No picture
Check whether AV cable is securely plugged in
No sound
Check whether audio connector is secure, or the sound
volume is turned off or down
Dark picture
Ensure that bright and contrast settings are properly
adjusted. Ensure monitor is warm enough
No color
Ensure color settings are properly adjusted in menu
Upside down or lateral
Check horizontal/vertical adjustment on remote.
inverted picture
No car-backing function
Event trigger is not securely connected
(i.e. Picture)
Remote Controller Fault
Battery may be dead or improperly installed:
replacement battery Model:CR2025,3V
Remote controller is not pointed in the direction of the
receiving sensor: Make sure remote is pointed at the
monitor
Long distance or improper angle: The effective distance
between the remote controller and the receiving sensor
is 7 meters and the angle is ±30°.
Obstacle: Move any obstacles out of the path
Dakota Micro, Inc.
8659 148th Ave. SE
Cayuga, ND 58013
www.dakotamicro.com
Possible Causes
Quad View Monitoring System

User Guide

Part Numbers: DMOV-7MQ-C2
www.dakotamicro.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OverView DMOV-7MQ-C2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dakota OverView DMOV-7MQ-C2

  • Page 1: Troubleshooting

    Long distance or improper angle: The effective distance between the remote controller and the receiving sensor is 7 meters and the angle is ±30°. Obstacle: Move any obstacles out of the path Dakota Micro, Inc. 8659 148th Ave. SE Cayuga, ND 58013 www.dakotamicro.com...
  • Page 2 Any action at law, suit in equity, or other judicial proceeding for the enforcement of any warranty provided for herein or otherwise, will be instituted only in the Courts of the State of North Dakota, the laws of which shall govern.
  • Page 3: Included Components

    Included Components Monitor I. Monitor Introduction LED Backlit Sun Visor LCD Screen A/V output Monitor w/ bracket Monitor remote control Power/Video harness Earphone Remote Receiver Vol- Vol+ Menu Bracket Down x2 Camera(s) w/ bracket x2 20M power/video cables 12v lighter adaptor Up/CAM Selection Quad View Mode Switch ON/OFF...
  • Page 4 Monitor Camera III. Installation of DVI24+1 Plug Bracket Screws Install DVI24+1Plug Bracket Screws OverView Mounting Bracket Camera Plug in securely and tighten screws IV. Install/Remove Sun Visor Mounting Bracket Base Installation Top Clip-buckle Camera Specifications Complete Image pick-up Device 1/3" Sharp Color CCD TV System NTSC/PAL (depending upon model) Lens Mount...
  • Page 5: Remote Control

    Monitor Remote Control VI. Monitor Operation: III. Button Function MUTE Press Mute to turn sound off ,to resume volume, press Mute again o r p ress V OL+ P OWER F or O N/OFF /CAM Vol - Menu Up/CAM ON/Standby a.T o select men u option Selection...
  • Page 6 Monitor Remote Control I. Introduction b. Normal/Mirror Image Monitor displays Camera function as listed below: MIRROR Mute ON/Standby CAM B NORMAL CAM L MIRROR CAM R MIRROR Volume+ CAM F MIRROR CAM Selection Menu SELECT ADJUST Volume- Down Press Up/Down to select CAMB / CAML / CAMR / CAMF Call press Vol+/-to set up Normal/Mirror image of CAMB / CAML / CAMR / CAMF Mode...
