INSTRUCTIONS FOR USE & MAINTENANCE MANUAL
CUATRO-3 90
Barbas wishes you many cosy evenings with your new appliance
This document is an essential part of your appliance.
Read it carefully before use of the appliance and keep it in a safe place!
Version number: 02 - 332875
Date: 10-06-2013
Wood-burning appliance
Serial number:
Production date:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUATRO-3 90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for barbas CUATRO-3 90

Summary of Contents for barbas CUATRO-3 90

  • Page 1 INSTRUCTIONS FOR USE & MAINTENANCE MANUAL CUATRO-3 90 Wood-burning appliance Barbas wishes you many cosy evenings with your new appliance This document is an essential part of your appliance. Read it carefully before use of the appliance and keep it in a safe place!

  • Page 3: Table Of Contents

    Cuatro-3 90 CONTENTS Page 1. INTRODUCTION ..................2. SAFETY ...................... 3. OPERATION ....................4. USING THE APPLIANCE FOR THE FIRST TIME ........5. USE ......................6. FUEL ......................7. MAINTENANCE ..................8. FREQUENTLY ASKED QUESTIONS ............9. WARRANTY TERMS ..................
  • Page 4 Cuatro-3 90 Instructions for use...

  • Page 5: Introduction

    Cuatro-3 90 INTRODUCTION Congratulations on your purchase of this modern Barbas appliance. This quality product will provide you with many years of enjoyment due to the fl ame effect and warmth that it provides. This appliance is exempted under section 21 of the Clean Air Act 1993 and can be used in accordance with the intended use as described in this manual in smoke control areas in the UK.

  • Page 6: Safety

    Ensure that the room in which the appliance is situated has adequate ventilation. It is essential that the appliance, the fl ue and combustion air supply are cleaned and inspected annually by a Barbas dealer/specialist. The safe operation of the appliance will thus remain guaranteed. Instructions for use...
  • Page 7 Cuatro-3 90 The appliance must never be used with the door open or the door glass removed. Wood and wood briquettes may be stoked in the appliance. Coals can’t be burned in the appliance. Avoid over-loading (white burning glow), caused, for example, by lengthy burning with a fully open primary air vent (combustion air supply slider all the way to “...

  • Page 8: Operation

    Cuatro-3 90 OPERATION Cuatro-3 appliance with fan set (option) and convection set (option) built into chimney breast Handle Ceramic heat-proof glass Locking for operating pin of fl ue gas fl ap Operating pin of fl ue gas fl ap Convection air outlet opening (appliance) (permanent)

  • Page 9: Using The Appliance For The First Time

    Cuatro-3 90 USING THE APPLIANCE FOR THE FIRST TIME GENERAL Allow your home to dry properly, after you have had your chimney breast modifi ed or newly built. Walls which have not been allowed to dry properly are a magnet for dust such as any smoke particles created when stoking up the appliance or suddenly opening the door.
  • Page 10 Cuatro-3 90 4.3 INSPECTION OF THE APPLIANCE BEFORE FIRST USE Check all available functions before using the appliance for the fi rst time. • Check the opening and closing operation of the door. Turn the handle all the way down: Door is locked.
  • Page 11 Cuatro-3 90 • Check the operation and setting of the fl ue gas fl ap. Locking (inside door) Flue gas fl ap pin Flue gas fl ap Combustion air-supply slider 2x Inlet opening convection air 2x Inlet opening combustion air All openings are closed, if the appliance is installed as a built-in fi...
  • Page 12 Cuatro-3 90 close open Locking closed (turned to the left) Locking open (turned to the right) Locking for operating pin of fl ue gas fl ap (inside of door). Locking all the way to the left (closed): Flue gas fl ap operation works normally:...
  • Page 13 Cuatro-3 90 • Flue gas fl ap in “open” position. • Check whether the retardant plate (brake plate) is located correctly in the supports. • Check the operation of the slider for the regulation of the combustion air intake (middle below the window).
  • Page 14 Cuatro-3 90 • Check whether the ashtray is completely empty. • Report any defects immediately to your dealer. • Remove enclosed documents and components from the appliance. • Check the function of the Perma Air ® convection fan (optional) using the wall dimmer switch.

