ProTalk
TK-3201
UHF FM TRANSCEIVER
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TK-3201 and is the answer not in the manual?

Questions and answers

Related Manuals for ProTalk TK-3201

Summary of Contents for ProTalk TK-3201

  • Page 1 ProTalk TK-3201 UHF FM TRANSCEIVER INSTRUCTION MANUAL...
  • Page 2 HANK We are grateful for your purchase of this KENWOOD product and welcome you to the Private Mobile Radio service (PMR 446). PMR is a mobile communication system for both business and personal use without the need for a license and with no call charges.
  • Page 3 RECAUTIONS • Refer service to qualified technicians only. Do not modify or attempt to adjust this transceiver for any reason. • Do not expose the transceiver to long periods of direct sunlight, nor place it close to heating appliances. • Do not place the transceiver in excessively dusty, humid, or wet areas, nor on unstable surfaces.

  • Page 4: Table Of Contents

    CONTENTS UNPACKING AND CHECKING EQUIPMENT ........1 ............1 UPPLIED CCESSORIES ORIENTATION ..............3 PREPARATION ..............4 ........4 NSTALLING EMOVING THE ATTERY Ni-MH B .......... 5 HARGING THE ATTERY ............7 NSTALLING THE ....7 NSTALLING THE OVER OVER THE PEAKER ICROPHONE ACKS...

  • Page 5: Unpacking And Checking Equipment

    UNPACKING AND CHECKING EQUIPMENT Carefully unpack the transceiver. We recommend you identify the items listed in the following table before discarding the packing material. If any items are missing or have been damaged during shipment, file a claim with the carrier immediately.
  • Page 6 Battery charger AC adaptor (E) AC adaptor (T) Ni-MH battery pack (KNB-29N) Speaker/ microphone Speaker/ microphone jack cover locking bracket Belt clip Screw set...

  • Page 7: Orientation

    ORIENTATION Channel selector Rotate to change the Antenna operating channel from 1 ~ 16. LED indicator Indicates the transceiver Power switch/ status. Lights red while Volume control transmitting, green while Turn clockwise to receiving, and flashes switch the power ON red while the battery and counterclockwise power is low while...

  • Page 8: Preparation

    PREPARATION NSTALLING EMOVING THE ATTERY The battery pack is not charged at the factory; charge it before use {pages 5 and 6}. Average battery pack life (calculated using 5% transmit time, 5% receive time, and 90% standby time) is 16 hours. ◆...

  • Page 9: Attery Ack

    Ni-MH B HARGING THE ATTERY The initial charging of the battery pack after purchase or extended storage (greater than 2 months) will not bring the battery pack to its normal operating capacity. After repeating the charge/ discharge cycle 2 or 3 times, the operating capacity will increase to normal.
  • Page 10 Plug the AC adaptor cable into the adaptor jack located at the rear of the charger. Plug the AC adaptor into an AC outlet. Slide the Ni-MH battery pack or transceiver with a Ni-MH battery pack into the charger. Make sure the battery pack terminals are in contact with the charger terminals by aligning the grooves of the battery pack with the tabs of the...

  • Page 11: Clip

    NSTALLING THE If necessary, attach the belt clip using the two supplied 3 x 8 mm screws. Note: If the belt clip is not installed, its mounting location may get hot during continuous transmission or when left sitting in a hot environment. Do not use glue which is designed to prevent screw loosening when installing the belt clip, as it may cause damage to the transceiver.

  • Page 12: Installing The Optional Speaker / Microphone ( Or Headset )

    NSTALLING THE PTIONAL PEAKER ICROPHONE EADSET Insert the speaker/ microphone (or headset) plugs into the speaker/ microphone jacks. Note: Always switch OFF the transceiver power when installing or removing a speaker/ microphone or headset. Attach the locking bracket using the supplied 3 x 6 mm screw. Note: The transceiver is not fully water resistant while using the speaker/ microphone.

  • Page 13: Getting Started

    GETTING STARTED Turn the Power switch/ Volume control clockwise to switch the transceiver power ON. A beep sounds. Press and hold the Monitor key to hear background noise, then rotate the Power switch/ Volume control to adjust the volume. Rotate the Channel selector to select your desired channel.

  • Page 14: Voice Operated Transmission (Vox)

    VOICE OPERATED TRANSMISSION (VOX) Using the VOX feature, you can operate the transceiver hands-free. In order to use this feature, however, you must use an optional headset; VOX will not function with the built-in microphone. For best operating conditions, we recommend you use an optional headset with both an ear piece and a microphone on a boom that rests in front of your mouth.
  • Page 15 Press the Call key to increase the VOX Gain level and the Monitor key to decrease the level. The VOX Gain can be adjusted from level 1 to level 10 and OFF. The transceiver announces the VOX Gain level as you adjust it. If OFF is selected, the transceiver announces “Off”.

  • Page 16: Vox Operation

    VOX O PERATION Set up a VOX Gain level from 1 to 10 {page 10}. To transmit, simply speak into the headset microphone. You do not need to press the PTT switch; the transceiver automatically detects your voice and begins transmitting. When you begin speaking, a beep will sound, informing you that the transceiver is transmitting.

  • Page 17: Key Functions

    KEY FUNCTIONS The default function of the Call key is Calling Alert. Calling alert tones are used to identify yourself to your party members and inform them that you are about to make a call. Your dealer can set up your transceiver with 1 of 10 different calling alert tones.

