Nanotechnology Under Counter Water Purification System
I n s ta l l at I o n a n d o p e r at I n g I n s t r u c t I o n m a n u a l
Hel neu st 57
RS-90
RC-93
RP-100
For systems, FIlters & servIce
t:
e:
w:
952.884.8417
info@bdavidwater.com
bdavidwater.com
Rev: 12/01/2015
Advertisement
Table of Contents
Related Manuals for B.David Company RS-90
Summary of Contents for B.David Company RS-90
- Page 1 B.David Company 9333 World Health Through Water Puri cation Systems Nanotechnology Under Counter Water Purification System I n s ta l l at I o n a n d o p e r at I n g I n s t r u c t I o n m a n u a l...
- Page 2 B.David Company 9333 Nanotechnology Under Counter Water Purification System World Health Through Water Puri cation Systems Important – Set Effective Life indicator to 1000 Gallons S p e c i f i c a t i o n S : pressure Range: 2.1-8.62 bar (20-115 psi)
- Page 3 p a R t S i n c L u D e D : • Filter system with filter cartridges • Installation hardware (mounting screws, saddle valve, fittings) • 6.35 mm (1/4-inch) tubing • Lead-free faucet tools and Materials Required: •...
- Page 4 i n S t a L L a t i o n • For standard under-sink installation on 10 mm (3/8-inch) cold water line. • Please read all instructions and precautions before installing and using your filtration System. • Numbered diagrams correspond with numbered steps. Installing the Saddle Valve (diagram 1) Use of a hand drill is recommended.
-
Page 5: Mounting The System
When drilling through a countertop make sure the area below the drilled area is free of wiring and piping. Make certain there is ample room to make the proper connections to the bottom of the faucet. Do not drill through a countertop that is more than 25mm (1-inch) thick. Do not attempt to drill through a tiled, marble, granite or similar countertop. - Page 6 Connecting the Faucet (diagram 5) caution: Do not over-tighten compression nut. Use caution not to bend or crimp tubes when securing. Locate compression nuts in installation kit and fau- cet package. Attach compression nuts to faucet stem and Effec- tive Life Indicator (ELI) and hand tighten. Then loosen compression nut one full turn.
- Page 7 Connecting the Saddle Valve (diagram 8) Locate Compression Nut in installation kit pack- age and attach to inlet fitting. Tighten the nut hand tight and then loosen one full turn. Repeat steps 6B and 6C. Connecting Inlet Line to System (diagram 9) Locate Compression Nut in installation kit pack- age and attach to inlet fitting.
-
Page 8: Filter Cartridge Replacement
note: Initially, filtered water may appear cloudy. Turn off water supply to system and press pres- If you set a glass of water on a level surface, you sure-relief button. Remove bottom of housings should be able to watch the cloudiness disappear and empty out water. -
Page 9: Troubleshooting
B. David specific / Replacement Filter Cartridges incidental or consequential damages, the above limitations or exclu- sions may not apply. 1. Stage # 1: RS-90 THIS WARRANTY GRANTS SPECIFIC LEGAL RIGHTS, ANO OTHER 2. Stage # 2: RC-93 RIGHTS MAY APPLY. SUCH RIGHTS VARY FROM STATE TO STATE. - Page 10 M a i n t e n a n c e Date Activity/Service Performed Installation Date Hel neu st 57 Tel: (952) 884-8417 B.David Company Email: info@bdavidwater.com Visit our website: www.bdavidwater.com World Health Through Water Puri cation Systems...
