USER MANUAL 19LEDCACI
LED TV with DVB S2 CA CI,
DVB T CI, DVD Loader and
Sound Bar
Before connecting, operating or adjusting this product, please read these instructions
completely. Please keep this manual for future reference
(All pictures used in this manual are only for illustration purpose. Those pictures may be different from the actual TV unit.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 19LEDCACI and is the answer not in the manual?

Questions and answers

Related Manuals for Denson 19LEDCACI

Summary of Contents for Denson 19LEDCACI

  • Page 1 USER MANUAL 19LEDCACI LED TV with DVB S2 CA CI, DVB T CI, DVD Loader and Sound Bar Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference (All pictures used in this manual are only for illustration purpose. Those pictures may be different from the actual TV unit.)
  • Page 2 Important Safety Instructions: The Lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of un-insulated "DANGEROUS VOLTAGE " within the product's enclosure that may be of sufficient magnitude to constitute a risk or electric shock to persons.
  • Page 3 Important Safety Instructions Continued Heat The Product should be situated away from heat source such as radiators, heat registers, stoves or other products (including amplifiers) that produce heat. Object and Liquid Entry Unit should not be exposed to liquids of any kind. Don't place the unit on an uneven surface.
  • Page 4 Important Safety Instructions Continued Power Cord Protection Protect the power cord from being walked on or pinched, particularly at plugs, outlets, and the point where they exit from the unit. If the mains plug should fails to fit, contact your electrician to replace your obsolete outlet.
  • Page 5 If the product has been exposed to rain or water. If the product does not operate normally after following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper Adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to its normal operation.

  • Page 6: Table Of Contents

    CONTENT: Page 1. Introduction 1.1 Product description 1.2 Product features 1.3 Package contents 2. System Set up 2.1 Front Panel Touchpad & Remote Control Function 2.2 Remote Control 2.2.1 Remote Control Battery Installation / Removal 2.2.2 Remote Control Operating Instruction 2.3 Connectivity TV Set 3.
  • Page 7 7.3 Sound Menu 7.3.1 Sound Modus 7.3.2 Treble 7.3.3 Bass 7.3.4 Balance 7.3.5 Auto Volume 7.3.6 Surround Sound 7.3.7 AD Switch 7.3.8 EQ (Equalizer) 7.4 Time Menu 7.4.1 Clock 7.4.2 Time Zone 7.4.3 Sleep Timer 7.4.4 Auto Standby 7.4.5 OSD Timer 7.5 Lock Menu 7.5.1 Lock System 7.5.2 Password setting...
  • Page 8 9.1 Picture Menu 9.2 Sound Menu 9.3 Time Menu 9.4 Parental lock 9.5 Set up Menu 10.Media OSD Operation 10.1Photo Menu 10.2 Music Menu 10.3 Movie Menu 10.4 Text Menu 11. DVD Operation 11.1 Basic Operation 11.2 DVD settings / DVD menu settings 11.3 DVD Picture Menu 11.4 Sound Menu 11.5 Time Menu...
  • Page 9 Powered by SD Electronics...

  • Page 10: Introduction

    1. INTRODUCTION Product Description Thank you for choosing the DENSON 19LEDCACI TFT/LED Colour TV / HD Satellite Receiver / DVB-T Receiver / DVD / Monitor and for your continued support and use of our products. The product combines the features of a TV / DVB-S-S2 HD Satellite receiver / DVB-T H.264 MPEG2 receiver / DVD Player and PC Monitor with a THIN FILM TRANSISTOR liquid crystal A-grade display (TFT-LED).This new generation of...

  • Page 11: Package Contents

    Package Contents Please check the Package to make sure it contains the following items: TFT LCD Remote Control EU Power Cord ADAPTER THIN & FLEXIBLE 50cm coax cable with mounted UNIVERSAL AUTO CIGARETTE 2 x Male F-connectors and 1 x LIGTHER PLUG LINE Female/Female Fconn.

  • Page 12: Front Panel Touchpad & Remote Control Function

    2.1.Front Panel Touchpad & Remote Control Function Item Function Discription Remote IR Sensor (Receives IR signal from remote Control) Red - Stand by, Green- Operating POWER Turn on/off TV SOURCE Call out the input source selection interface. MENU Display the main menu on screen; go to the previous level of OSD. - CH + Decrease TV channel/ Increase TV channel.

  • Page 13: Remote Control

    2.2 Remote Control： ： ： ： POWER: Standby mode turn on/off. (Mute): Turn volume off/on. 3 SLEEP: To setup power-off timer. ZOOM: to select the screen display aspect ratio. LANG/AUDIO: To select language and audio channel for ATV and DTV TV/RADIO: Switch between TV and radio channels in DTV mode.
  • Page 14 31 ►►: Fast forward for USB media mode and DVD mode. 32 I : To playback previous chapter for USB ◄◄ media mode and DVD mode. I: To advance forward to the next chapter ►► for USB media mode and DVD mode. ►II: Press to play or pause for USB media mode and DVD mode.