  • Page 15: Use

    Cuatro-3 90 5.1 VENTILATION If wood is to burn, it needs air. For each kilo of wood that you put on the appliance (door closed), 10 - 15 m of extra air is needed. That means about 35 m per hour! Depending on how the appliance has been installed, the combustion air will either be drawn directly from outside or from the living room itself.
  • Page 16 Cuatro-3 90 When setting the appliance, turn the locking all the way to the right. If necessary, leave the door ajar for 10 minutes. Do not open the door wide, as the window will remain cold. If the door is shut during this time, smoke will condense on the glass and form soot.
  • Page 17 Cuatro-3 90 Weather conditions In order to reduce pollution and any other inconvenience, we advise not fi ring up the appliance when there is no wind, or in foggy/misty conditions. Smoke development Your appliance has been designed to be used with the load/observation door closed.
  • Page 18 Cuatro-3 90 Increasing the draught: • Remove the fl ue gas fl ap by lifting it slightly, tipping it backwards and removing it. • Bend the strips, L and R, on the retardant plate (brake plate) holder completely backwards. As a result, the opening for the discharge of the fl ue gases increases.
  • Page 19 Cuatro-3 90 5.4 HEATING ECONOMICALLY The most environmentally-friendly and economic way of heating with wood is to have your fi re hot but calm. The ash should appear to glow a soft red-orange and should not glow like a blacksmith’s fi re. Fires like that burn quickly and intensely, leaving little time for complete combustion.
  • Page 20 Cuatro-3 90 5.6 GENERAL HEATING TIPS • Burn dry wood only. Damp wood not only burns poorly, it causes more pollution in the appliance (window), the chimney, your room (when opening the door of the appliance, for instance) and the environment. Wood can only be classifi ed as dry if it has been stored under a Dutch barn for at least two years (not covered with plastic).
  • Page 21 Cuatro-3 90 OUTPUT In practice, combustion is all about loss. This entails: • Loss through excess heat leaving the chimney, rather than going into the room. • Loss through insuffi cient combustion, such as CO (carbon monoxide) and soot particles.

  • Page 22: Fuel

    If this happens, there is a risk of fi re. It may also damage your appliance and chimney. BARBAS will not assume liability for damage caused by overheating. Burning one layer of wood can lead to varying outputs. When used correctly, one load will burn in around 45 minutes.
  • Page 23 Cuatro-3 90 Cuatro-3 90: Per fi lling: (= for 45 minutes) Wood: 3 blocks each around 1.10 kg Briquettes: 5 blocks each around 0.55 kg Dimensions wood block: c. 28 cm long and 30 cm perimeter (≈ 1.1 kg). The maximum burning load is based on a nominal capacity of 16 kW and a effi...

  • Page 24: Maintenance

    Cuatro-3 90 MAINTENANCE • Emptying the ashtray • Regularly check how much ash is in the ashtray. • Make sure the ashtray is never more than ¾ full. If the ashtray is more than ¾ full, it can obstruct the fl ow of air to the appliance.
  • Page 25 Cuatro-3 90 • Paint Check annually, if necessary touch up with BARBAS heat-resistant paint (do not paint when the appliance is in use!) • Parts Individual parts for replacement/accessories are available from your BARBAS dealer Use only original parts • Modifi cations Introduced modifi...

  • Page 26: Frequently Asked Questions

    Can a wood-burning appliance/fi replace insert be connected to a central heating installation? The Barbas range does not have any appliances that can be connected to central heating installations. We do not advise attempting it!! At what temperature does the convection fan cut in? If the appliance is fi...
  • Page 27 Cuatro-3 90 How do I know if I’m heating correctly? Follow the instructions in this manual. The fl ames should play softly across the wood and the wood should burn evenly. Once the fuel has been burning for a short time, the smoke from the chimney should be almost translucent.
  • Page 28 Cuatro-3 90 Do I have to take any extra measures if the room I am heating has an extractor fan (mechanical ventilation)? If the combustion air comes from the living-room: A fl ue gas fan is required for permanent extraction of the area in which the appliance is placed.

  • Page 29: Warranty Terms

    2.3. Complaints will only be accepted if they are reported to the Barbas dealer, together with the serial number of the Barbas appliance which is stated on the front of the instructions for use. 2.4. In addition, the original receipt (invoice, receipt, cash receipt) showing the date of purchase must also be submitted.
  • Page 30 Article 5: Warranty period 5.1. This warranty will only be granted during the warranty period. 5.2. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase.
  • Page 32 Your Barbas dealer 02 - 100613 - 332875...
