I Vision Electronics Co., Ltd
Dear customers, you are strongly recommended to read the
"User's Manual" carefully before use since the machine needs a
professional job for functional settings.
Ivision IP Camera
User's Manual
Release date:
2011/10/26
Revision:
1.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IV-NT6811D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for iVision IV-NT6811D

  • Page 1 I Vision Electronics Co., Ltd Dear customers, you are strongly recommended to read the “User’s Manual” carefully before use since the machine needs a professional job for functional settings. Ivision IP Camera User’s Manual Release date: 2011/10/26 Revision:...
  • Page 2 I Vision Electronics Co., Ltd Declaration Some technical details in this User’s Manual may not be described accurately or some printing errors may exist in this user’s Manual. When you use the product and have any problems that could not be solved by following this User’s Manual, please call our Technical Dept. for troubleshooting.

  • Page 3: Table Of Contents

    I Vision Electronics Co., Ltd Catalogue About the product ........................... 4 1.1 Product introduction ........................4 1.2 Function introduction ........................4 1.3 Technical specifications ......................4 Appearance and description ......................5 Equipment and installation ......................5 3.1 Operation environment ......................5 3.2 Installation of equipment ......................

  • Page 4: About The Product

    Two-way voice Talkback, support external audio input and output;  Complete network protocol, support RTSP, VLC（PS/TS） Media Protocol;  Support the mobile phone for remote monitoring; 1.3 Technical specifications IV-NT6811D/NT9011D Parameter/Model Compression standard Video frequency compression standard H.264/MJPEG Compression output code rate 32K～4Mbps/1M～16Mbps...

  • Page 5: Appearance And Description

    Power source DC12V/1A Power consumption <5W 2 Appearance and description NT6811D IV-NT6811D IV-NT9011D IV-NT6811B IV-NT9011B You can use the following steps to restore to the Default Settings, i.e.: 1. Switch the power source off; 2. Press and hold the Reset button;...

  • Page 6: Installation Of Equipment

    I Vision Electronics Co., Ltd 3.2 Installation of equipment 1. Connect the NVS with PC via cross network cable; 2. Switch the DC12/1A power on; 3. If the network connection is successful, the indicating lamp (orange) at the network interface will flash within 5 seconds and the indicating lamp of data (green) will be on; at this time, the physical connection of the NVS is finished.

  • Page 7: Function Introduction

    I Vision Electronics Co., Ltd password); 6) Click “OK” button to open Preview of NVS as follows: 4.3 Function introduction 4.3.1 Real-time monitoring [Network Mode]: TCP and Multicast, choose as per your own demand; [Play real-time video]: Click “ ” button, it will play all real-time video of all channels in the preview window;...
  • Page 8 I Vision Electronics Co., Ltd Set the “Audio-in Type” into “Microphone input”; when starting Boost of the microphone, the sound will be amplified. Linear input: for the NVS, it can also use the audio cable to connect its audio input port with the audio output port of the computer.

  • Page 9: Video Replay

    I Vision Electronics Co., Ltd Note: It supports the device with the Talkback function. [Snapshot]: Click “ Snapshot” button, it can save the current screen image in the C::\temp catalogue of the local computer as the *.Bmp format; the naming method of the image file is as follows, i.e.: device name + time;...
  • Page 10 I Vision Electronics Co., Ltd Front-end device: Search the front-end SD card video file Enter the data, start and end time of the query video (local video and remote video) and click “Search” button, it will display all video files that meet the query conditions in the file list. 1.

  • Page 11: Parameter Setting

    I Vision Electronics Co., Ltd [Size of preview image]: Click “ ” button respectively, it will play the preview image in the 1X, 2X and full screen size; the selected size button will become white; when choosing the full screen size, it can restore the original size by clicking the right mouse. [Image buffering]: Click “...
  • Page 12 I Vision Electronics Co., Ltd Click “OK” button, the date and time displayed on the preview window will become synchronous with the date and time of the computer being accessed. 2. Synchronization with NTP Server: Select “synchronization with NTP Server” from the pull-down menu as follows, i.e.: Set the time zone, address and port for the NTP server, make the time synchronize with the current time.
  • Page 13 I Vision Electronics Co., Ltd The default user name and password for the administrator is 888888/888888; it can be changed the user name and password; after changing, click the “OK” button to confirm and login the webpage again; afterwards it can view the real-time video; similarly, it can be changed the name and password of two default common users, i.e.: 1/1 and 2/2.

