Shindaiwa 340s Instruction Manual

Shindaiwa 340s Instruction Manual

Chain saw
Hide thumbs Also See for 340s:
Table of Contents

Advertisement

Quick Links

Download this manual
x7722271404 / x772000164

Instruction Manual

The muffler or catalytic muffler and surrounding cover may become extremely hot.
Always keep clear of exhaust and muffler area, otherwise serious personal injury may
occur.
The engine exhaust from this product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Users of this equipment risk injury to themselves and others if the unit is used
improperly and/or safety precautions are not followed. ECHO provides an operator's
manual and a safety manual. Both must be read and understood for proper and safe
operation. Failure to do so could result in serious injury.
Specifications, descriptions and illustrative material in this literature are as accurate as known at the time
of publication, but are subject to change without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
X7503274701
© 8/2015 ECHO Inc.
340s

CHAIN SAW

Burn Hazard

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 340s and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shindaiwa 340s

Summary of Contents for Shindaiwa 340s

  • Page 1: Chain Saw

    / x772000164 340s CHAIN SAW Instruction Manual Burn Hazard The muffler or catalytic muffler and surrounding cover may become extremely hot. Always keep clear of exhaust and muffler area, otherwise serious personal injury may occur. The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
