Urban Industry Limited

Thor Industrial Estate

Braydon Lane

Cricklade

SN6 6HQ

Tel: +44 (0) 1793 613900

Email: sales@patioheaters4u.com

Registered in England No. 4682994

www.patioheaters4u.com

Printed in the UK

Model No:

BFX740

Terrace & Patio Heater

Operating Instructions

Safety Information..................... .2

Assembly Parts....................... .4

Setting Up................................ .6

Heater Stand & Location............. .9

Leakage Testing...................... 11

Operation & Storage.................. 12

Before Requesting Help........... 13

Technical Data & Specifications 14

Guarantee................................ 15

Certified

Please retain this manual for reference

Table of Contents

Need help?

Do you have a question about the BFX740 and is the answer not in the manual?

Questions and answers

Summary of Contents for Patio Heater 4U BFX740

Page 1 Model No: BFX740 Terrace & Patio Heater Operating Instructions Safety Information...………..…..2 Assembly Parts………………….. .4 Setting Up………..………………..6 Heater Stand & Location…...9 Urban Industry Limited Leakage Testing…………………. 11 Thor Industrial Estate Operation & Storage..………..12 Braydon Lane Before Requesting Help...…….. 13 Cricklade Technical Data &...
Page 2 SAFETY INFORMATION WARRANTY PLEASE READ THE FOLLOWING SAFETY RULES PRIOR TO OPERATION OF THE HEATER. This guarantee is in addition to and does not in any way affect any If you smell gas: statutory or other consumer rights. If within 12 months of purchase the appliance proves to be defective by reason of faulty design, 1.
Page 3 PLEASE READ THE SAFETY GUIDELINES TECHNICAL DATA & SPECIFICATIONS PRIOR TO OPERATION OF THE HEATER • This outdoor gas appliance is for outdoor use only and must not be used in a building, garage or any enclosed area. • The pressure regulator and hose assembly supplied with the patio heater must be used.
Page 4 ASSEMBLEY PARTS & PROCEDURE PROBLEM SOLVING Parts supplied: PROBLEM PROBABLE CAUSE SOLUTION  Cylinder base with LPG tank housing Pilot will not light Gas valve may be OFF Turn gas valve ON  Post assembly with 3 pcs post bracket Tank fuel empty Refill LPG tank Opening blocked...
Page 5 OPERATION & STORAGE PARTS & SPECIFICATIONS TO TURN ON THE HEATER 1. Cylinder Base 1. Turn On the valve on the gas supply cylinder completely. 2. Press the pilot light button for 30 seconds and hold on then press 2. Gas tank housing the igniter button several times until the flame starts.
Page 6 STEP-BY-STEP PROCEDURE CAUTION & LEAKAGE TEST PRECAUTIONS STEP 1:  Periodically check the whole gas system for leaks or immediately if the smell of gas is detected.  Extinguish all open flames. 1-1 Place the 3 piece post bracket on each ...
Page 7 SETTING UP STEP-BY-STEP PROCEDURE HEATER STAND AND LOCATION STEP 4 :  The appliance can be anchored with the use of the ground 4-1 Fit the LPG hose onto the burner fixing bracket. gas inlet connector as shown.  To fix the heater into the ground attach the 3 pcs ground fixers 4-2 Tighten the jubilee clip around the using M6 x 10mm (length) fixer bolts.
Page 8 STEP-BY-STEP PROCEDURE SETTING UP HEATER STAND AND LOCATION STEP 7 : • The heater is for outdoor use only. Always ensure adequate fresh 7-1 Access the gas storage area by raising the gas tank housing air ventilation. and placing it on top of the post bracket. •...
