Summary of Contents for ITL NV200
-
Page 1: Nv200 Manual Set - Section
NV200 MANUAL SET QUICK START CONFIGURATION GUIDE Innovative Technology assume no responsibility for errors, omissions, or damages resulting from the use of information contained within this manual. -
Page 2: Table Of Contents
NV200 Manual Set – Section 1 NV200 MANUAL SET – SECTION 1 QUICK START AND CONFIGURATION GUIDE Assembly Panel Layout DIP Switch Settings Connectors and Pinouts Status Indicators Programming Technical Specifications NV200 Bezel Flash Codes Frequently Asked Questions Copyright © Innovative Technology Ltd 2014... -
Page 3: Quick Start And Configuration Guide
This section contains the essential information that a user needs to quickly assemble and configure the NV200 validator ready for installation into the host machine. Assembly Installing the NV200 is a simple operation, described in the steps outlined here: To remove the NV200 head unit, first unlock the NV200 cashbox... - Page 4 Check bezel fixing screw length before installation. The bezel on the front of the NV200 validator has been designed to be removed and refitted very easily. To remove or refit the bezel the top cover must be open fully to allow access to the bezel mounting area.
- Page 5 NV200 Manual Set – Section 1 Removing the bezel: Lift the upper cover by pulling the top latch forward. If fitted, remove the two bezel securing screws and then slide the bezel assembly upwards. Finally unplug the cable from the socket on the front of the validator head.
-
Page 6: Panel Layout
NV200 Manual Set – Section 1 Panel Layout All the connectors and switches needed to set up and interface the NV200 Validator are easily accessible on the back of the unit: Interface Connector USB Connector DIP Switch Settings The NV200 has a Dual Inline Package (DIP) switch bank that is used to set the various options for the unit. -
Page 7: Connectors And Pinouts
16 way connector. regardless of connection type. The first connector is a 16 pin socket used to interface the NV200 to the host machine. The pin numbering of the socket is shown below, as well as an overview of the socket connections:... -
Page 8: Technical Specifications
NV200 Manual Set – Section 1 Technical Specifications The full technical specifications for the NV200 Validator can be found in Section 6, Appendix B of this manual set. A brief summary is given here: DC Voltage Minimum Nominal Maximum Absolute limits 10.8 V... -
Page 9: Nv200 Bezel Flash Codes
NV200 Bezel Flash Codes The NV200 Validator has inbuilt fault detection facilities. If there is a configuration or other error the NV200 front bezel will flash in a particular sequence; a summary of the Bezel Flash Codes for the NV200 is shown below:... -
Page 10: Frequently Asked Questions
Look at the DIP switch tables in subsection 1.3 of this manual. b. Will my NV200 validator support 24V DC operation? Early revisions of the NV200 did not support 24V DC operation. Check the following to ensure compatibility:... - Page 11 ITL Support for further assistance. f. Some or all notes are not accepted Check that all the dipswitches on the rear of the NV200 are OFF (down), and that no inhibits are set in the Validator Manager software. If the problem persists, contact ITL Support for further assistance.
