LuxCom OM1004 Operating Manual

Ethernet switch three 1000base-x optical ports one 10/100/1000base-t port with rapid spanning tree
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OM1004

Ethernet Switch

Three 1000BASE-X optical ports
One 10/100/1000BASE-T port
With Rapid Spanning Tree

OPERATING MANUAL

REV. 2.5
April 26, 2013
102 WALGREEN ROAD, OTTAWA, ONTARIO, K0A 1L0
Telephone (613) 831-7777
Fax (613) 831-7778
www. luxcom.com
email: sales@luxcom.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OM1004 and is the answer not in the manual?

Questions and answers

Related Manuals for LuxCom OM1004

Summary of Contents for LuxCom OM1004

  • Page 1: Ethernet Switch

    OM1004 Ethernet Switch Three 1000BASE-X optical ports One 10/100/1000BASE-T port With Rapid Spanning Tree OPERATING MANUAL REV. 2.5 April 26, 2013 102 WALGREEN ROAD, OTTAWA, ONTARIO, K0A 1L0 Telephone (613) 831-7777 Fax (613) 831-7778 www. luxcom.com email: sales@luxcom.com...

  • Page 2: Table Of Contents

    Table of Contents Description........................1 Indicators..........................1 Dip Switches........................2 Rapid Spanning Tree Protocol (RSTP)................3 Configuration Interface....................4 OM1004 Main Menu......................4 The main menu is shown below..................4 Bridge RSTP Menu......................6 Software Menu........................7 Specifications*.........................9 Ordering Information.....................10 Certification........................10 Warranty..........................10...
  • Page 3 Manual Revision History Revision 1.0 Initial release Revision 2.0 new format Revision 2.1 Revision 2.2 Revision 2.3 Revise ALARM LED description Revision 2.4 Update spec. for power supply Revision 2.5 auxiliary power supply cube not supplied.

  • Page 4: Description

    A universal AC power supply is built in, while an auxiliary 5V DC input from an external power cube (not supplied) allows for power source redundancy. The OM1004 is enclosed in a rugged metal case for low radiated and conducted emissions. It does not support jumbo packets.

  • Page 5: Dip Switches

    Dip Switches Dip Switches RSTP Up enables Rapid Spanning Tree Protocol (RSTP). See the Rapid Spanning Tree section. Mode Up (software) allows the RSTP to be configured using the Serial Configuration Interface. Down (hardware) sets the RSTP to function in its default settings. Unused Unused Port alarm 1...

  • Page 6: Rapid Spanning Tree Protocol (Rstp)

    (including the RJ45 port) is the preferred path. Alternately the serial Configuration Port on the OM1004 can be used to set the priority of the ports (SW2 up), however this is best avoided unless the user is familiar with RSTP.

  • Page 7: Configuration Interface

    Bits per Second . .= 38400 Data Bits....= 8 Parity ....= None Stop Bits....= 1 Flow control..= Hardware At this point pressing “enter” on the keyboard will bring up the OM1004 management menu. OM1004 Main Menu The main menu is shown below. OM1004 Main Menu...

  • Page 8: Ethernet Menu

    The main menu is shown below. Ethernet Menu The Ethernet menu is shown below: OM1004 Ethernet Menu Show ethernet status Show switch interface and port registers Show switch global registers Show port packet statistics Esc Back :> This menu shows status and statistics for each port. The ports are plug and play, so there are no configuration options.

  • Page 9: Bridge Rstp Menu

    The hardware /software default settings are shown in brackets to the right of each item. Show bridge status Shows status which applies to all ports on the OM1004. Show port status Shows status which applies to individual ports on the OM1004.

  • Page 10: Software Menu

    Esc Back :> This menu allows new software files for the OM1004 to be uploaded with the Xmodem protocol and installed. There are two stored files: PRIMARY and BACKUP. A new upload replaces the previous BACKUP. The PRIMARY file is used for reprogramming the OM1004. BACKUP and PRIMARY can be swapped with the `3' command.
  • Page 11 CRC to checksum mode. In that case, it may be necessary to select the upload file in the first thirty seconds, or defer selecting the upload file until the OM1004 has switched to checksum mode.

  • Page 12: Specifications

    Specifications* Specifications* Optical Model Light Fiber Optical Optical Optical Connectors Source Size Output Sensitivity Range Minimum Maximum 850 nm laser 50/125 µm -9 dBm -18 dBm 550 m SC or ST 850 nm laser 62.5/125 µm -9 dBm -18 dBm 275 m SC or ST 1310 nm laser...

  • Page 13: Ordering Information

    This Luxcom product is warranted against defects in materials and workmanship for a period of five years from the date of shipment. Luxcom will, at its option, repair or replace products that prove to be defective during the warranty period provided they are returned to Luxcom .