  • Page 15: Remote Control Battery Installation / Removal

    2.2.1. Remote Control Battery Installation / Removal CAUTION !! Avoid damaging the Remote Control by NOT: Applying excessive pressure when pressing buttons Exposing to extreme Low or High temperatures Exposing to excessive Moisture Mishandling to Dropping 2.2.2. Remote Control Operating Instruction: The Remote Control Transmission consists of an Infrared (IR) Signal.

  • Page 16: Connectivity Tv Set

    2.3. Connectivity TV SET: Right Side: Linkerkant: Left Side: LNB-IN DVB-S2 CI Slot DVB-S2, behind a detachable cover Smartcard reader DVB-S2 USB input of the DVB-S2 receiver DVD Slot Powered by SD Electronics...

  • Page 17: First Time Installation

    3. First Time Installation After you have installed the satellite Dish or DVB-T antenna you switch the TV set On with the ON/OFF switch at the right side of the TV set. Press Power button on the remote control. The Power indicator instantaneously changes from red to green. 3.1 Basic Operation: −...

  • Page 18: Pvr Setting

    1. Play Mode Press the GREEN button to set the play mode. It include the Loop, Slide Show Interval and Photo View Mode options. 4.2.3. PVR Setting Press the BLUE button to enter the PVR Setting menu. In this menu, you can set the options of Record Partition, Record Mode, Record Type, Record Time, Auto Timeshift, Timeshift...

  • Page 19: Pvr

    3. Movie 1) Press the VOL+/VOL- to highlight the Movie. 2) Press the CH+/CH- to change the folder or file and press the OK button to open the folder or play the movie file. It supports *.3GP, *.AVI,*.MKV, *.MP4, *.MOV, *.MPG, *.TS, *.M2TS, *.DAT, *.VOB format movie files. OK: View play list or play the highlighted file in the play list.

  • Page 20: Usb Software Upgrade Of The Dvb-S2 Receiver

    and press the Red button to mark it, then move it to the destination press OK to confirm, then you can move the marked file to destination. 4) Press the GREEN button set the Play Mode. 5) Press Yellow key to delete highlighted file from Play List. 6) Press the BLUE button to delete all files from Play list.

  • Page 21: Osd Language Settings

    After you selected the SOURCE, the First step is to set the OSD language required. Push the MENU button on the RCU or TV set to enter the MAIN MENU. In the Main Menu you can use the ◄ / ► button to select one of the next sub Menu’s > CHANNEL, PICTURE, SOUND, TIME, LOCK and SET UP.

  • Page 22: Channel Menu

    To view DVB-T digital TV, you have to push the SOURCE button on the RCU and select DTV with the ▼ / ▲ buttons and then push OK button to confirm. ( DTV = Digital TV > DVB-T is DTV ) 7.1 Channel Menu: Press LCD-MENU button to display the MAIN OSD MENU.

  • Page 23: Program Setting

    − Select the Current CH for the manual tuned channel to be stored in. − Select the TV colour system and sound system. − Select whether Auto Frequency Control (AFC) to be on/off. AFC will do minor adjustment for shifted frequency in order to get better tuned picture.

  • Page 24: Picture Menu

    − Select CI Information then press OK or ► button to enter CI Information interface. − Display the Common Interface card information. Note: Not available in ATV mode. 7.2. Picture Menu: 1. Press LCD-MENU button to display the MAIN OSD MENU. Press ◄ / ► button to select the Picture Menu.

  • Page 25: Colour

    − Select Brightness then press OK or ► button to enter brightness sub menu. − Press ◄ / ► button to make the adjustment. − Press OK or LCD MENU button to confirm adjustment and go back to previous menu. Note: Brightness only available for adjustment when in Personal picture mode.

  • Page 26: Dynamic Cr

    7.2.9. Dynamic CR: − Dynamic contrast ratio function. − Press ► button to select ON/OFF for this function. − This feature allows backlight adjustment to automatically control the black and white level of display. 7.3. Sound Menu: Press LCD-MENU button to display the MAIN OSD MENU. Press ◄ / ► button to select the Sound Menu.

  • Page 27: Balance

    − Select Bass then press OK or ► button to enter Bass sub menu. − Press ◄ / ► button to make the adjustment. − Press OK or LCD MENU button to confirm adjustment and go back to previous menu. 7.3.4.

  • Page 28: Clock

    1. Press LCD-MENU button to display the MAIN OSD MENU. Press ◄ / ► button to select the Time Menu. Press ▼ / ▲ button to select the option that you want to adjust in the Time menu, then press OK button or ►...

  • Page 29: Osd Timer

    − Press OK button to confirm selection. Press LCD MENU button to return to previous menu without changes. − Press EXIT button to exit the OSD completely. − Auto Standby function allows TV to go into standby mode if the TV is not operated at all for the duration.