  • Page 18: Background Operations

    BACKGROUND OPERATIONS (TOT) IMER The purpose of the Time-out Timer is to prevent you from using a channel for an extended period of time. This function is useful, for example, when you accidentally keep the PTT switch pressed. Additionally, by limiting the amount of time you can continuously transmit, this feature helps you save on battery power consumption.

  • Page 19: Quiet Talk (Qt)/ Digital Quiet Talk (Dqt)

    (QT)/ D (DQT) UIET IGITAL UIET Quiet Talk (QT) and Digital Quiet Talk (DQT) are functions that reject signals from undesired parties that are using the same channel as you. You will hear audio from the speaker only when you receive a signal that contains a QT tone or a DQT code that matches the one set up on the channel you are using.

  • Page 20: Channel Setup Mode

    CHANNEL SETUP MODE This transceiver allows you to reprogram each of the channels with different frequencies and Quiet Talk/ Digital Quiet Talk settings. The table below lists the default channel settings. i t t Note: If you do not select an operating frequency for a channel, you will not be able to select a Quiet Talk/ Digital Quiet Talk setting for that same channel.

  • Page 21: Channel Operating Frequencies

    HANNEL PERATING REQUENCIES To change the operating frequency of a channel: With the transceiver power OFF, press and hold the PTT switch and Call key while turning the transceiver power ON. Continue to hold the PTT switch and Call key until the LED flashes orange one time and the transceiver announces “Self”.
  • Page 22 Press the PTT switch within 5 seconds to save the setting, otherwise the operation will cancel. A beep will sound and the transceiver will announce the new Table number. Repeat steps 3 to 5 to set up another channel. Turn the transceiver power OFF and then ON again to activate the new settings.

  • Page 23: Quiet Talk (Qt)/ Digital Quiet Talk (Dqt) Settings

    (QT)/ D (DQT) S UIET IGITAL UIET ETTINGS To change the QT/ DQT settings of a channel: With the transceiver power OFF, press and hold the PTT switch and Call key while turning the transceiver power ON. Continue to hold the PTT switch and Call key until the LED flashes orange one time and the transceiver announces “Self”.
  • Page 24 Press the Call key to increment the Tone number or the Monitor key to decrement the number, to select the new tone or code. Tone numbers and their corresponding tones/ codes are provided in the table on page 21. Press and hold the Call or Monitor key to increment/ decrement the Tone number by 5 at a time.
  • Page 25 i t t i t t i t t Note: The QT/ DQT settings can be changed by your dealer.

  • Page 26: Channel Confirmation Mode

    HANNEL ONFIRMATION To confirm your channel settings: With the transceiver power OFF, press and hold the PTT switch while turning the transceiver power ON. Continue to hold the PTT switch until the LED flashes orange one time and the transceiver announces “Channel Confirm”. Release the PTT switch.

  • Page 27: Key Assignment Mode

    KEY ASSIGNMENT MODE This transceiver allows you to reprogram the Call and Monitor keys with any of the functions listed in the table below. Explanations on the use of each function are provided on the following pages. i t c n i l ) t l ) t l...
  • Page 28 To change the functions of the Call and Monitor keys: With the transceiver power OFF, press and hold the Call and Monitor keys while turning the transceiver power ON. Continue to hold the Call and Monitor keys until the LED flashes orange one time and the transceiver announces “Setup”.

  • Page 29: Calling Alert

    Press the PTT switch within 5 seconds to save the setting, otherwise the operation will cancel. A beep will sound and the transceiver will announce the new Table number. Turn the transceiver power OFF and then ON again to activate the new settings.

  • Page 30: Key Lock

    Press and hold the key programmed as Key Lock for 1 second to lock/ unlock the transceiver keys. The following keys/ functions can still be used when Key Lock is active: Calling Alert, Key Lock, Monitor, Monitor Momentary, PTT, Squelch Off, Squelch Off Momentary, and Volume. If the key is programmed “with Backup”, when the transceiver power is turned OFF and then ON again, the keys remain locked.

  • Page 31: Scan

    Scan is useful for monitoring signals on the transceiver channels. When scanning, the transceiver checks for a signal on each channel and only stops if a signal is present. If the QT/ DQT matches, the transceiver stops at the channel and opens the squelch so you can listen to the call.

  • Page 32: Revert Channel

    ■ Temporary Delete You can temporarily remove specific channels from the scanning sequence during Scan. When Scan pauses at a channel, you can remove that channel from the scanning sequence by pressing and holding the key programmed as Temporary Delete for 1 second or Scan + Temporary Delete for 3 seconds.

  • Page 33: Scrambler

    CRAMBLER Whereas the Quiet Talk and Digital Quiet Talk functions {page 15} allows you to ignore unwanted calls, Scrambler allows you to hold a conversation in complete privacy. When activated, any other party listening in on your channel will be unable to understand your conversation.

  • Page 34: Optional Accessories

    OPTIONAL ACCESSORIES KMC-17 (Speaker/ microphone) KMC-21 (Speaker/ microphone) KHS-1 (Headset) KHS-21 (Headset) KWR-1 (Water resistant bag)

  • Page 35: Troubleshooting Guide

    TROUBLESHOOTING GUIDE • • e l l . y l l l a • y l t • • s ’ • • l l a ) ’...