  • Page 14: Network Parameter Setting

    I Vision Electronics Co., Ltd Click “Restore to leave factory default parameters” , restart the network video server manually to restore the default parameters, except the network parameters and device name (the device name will not be restored). [System update]: Click “System update”, setting interface as following : Click “Browse…”...
  • Page 15 I Vision Electronics Co., Ltd [IP address & port]: Click “IP address & port” line, setting interface as follows: Change the IP address, subnet mask, gateway, web port, Data transfer port remote host address and port , Multicast etc, as well as the web port, UPNP, PPPOE service;...
  • Page 16 I Vision Electronics Co., Ltd Enter PPPOE user name and password to dial up. The optional connection type is [DHCP], setting as follows: The default DHCP is the Disable Status. After starting DHCP, save the parameters and re-boot, and then connect the network video server and PC to a router with the DHCP function; the router will distribute an IP at the same network segment as the router to the network video server automatically (for instance: the IP address of router is 192.168.0.1;...
  • Page 17 I Vision Electronics Co., Ltd 1. Static IP: Click “refresh”, and then double click the wireless network name, enter the password; Enable WIFI, select network type Setting default gateway: check Wireless SSID: enter SSID of the wireless route Input password: Enter the encryption key Test the wireless network: click “refresh”...
  • Page 18 I Vision Electronics Co., Ltd 3. DHCP: Wireless DHCP connection. Search the wireless router that with DHCP function, the router will a wireless IP address assigned at the same network segment as the router to network video server automatically (for instance: the IP address of router is 192.168.0.1;...
  • Page 19 I Vision Electronics Co., Ltd Enabled “start DDNS”, select DDNS supplier, enter DDNS username and password, domain name, DDNS server address and port, and set the Web mapping port and update interval, and then click “OK” button. Enter the domain name in the web browser; if it can access to the device, it means the domain name is setted successfully.
  • Page 20 I Vision Electronics Co., Ltd Save and re-boot. 2. Set “Dial-on-demand” mode: 1) Set the address for remote host; 2) Set Ping Link Detection shown by Figure 2 and set Ping IP address; It can realize the dial-on-demand through the two methods said above. 3.
  • Page 21 I Vision Electronics Co., Ltd Save and re-boot; and then access to “Dial up settings” interface, click “Apply” to realize the manual dialing (for manual dialing, it does not set the parameter options for LCP echo interval and LCP echo failure; such parameters have no business with the manual dialing). II.
  • Page 22 I Vision Electronics Co., Ltd The client-terminal software is available to view image immediately. III. Access method of external network 1. After making the device online, enter 3G IP in the address bar to access; 2. Access through the dynamic domain name, See the following Figure: IV.
  • Page 23 I Vision Electronics Co., Ltd Used to view the 3G connection log after re-booting. 5. 3G status： Used to view the current 3G network status. 6.PIN Code： The function is the same as the PIN function of mobile phone. 7.SMS settings： Used to set phone number and content for short message, and if it will use the short message to inform when equipment is online.
  • Page 24 I Vision Electronics Co., Ltd Start FTP, finish these settings Upload snapshot and record to FTP when alarming, or upload timing snapshot to FTP [UPNP]: Click “UPNP parameter” , setting interface as follows: Connect the device with the router that with UPNP function, the WEB port, Data transfer port,RTSP port , Data control port and remote transfer port will be mapped , and the status will display “Mapping”.

  • Page 25: Channels Parameters Setting

    I Vision Electronics Co., Ltd 启 用 Rtsp: 勾 选 启 用 Rtsp 后 ， 在 你 安 装 的 播 放 器 媒 体 -> 打 开 网 络 里 输 入 “rtsp://192.168.1.19:554/live”播放实时视频。 Enable Rtsp: enable RTSP,you play real-time video entering “rtsp://192.168.1.19:554/live”...
  • Page 26 I Vision Electronics Co., Ltd Enter the superimposed characters on the video screen, with two rows available for setting, including the Chinese characters, letter in capital and lower case, figures and special character; set the coordinates position where will display, select time format, set the position for the displayed coordinates;...
  • Page 27 I Vision Electronics Co., Ltd transferred simultaneously; if the code stream format is the video format, it will only transfer the video, but not the audio. After changing the code stream format, it needs to re-boot the device to activate. Note: After selecting MJPEG encode, the code rate will be turned to 8000 automatically.
  • Page 28 I Vision Electronics Co., Ltd [Brightness and color adjustment]: Click “Adjust color” line, it will unfold the setting interface as follows: Set the brightness, contrast, saturation and horizontal offset of image. Note: The horizontal offset refers to the left-side offset. [Area shield]: Click “Area shield”...

