GeyserFlow Series
G-1900
G-2300
G-3500
G-4200
G-4900
G-6300
Instruction and Maintenance Manual
Waterfall Pump
1/6HP 100W / Discharge 1"
1/4HP 200W / Discharge 1.25"
1/3HP 250W / Discharge 1.5"
1/2HP 400W / Discharge 2"
3/4HP 600W / Discharge 2"
1HP 750W / Discharge 2"
Matala
"Make water alive"
-1-
®
Advertisement
Table of Contents
Summary of Contents for MATALA WATER TECHNOLOGY G-1900
- Page 1 GeyserFlow Series Waterfall Pump G-1900 1/6HP 100W / Discharge 1” G-2300 1/4HP 200W / Discharge 1.25” G-3500 1/3HP 250W / Discharge 1.5” G-4200 1/2HP 400W / Discharge 2” G-4900 3/4HP 600W / Discharge 2” G-6300 1HP 750W / Discharge 2”...
- Page 2 Introduction Thank you for selecting the GeyserFlow Series Waterfall Pump. This instruction manual explains the product operations and gives important precautions regarding its safe use. In order to use the product to maximum benefit, be sure to read the instructions thoroughly and follow them carefully. To avoid accident, do not use the pump in any way other than as described in this ! WARNING instruction manual especially when you see...
-
Page 3: Prior To Operation
Other specifications are noted in the chart below. Output Discharge Rated Maximum Dimension Weight Model (Hp) (W) (mm) (Inch) Head(Ft.) Flow(GPH) Head(Ft.) Flow(GPH) L x W x H (mm) Kg/lb G-1900 1/6 100 1" 1392 22.0 1910 190x130x280 5.0/11.0 G-2300 1/4 200 1-1/4"... - Page 4 Installation and Meaning : Symbol DANGER Keep the pump equipment out of the reach of children! DANGER Warns that the failure to follow the directions given could cause serious risk to individuals or objects. W A R N IN G WARING This sign warns the operator that the failure to follow an instruction may damage the pump and/or the system.
-
Page 5: Electrical Wiring
Electrical Wiring Electrical wire Connection : ! WARNING : Verify that the voltage and frequency of the electric pump shown on the nameplate correspond to those available on the mains. The installer must make sure that the electric system is grounded in accordance with the law in force. -
Page 6: Troubleshooting
Troubleshooting Problems Possible Causes * Line circuit breaker is off, or fuse is burned or loosed. * Water level in sump has not reached turn-on level as indicated Pump dose not in installation drawing on the carton. run and hums * Pump cord is not making contact in receptacle.