  • Page 30: Password Setting

    − The default password is “0000”. − After correct password is entered, the “Block program”, Parental Guidance” and “Key Lock” function will be available for setting. 7.4.2. Set Password: − Select Set Password then press OK or ► button to enter change password interface as seen below. −...

  • Page 31: Parental Lock

    − Blocked channel can only be watched when correct password is inserted. 7.5.4. Parental Guidance: − Select Parental Guidance then press OK or ► button to enter Parental Guidance sub menu. − Press ▼ / ▲ button to select the age requirement you desire. You can select from: Off/4/5/6/7/8/9/10/11/12/13/14/15/16/17/18 −...

  • Page 32: Impaired Hearing

    − Press OK button to confirm selection. Press LCD MENU button to return to previous menu without changes. − Press EXIT button to exit the OSD completely. 7.6.3. Impaired: − Select Hearing Impaired then press OK or ► button to enable/disable the Hearing Impaired function. −...

  • Page 33: Aspect Ratio

    7.6.5. Aspect Ratio: − Select Aspect Ratio then press OK or ► button to enter Aspect Ratio sub menu. − Press ▼ / ▲ button to select the aspect ratio display you desire. You can select from: Auto / 4:3 / 16:9 / Zoom1 / Zoom2 −...

  • Page 34: Pc Mode Osd Operation

    8. PC Mode OSD Operation: 8.1. Screen Menu: Press LCD-MENU button to display the MAIN OSD MENU. Press ◄ / ► button to select the Screen Menu. Press ▼ / ▲ button to enter the sub menu entries. 8.1.1. Auto Adjust: −...

  • Page 35: Sound Menu

    8.3. Sound Menu: − Same with ATV mode. 8.4. Time Menu: − Same with ATV mode. 8.5. Lock Menu: − Same with ATV mode with the exception of Block Program and Parental Guidance function are unavailable. 8.6. Setup Menu: − Same with ATV mode with the exception of TT Language, Hearing Impaired and PVR File System functions are unavailable.

  • Page 36: Media Osd Operation

    10. Media OSD Operation: Plug in the USB drive with the media file into the USB port before operating the Media interface. Select the source as MEDIA. Press ◄ / ► button to select the media format between Photo, Music, Movie and Text. Press OK button to enter the selected media entries.

  • Page 37: Music Menu

    Play Start the slide show Prev. Go to previous photo. Next. Go to next photo. Stop Stop the slide show and go back to thumbnail view mode. Repeat RepeatAll: Repeat all the photos in slide show again RepeatNone: No repeat, slide show go back to thumbnail mode after showing all the photos.

  • Page 38: Movie Menu

    Fast backward, speed of 2x, 4x, 8x and 16x. Fast forward, speed of 2x, 4x, 8x and 16x. Prev. Go to previous song. Next. Go to next song. Stop Stop the slide show and go back to thumbnail view mode. Repeat RepeatAll: Repeat all the songs in the playlist/folder.

  • Page 39: Text Menu

    RepeatNone: No repeat, will stop after all the movies in the playlist are played. Repeat 1: Continuously playing current movie, repeating itself. Set A/B Set the movie to repeatedly playing section A to section B. Playlist Show the playlist of the movies folder. You can use the P+ and P- (channel up/down button) to go to next page and previous page quickly.

  • Page 40: Dvd Operation

    Stop Quit reading the text file and go back to previous menu. Music Play the music in the background. Only music file placed in the same directory with the text file will be played. Playlist Show the playlist of the text folder. You can use the P+ and P- (channel up/down button) to go to next page and previous page quickly.
  • Page 41 The screen will show next: With the ▼ / ▲ button you can select the desired Picture Modus. If selected PERSONAL and push the OK button, you will enter the Personal Picture setting and the screen will show next > With the ▼...

  • Page 42: Sound Menu

    The Contrast setting is shown of current setting ( on picture this is 58% ) If you want to adjust the setting, please push the OK button. Next menu is shown > With the ◄ / ► button you can adjust the contrast setting. Push EXIT to leave the OSD Menu or push MENU button to return to previous menu.

  • Page 43: Reference

    12. REFERENCE 12.1 Cleaning LCD Monitor 1. Please make sure that you have turned off this machine. 2. Do not expose liquid of any kind on the LCD Monitor or plastic box. Please NOTE when cleaning the LCD monitor. 1. Gently wipe the screen with a clean, soft, lint-free cloth to remove dust or other particles that can scratch the screen. 2.

  • Page 44: Trouble Shooting

    13. Troubleshooting Please use the following table to resolve the most common possible causes of the problem before calling service personnel. A minor adjustment may eliminate the problem and restore your TV reception. Symptom Corrective Actions Check that power is turned on. Adjust brightness and contrast.
