d. TO :
Rm#501 Mario Tower, 222-12, Guro-Dong, Guro-Gu, Seoul, Korea
TFT LCD MONITOR 15"
1. Introduction
VX1500 of slim shape is a TFT Monitor for the industrials which have an analog RGB signal input,
including OSD function for adjusting the optimized display screen, and touch screen, instead of using a
mouse. It is designed for the industrials which using aluminum and Steel chassis with slim type.
2. Specifications
2.1 LCD Monitor Spec
Display Size : 15" TFT Color LCD
-
Active Area(H x W) : 304.1 x 228.1 mm
-
Supporting Resolutions : Full display by zooming out on VGA/SVGA/XGA
-
Driver Element : a-SI TFT active matrix
-
Pixel Arrangement : RGB vertical stripe
-
Display Mode : Normally white
-
Surface treatment : Haze 13, Anti-glare & Hard – Coating (3H)
-
Resolution : 1024 x 768 dots
-
Aspect Ratio : 4:3
-
Max. Colors : 16,777,216 color
-
Pixel Pitch(H x W) : 0.297 x 0.297 mm
-
Luminance(cd/m
-
Contrast Ratio : Typ. 450 : 1
-
Backlight Life Time : Typ. 35,000 Hr
-
Viewing Angel : Typ. Hor. 65°/65°, Ver. 50°/60°
-
Jinyoung Contech Co., Ltd.
TEL : 82-2-890-6400
HOME PAGE :
http://www.jyct.com/
VX1500
- With Touch Screen (Optional)
ifications
2
) : Typ. 250
TFT LCD Monitor : VX1500 1/8
FAX : 82-2-890-6406
Issued Date :
Mar 10, 2003
Ver. 3.0
Page :
8pages
USER'S MANUAL
Advertisement
Related Manuals for Jinyoung Contech VX1500
Summary of Contents for Jinyoung Contech VX1500
- Page 1 - With Touch Screen (Optional) 1. Introduction VX1500 of slim shape is a TFT Monitor for the industrials which have an analog RGB signal input, including OSD function for adjusting the optimized display screen, and touch screen, instead of using a mouse.
- Page 2 800 x 600 56 / 60 / 72 / 75 / 85 1024 x 768 60 / 70 / 75 / 85 compatibles DOS 640 x 350 DOS 640 x 400 DOS 720 x 400 TFT LCD Monitor : VX1500 2/8...
- Page 3 Chemically strengthened glass backing panel Optically bonded buffer layer Transmittance : Typ. > 74% Durability : Point Activation Typ. 1,000,000 Gouge Hardness 4H per ASTM D3363-92a Note : These specifications are subject to change for up-date without notification TFT LCD Monitor : VX1500 3/8...
-
Page 4: Osd Functions
3. OSD Functions Selected Menu Button : Selected SEL Button: Selected Sub item: TFT LCD Monitor : VX1500 4/8... - Page 5 "cancel" and adjust again H-Total Adjust Item Adjust increase/decrease image of horizontal size Phase Adjust Item Adjust data sampling position of image. H-Position Adjust Item Move the image horizontally. V-Position Adjust Item Move the image horizontally. TFT LCD Monitor : VX1500 5/8...
- Page 6 In case of detecting the mode (resolution) that cannot be totally Out of Range supported by LCD. In order to remove the phenomenon, it should be adjusted into the mode (resolution) that can be supported by LCD. 4. Dimensions Introduction TFT LCD Monitor : VX1500 6/8...
- Page 7 * No power Type * Power Type TFT LCD Monitor : VX1500 7/8...
-
Page 8: Packing List
Appendix 1. Packing List LCD Monitor LCD Monitor Manual AC Power Inlet Cable or AC Adapter VGA Cable Supporters, 4PCS Touch Cable (Optional) Touch Screen Install Diskette (Optional) Touch Screen User’s Manual (Optional) TFT LCD Monitor : VX1500 8/8...
