Turner IntesisHome IS-IR-WIFI-1 User Manual

Universal wall split wifi controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IS-IR-WIFI-1 User Manual
Issue date: 02/2015
r1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntesisHome IS-IR-WIFI-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Turner IntesisHome IS-IR-WIFI-1

  • Page 1 IS-IR-WIFI-1 User Manual Issue date: 02/2015 r1.3...
  • Page 2 ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng Intesis Software S.L. © 2015 Intesis Software S.L. All rights reserved. This document has been carefully written by Intesis Software SL. and a lot of effort has been made to ensure no errors or mistakes are present in the document. Intesis Software S.L. is not responsible for printing or clerical errors.

  • Page 3: Table Of Contents

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng Table of contents Welcome ..................................3 About this document ..............................3 1 Description ................................4 2 Before starting ................................. 5 3 Quick Start ................................6 4 Device installation ..............................7 Wall mounted position ........................... 7 Desktop position ............................

  • Page 4: Welcome

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng Welcome Welcome to IntesisHome, the new eco-friendly system that will allow you to control your Air Conditioning units through our web interface, Apple devices (iPhone, iPad and iPod) and even Android devices. IntesisHome Universal device will offer you: ...

  • Page 5: Description

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 1 Description The IntesisHome Universal device is an external module capable of connecting your Air Conditioning units into your Wi-Fi network in order to provide global connectivity and remote control applications through a friendly user interface. The packaging includes: IntesisHome Device Quick...

  • Page 6: Before Starting

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 2 Before starting Before starting the installation and configuration process please, make sure that you have:  IntesisHome device. Before start using IntesisHome you need to acquire and install (if you haven’t done yet) an IntesisHome device Note: Make sure that you buy the right device.

  • Page 7: Quick Start

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 3 Quick Start In order to start using our system you need to install the device, register it and own a user account. Next, there is a step by step guide to help you going through all this process. 1.

  • Page 8: Device Installation

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 4 Device installation CAUTION: To ensure regulatory compliance, use only the provided power supply. IMPORTANT: Keep in mind that some furniture and materials (carpets, curtains, glass, metal…) may affect on the IR communication. NOTE: The IntesisHome device has 2 IR emitters pointing at 2 different locations.

  • Page 9: Desktop Position

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng Case C: Installed below the AC unit. In that case, the signal will travel from the IntesisHome device to the AC unit tacking advantage of the rebounds on the wall in front of it or other furniture present in the room.

  • Page 10: Power Connection

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 4.3 Power connection The IntesisHome device comes with a 5V DC 0,2 A power supply to be connected to the device. We do also provide 4 different types of plugs to match your current location needs: European Union (EU), United Kingdom (UK), United States (US) and Australia (AU).
  • Page 11 ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 230 VAC Figure 4-7 Additional cable connection Along with the device, there is also an additional cable. One end may be connected to the power supply. First, remove the plug adaptor, you’ll see that the power supply includes an IEC- 60320 C8 standard connector and the cable uses an IEC-60320 C7 connector.

  • Page 12: Location Selection

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 4.4 Location selection Determining that the IntesisHome device will be working as expected in the installation location is an important stage. In order to determine the best location for your IntesisHome device, we offer you two possible options: use your Wireless Controller (the one of your AC unit) or use the special Parrot Mode.

  • Page 13: Using Your Wireless Controller

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 4.4.1 Using your Wireless Controller In order to determine if the desired location is suitable, please follow instructions next: 1. Pick up your Wireless Controller (the one from the AC unit). 2. Locate the Wireless Controller in the position you want to install the IntesisHome device. 3.

  • Page 14: Using Parrot Mode

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 4.4.2 Using Parrot Mode The IntesisHome device includes a special mode (Parrot Mode) that will help you determining if the desired location is a good option or not. While this mode is active, the device will be sending constantly one command so you can check if in the desired location the AC system receives such signal and therefore is a good place to install the device.

  • Page 15: Ir Wireless Remote Controller Feedback

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 4.4.3 IR wireless remote controller feedback The IntesisHome device includes an important feature: IR wireless remote controller feedback. Using this feature, you will be able to update the App status according to the last commands sent from the IR wireless remote controller to the AC unit.

  • Page 16: Wi-Fi Configuration

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 5 Wi-Fi configuration The IntesisHome device supports different Wi-Fi configuration modes:  Auto (SSID visible networks)  Manual (for non SSID visible networks)  Advanced (for static IP configuration)  WPS In order to connect the IntesisHome device to your Access Point or Router, please proceed with the Wi-Fi configuration as follows: 1.

  • Page 17: Ir Configuration

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 6 IR configuration IMPORTANT: Before starting the IR configuration process, please check the compatibility list www.intesishome.com/downloads/universal and make sure that you have the IntesisHome Universal Controller already connected to the Internet. Once you have the IntesisHome device installed and Wi-Fi configured, you are ready to start the IR Configuration process.

  • Page 18: Manual Mode

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 6.2 Manual mode If instead of using the IR remote controller of your AC unit, you want to use our web interface, please visit user.intesishome.com and follow instructions next: 1. Make sure that you have your IntesisHome device Wi-Fi configured. 2.

  • Page 19: Device Registration

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 7 Device registration After configuring the Wi-Fi connection and the IR communication, there is only one last step to be done: register your device. Please, follow bellow instructions to register your device: 1. Visit user.intesishome.com. 2.

  • Page 20: Operation Modes

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 8 Operation modes The IntesisHome device can be operated in two different ways: standard operation (from the App or Web Interface) or back up operation (using the IH button). 8.1 Standard operation: App and web control of the AC unit. This is the standard way to control the AC unit.

  • Page 21: Back Up Operation: Control Of The Ac Unit From The Ih Button

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 8.2 Back up operation: control of the AC unit from the IH button Additionally, the IntesisHome device offers another important functionality. In case your Internet connection is not working and/or your IR remote controller is broken, you can set some commands to the AC unit pressing the IH button.

  • Page 22: Advanced Configuration

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng It is also important to remember that some functions (modes, fan speed…) are directly related with the specific features of each AC unit. Therefore, it is important to keep in mind that the closest this selection is similar to reality the best the user experience would be.

  • Page 23: Anti-Frost Function

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 12 Anti-frost function In order to prevent the indoor temperature reach freezing points, IntesisHome offers the possibility to set the set point temperature on a special set point. It can be enabled/disabled both: from the App (iOS and Android) and from the web interface. Turns the anti-frost function On/Off This function can be configured only from the web interface, clicking on the gearwheel icon, allowing:...

  • Page 24: Led Status Summary

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng Ambient Temperature Indoor temperature is over protection temperature + hysteresis Then, the IntesisHome device sends: OFF hysteresis (2ºC) protection temperature (15ºC) Time Indoor unit is OFF & anti-frost protection is enabled Then, the IntesisHome device sends: ON, Heat, Set Point & Fan Speed High The anti-frost function includes also some protections such as: ·...

  • Page 25: Led Status During Ir Configuration (Learning Mode)

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng Blinking Connecting to access point and server (up to 2 min) Yellow Blinking Downloading configuration. Wait (up to 2 min) Error Connecting to Access point or router. Try to connect Green Alternate blinking again and make sure you write the correct password.

  • Page 26: Troubleshooting

    ® IntesisHome IS-IR-WIFI-1 User Manual r1.3 eng 14 Troubleshooting 1. Can’t connect the IntesisHome device to my Wi-Fi network If you have problems connecting the IntesisHome device to the Wi-Fi network, please visit the connection section in our FAQ site to get more information about possible problems and solutions.
