Getting Started Guide
• Assembly Instructions
• User Guide
• Table Top Maintenance
• Warranty Information
(800) 445-4559 www.designingfire.com
Fax: 651-305-6347 customerservice@designingfire.com
INSTALLERS:Please leave the instruction manual with the consumer for future reference.
© 2015 Designing Fire, Inc. All Rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Designing Fire Oriflamme RIVER ROCK
Summary of Contents for Designing Fire Oriflamme RIVER ROCK
- Page 1 Getting Started Guide • Assembly Instructions • User Guide • Table Top Maintenance • Warranty Information (800) 445-4559 www.designingfire.com Fax: 651-305-6347 customerservice@designingfire.com INSTALLERS:Please leave the instruction manual with the consumer for future reference. © 2015 Designing Fire, Inc. All Rights reserved...
- Page 2 VERTICAL TANK ASSEMBLY INSTRUCTIONS ALL TABLE TOPS 1. Remove the base and top from packaging 2. Place the four plastic plugs into the four corners at the top of the base. 3. With the help of another person, set the table top on the base so it rests on the four plugs.
- Page 3 4. Take out your burner and notice the venturi tube underneath the burner. Place the burner into the opening of the table and line up the venturi tube with the control valve. Make sure the tube is lined up with the control valve flow. Flex tube can be moved for minor adjustments.
-
Page 4: Additional Instructions
ADDITIONAL INSTRUCTIONS To access your propane tank you must remove the burner by using the burner puller and place burner onto the provided burner stand. Instructions provided. 1. First slide your Venturi tube off the end cap. Find the first burner clip which is located above the control valve. - Page 5 WARNING: If propane is leaking from the fire table, turn off propane tank valve. Use caution as liquid propane can cause frost burn on bare skin. Liquid propane leaks are caused by overfilled USER GUIDE propane tanks. Remove tank and return to propane dealer for proper re-filling. See propane instructions sheet on how to solve.
- Page 6 DIANGONAL TANK ASSEMBLY INSTRUCTIONS ALL TABLE TOPS 1. Remove the base and top from packaging 2. Place the four plastic plugs into the four corners at the top of the base. 3. With the help of another person, set the table top on the base so it rests on the four plugs.
- Page 7 5. Reach your hand through the opening under the control valve and pull the venturi tube over the end cap of the control valve. The tube fits loosely on the end cap for safety and oxygen flow. Simply sliding the venturi tube either direction on the orifice will adjust air/fuel mixture.
- Page 8 ADDITIONAL INSTRUCTIONS To access your propane tank table you must remove the burner by using the burner puller and place burner onto the provided burner stand. Instructions provided. 1. First slide your Venturi tube off the end cap. Find the first burner clip which is located above the control valve.
- Page 9 WARNING: If propane is leaking from the fire table, turn off propane tank valve. Use caution as liquid propane can cause frost burn on bare skin. Liquid propane leaks are caused by overfilled USER GUIDE propane tanks. Remove tank and return to propane dealer for proper re-filling. See propane instructions sheet on how to solve.
-
Page 10: Granite Table Maintenance
TABLE TOP MAINTENANCE GRANITE TABLE MAINTENANCE Granite is a dense, coarse-grained stone and one of the hardest materials on earth. Its luster, hardness, colors and variations are all indications of the stone’ s mineral composition and origin. Most have pits and fissures that are inherent to the stone and are part of its rich natural texture and beauty. - Page 11 SAVANNA/TUSCAN STONE MAINTENANCE The Tuscan stone top achieves the appearance of real stone with the use of Century Stone natural iron oxides and quartz concrete overlay. Each table is hand stained using iron oxides. These oxides are water based colorants, not solid colors like paints.
- Page 12 SANTA FE GENERAL FACTS ABOUT NATURAL SLATE: • Slate is a natural stone and no two pieces are ever alike • Consists of thin layers of stone and as the layers of slate are separated, unique patterns and colors emerge • Natural unevenness and variation in authentic slate which adds to its diversity • Highly resistant to abrasion and cracking • No rusting because of its high purity • Density of slate makes it ideal for outdoors...
- Page 13 HAMMERED COPPER GENERAL FACTS ABOUT HAMMERED COPPER: • Copper is mined and extruded into copper sheets • Sheets are shaped and hammered with a dark acid-etched finish applied • Tops can be formed onto outdoor substrates • 18 gauge copper is used • Special finish is applied to maintain patina MAINTAINING THE HAMMERED COPPER: • Top requires regular wiping with water or mild soapy water with soft cloth • Vinegar, cleaners that contain acid abrasive cleaners or furniture polish should NOT be used • Acidic food and contaminates will cause the table to become brighter but will correct itself throughout time in the elements Upon receiving your new Hammered Copper table seal it with a Carnauba Wax found at your local hardware store.
-
Page 14: Warranty
Designing Fire, Inc. offers a (2) year, (2) year COMMERCIAL, functional warranty only with proper maintenance from date of delivery for all working components of the table such as the control valve and regulator. Designing Fire, Inc. will, at manufacturer’ s option, repair or replace any Designing Fire, Inc. -
Page 15: For Outdoor Use
This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN AN EXPLOSION OR FIRE THAT MAY CAUSE PROPERTY DAMAGE, SERIOUS • Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid burns or... - Page 16 1-800-445-4559 www.designingfire.com...
