User´s Manual English CONTENTS GENERAL INFORMATION Main Features For your Safety Unpacking General Operation Front Panel Rear Panel INSTALLATION WELCOME PAGE MAIN MENU 1. TV P 10 2. RADIO P 13 3. MULTIMEDIA P 1 4 4. GAME P 1 5 5. -
Page 2: General Information
User´s Manual English GENERAL INFORMATION This Digital Terrestrial Receiver (DTR ) will take you to the new and exciting world of Digital Television . A world of crystal clear widescreen pictures , digital sound , more information and new services . All this and more on "Free to Air" Digital Television . To make full use of your new DTR please take the time to familiarize yourself with the extensive features of the unit detailed in this User's Guide . -
Page 3: For Your Safety P
User´s Manual English SAFETY INSTRUCTIONS ¡WARNING! To prevent the danger of fire or electric shock do not use an extension socket or pin if you can not insert properly. Do not expose the unit to spray water or moisture. • This symbol is intended to Warning: To reduce the risk of electric This symbol is intended to alert the... - Page 4 User´s Manual English 9. Touchdown and Polarization - Note proper precautions. 10. Food - The power cord that came with your device may not be manipulated for a perfect and safe operation. 11. Cleaning - The appliance should be cleaned only in the manner indicated by the manufacturer. 12.
-
Page 5: Unpacking P
User´s Manual English UNPACKING Digital Trrestrial Receiver Remote Control 2 batteries, 1.5V, " AAA " Manual GENERAL OPERATION Throughout this manual you will notice that the everyday operation of the receiver is based on a series of user friendly on screen display and menus . These menus will help you get the most from your receiver , guiding you through installation , channel organizing , viewing and many other functions . -
Page 6: Rcup
User´s Manual English REMOTE CONTROL DTR 126... -
Page 7: Front Panel
User´s Manual English FRONT PANEL REAR PANEL Ant In USB In SCART OUT (VCR) Ant Out SCART In (TV) DTR 126... -
Page 8: Installationp
User´s Manual English INSTALLATION Connected to the antenna main house through the tenna cable Connect a USB device Connect to TV using a SCART cable or EUROCONNECTOR Carries the signal from Connect the device to a the antenna to another video recorder via a device or digital receiver SCART cable or... -
Page 9: Welcome Page
User´s Manual English WELCOME PAGE When power on first time , it will show welcome page like below. Press PR + ,PR - keys to move highlight to select Antenna Setting , Country Setting , OSD Language , Audio Language , Subtitle Language and ,LCN. -
Page 10: Tvp
User´s Manual English This menu has two sub -menus : List -TV Guide 1.1 TV List When you enter “TV List ” menu , the screen will display as below. You can move highlight by pressing [Up /Down ] key and preview the highlighted program in preview window beside the channel list . - Page 11 User´s Manual English 1.1.2 Lock Pressing keys to select the Lock button , and then press PR + ,PR - keys to select the program you want , press OK key on RCU to assign the selected channel with lock mark , the mark will be disappeared if you press OK key again , or press [EXIT ] key to cancel the operation .
- Page 12 User´s Manual English 1.1.6 Skip Pressing keys to select the Skip button , and then press PR + ,PR - keys to select the program you want , press OK key on RCU to assign selected channel with skip mark . hen you can move the selected channel to the position where you want to place it by pressing [Up /Down ] keys .
-
Page 13: Radio
User´s Manual English 1.2 TV Guide TV Guide equals to one electronic program guide , from which you can look up all the programs in a week . The contents shown in this window are provided by the front -ead operator . In main menu , move cursor to TV Guide item and press OK key to enter into this window... -
Page 14: Multimedia
User´s Manual English MULTIMEDIA This menu has three sub -menus : -My Album -My Music -My Movie 3.1 My Album My Album When you enter , the screen will display as beside . You can press PR + ,PR - , keys to move the cursor and choose the pictures , and press OK key to view it in full screen mode . -
Page 15: Game
User´s Manual English GAME When you enter GAME menu like beside you will find the receiver provides a game for you to play . This menu has three sub -menus : -Gomoku -Calendar -Calculator 4.1 Gomoku Choose Gomoku and press [OK ] key to enter . 4.2 Calendar When you enter Calendar menu , the screen will display as beside . - Page 16 User´s Manual English SETUP This menu has six sub -menus : -Installation -TV Setup -Password -Advance Timer -SW Update -Set Default 5.1 Installation When you enter the Installation menu , the screen will display as beside . In this menu , you can press PR + ,PR - keys to select sub -menus and press keys to move highlight to choose your choice .
- Page 17 User´s Manual English 5.3 Password When you enter the Password menu , the screen will display as beside . In this menu , you can press PR + ,PR - keys to select sub - menus and press OK key to enter the menu which is chosen .
- Page 18 User´s Manual English 5.5 Software Update This menu has two sub -menus : -Update by USB -Box to Box 1) Update by USB : Press OK key to pop up the SSU window as beside . You can select the update file in right of the window, and press OK key to start update , if there is no update file in the USB device it will show No file ! 2) Box to Box : Press red key to select the target...
- Page 19 User´s Manual English 6. Keys 6.1 Number Use the numeric keys ( 0 - 9 ) to input the number of the desired channel . If the inputted number is beyond the valid channel number , system will "Invalid number ” and press OK key to close this message 6.2 TV /RADIO In normal mode , press TV /RADIO key to switch between TV mode and Radio mode .
- Page 20 User´s Manual English 6.9 Audio 1. Press keys to enter into the Audio window . 2. Press keys to select sound mode among LL , RR and LR . 3. Press MENU or EXIT key to close this window 6.10 Recall Press key to switch the current channel to the previous channel.
-
Page 21: Trouble Shooting
User´s Manual English TROUBLE SHOOTING There may be various reasons for the abnormal operation of the receiver. Check the receiver according to the procedures shown below. If the receiver does not work properly after checking it ,please contact the dealer. Don't open the receiver cover .It may cause a dangerous situation . - Page 22 User´s Manual English VHF:177,5MHz to 227,5MHz Input Frequency UHF:474 MHz to 858MHz Standard DVB-T (ETSI 300 744) Channel Bandwidth 6MHz, 7MHz, 8MHz Terrestrial OFDM Spectrum Tuner/Demodulator 2k/8k-carrier hierarchical Modulation Mode Guard 64QAM:-78.5dBm～-8.75dBm；16QAM:-84.1dBm～-8.7 Interval Modes FEC Modes Rate 90.3dBm～-8.75dBm Cheertek CT216T/CT216TH Transport DVB Demultiplexer Flash Memory...
- Page 23 User´s Manual English P.G.Technology, S.A. C/ Tormes nº 9 ( Polígono Industrial ) 28840 Mejorada del Campo (Madrid) SPAIN Tel. 902 51 14 06● Fax. +34 91 679 48 91 ● info@npgtech.com ● www.npgtech.com DTR 126...