  • Page 29: Alarm Parameters Setting

    I Vision Electronics Co., Ltd [Audio parameter]: Select “Audio parameter” option, it will display the audio parameter setting page beneath; when setting the audio parameters, please refer to the above audio frequency and Talkback function. 4.3.3.4 Alarm parameters setting [Alarm parameters]: Select “Alarm parameters” option, it will display the parameters beneath as follows: [Sensor Detection Schedule Settings]: Click “Sensor Detection Schedule Settings”...
  • Page 30 I Vision Electronics Co., Ltd Under the normal open mode, it need to trigger the alarm (connect the alarm input with the earth); Under the normal close mode: the network video server will be under the alarm status; after triggering alarm (connect the alarm input with the earth)), the alarm will stop. Start the Trigger Channel Snapshot, the image will be saved in the fore-end storage device.
  • Page 31 I Vision Electronics Co., Ltd Setting alarm when OSD superposition displays. Click “Motion Detection Schedule Settings” line; it will unfold the setting interface as follows: Set the time group and alarm linkage, and then click “OK”; Start the Trigger Channel Snapshot and save the image in the Server-end storage. fore-end storage device.

  • Page 32: Server-End Storage Setting

    I Vision Electronics Co., Ltd Firstly, install email server in the LAN, such as CMailServer installation; add the email account. Even though the Motion Detection Area Settings and sensor alarm does not start the alarm linkage Snapshot, the email box of the recipient will receive alarm email. The email will comprise the email subject and text only (no picture).
  • Page 33 I Vision Electronics Co., Ltd Start the front-end timing video, set the time segment for timing video, and then click “OK” button; the device will start recording pictures on the given time. [FTP scheduled record]: Click “FTP scheduled record” line, it will unfold the setting interface as follows: With reference to the FTP parameter setting option said above, set the FTP uploaded server, select the FTP timing video, set the time for timing video, and then click “OK”...
  • Page 34 I Vision Electronics Co., Ltd Select the timing Snapshot, and set the time interval for Snapshot within the given time period. The network video server will make Snapshot and save it in the Server-end storage with the setting time interval. If “Snapshot FTP Upload” is triggered, the Snapshot picture will be uploaded to the local root directory of FTP Server.

  • Page 35: Fqa

    I Vision Electronics Co., Ltd Click “Format”, it will pop up a hint; click “OK” button, it will start formatting. Please reboot the system after successfully format. By refreshing the webpage, it can examine the free space. Note: The file system is EXT3. If using the software explore2fs.exe and card reader independently, it can download file.

  • Page 36: It Can Not Play The Video Normally After The Program Upgrades

    I Vision Electronics Co., Ltd  Possible reason: the signal cable is not connected properly;  Solution: Re-connect the control cable between the PTZ or dome camera and the network video server. 5.3 It can not play the video normally after the program upgrades ...

  • Page 37: Why It Goes Wrong When Visiting The Nvs Through Internet Explore After Upgrading

    I Vision Electronics Co., Ltd 5.6 Why it goes wrong when visiting the NVS through Internet Explore after upgrading Delete the cache of Internet Explore. You can follow this steps to realize this operation, i.e.: select “Tool menu” — “Internet option”, click “Delete file” button on the 2 item (Temporary Internet file);...

  • Page 38: Appendix

    I Vision Electronics Co., 6.Appendix Appendix A: Explanation for Port In Use (mapping) of NVS When transferring video, the NVS will occupy the following ports as the defaults, i.e.: 80------ Web Port 3000------ Data Transfer Start Port 3001------ Data Control Port When accessing to the NVS through the public internet, it must make port mapping operation on such three ports.

  • Page 39: Appendix B Factory Default Parameters

    Appendix B Factory Default Parameters  Factory Default Network Parameters Parameter Default Value IP address 192.168.1.19 Subnet mask 255.255.255.0 Gateway 192.168.1.1 Transfer start port 3000 Data control port 3001 Remote replay port 3002 Web port Multicast address 235.1.1.1 Multicast port 6500 DDNS Close...
  • Page 40 4. P frame P frame is the one to compress and transfer encoded image of volumes of data by reducing the time redundancy information of the encoded frame before the image sequence; it is called also the predicated frame. 5. BBP frame BBP frame is the video frame;...
  • Page 41 UPNP is the abbreviation of Universal Plug and Play, i.e.: the Universal Plug and Play Protocol. It is actually a structure to realize peer-to-peer network connection for computer and intelligent electrical appliances, whereas the intranet address and the network address is changed based on this protocol. Therefore, as long as our router support UPnP and we use the XP operating system that supports the protocol, we can improve the point-to-point transfer speed accordingly.
  • Page 42 hundreds of feet. As the technology develops and the standard promulgates, such as the IEEE802.11a and IEEE802.11g and others, the IEEE 802.11 has been collectively called as the Wi-Fi. In view of the application layer, user is required to be available the user-terminal device covering Wi-Fi firstly if intending to use Wi-Fi.
