Summary of Contents for Health Vision purecare 982
- Page 1 Advanced Pro. Digital Electric Stimulator User’s Manual Please read this User’s Manual thoroughly before using your digital electric stimulator. TENS MASSAGE SUPER CHANNELS Handheld, Advanced...
-
Page 3: Table Of Contents
Health Vision’s - PL982 Index Page no. 1. Introduction 2. Three Modes- Tens/EMS & Massage 3. General Safety Instructions 4. Machine parts & function keys 6 & 7 5. Machine Operation- Start up 6. 30 Program Overview 7. How to Use Tens/Ems &Massage modes 8. -
Page 4: Introduction
INTRODUCTION Chapter 1 Thank you for purchasing Health Vision PL-982 Digital Electric Stimulator ( TENS/EMS & MASSAGE MACHINE). All of our products undergo rigorous testing to ensure maximum quality. Please read the manual and understand the operation thoroughly before using the Tens machine. - Page 5 application. First one to strengthen the musculature (activating application) and the second one to achieve relaxing resting effect (relaxing application). 3) MASSAGE • Muscle relaxation in order to loosen up muscular tension • Improving muscular fatigue symptoms • Accelerating muscle regeneration after high muscular performance...
-
Page 6: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS Chapter 2 1. Inspect the device before use to 12. Do not use on injured or inflamed skin. ensure that it is in a good condition 13. The device must not be used near the and accessories like--- four eletrodes, heart. - Page 7 22. You should consult your medical doctor if substances, gases or explosive. you have complaints arising as a result of 32. Always remove the electrodes from the stimulation treatment the skin with a moderate pull in order 23. Do not use the device in damp/humid to avoid injury in the event of highly conditions and prevent it from getting sensitive skin.
-
Page 8: Machine Parts & Function Keys 6
Machine parts Chapter 3 Display (main body parts): 1. Modes-Tens/EMS & Massage 2. Program Number 3. Treatment Timer 4. Intensity Indicators 5. Low Battery Indicator 6. Frequency Display 7. Pulse Width Display 8. Body Map Indicator Keys: A. On/OFF B. Menu C. - Page 9 A. ON/OFF key E. Intensity adjust dial (CH1/CH2) 1. Press on-off key to switch on the device. 1. When stimulating, rotate dials clockwise If the key is held down more than 10 to increase intensity and vice versa seconds when switching on, the unit 2.
-
Page 10: Machine Operation- Start Up
OPERATION Chapter 4 Start Up If an admissible key is pressed, there is one short beep. If an inadmissible key is pressed, 1. Press on the battery cover at the back of there are two short beeps. the device and push it to the left side. 2. -
Page 11: Program Overview
Program Overview fiber orientation. If deep tissue layers are to be stimulated the electrodes must be placed The PL-982 unit has a total 30 programs: across to the fiber orientation or cross • 10 TENS programs electrode arrangement. Please see the figure • 10 EMS programs 1 and 2 on page no 19. • 10 MASSAGE programs • In order to extend the durability of the For all programs, you can set the length electrodes, use them on clean skin which of application from 5 minutes to 90 minutes. -
Page 12: How To Use Tens/Ems &Massage Modes
How to use TENS / EMS P1- 8. Select the pulse intensity which is the most comfortable for you by rotating P9, MASSAGE P0-P9 (quick the key CH1+/CH2+. The pulse intensity start) display indicate the strength of the pulse. 9. All keys, including intensity dials, will be 1. -
Page 13: How To Change Settings
How to change the settings Switching Off the Machine- Press and hold the ON /OFF key for 10 Automatic Key Lock Function seconds or till all Graphics disappears. To avoid accidentally change of intensity, PL-982 integrated auto key lock for safety Changing application (completely or purpose. -
Page 14: How To Customize Own Program
Chapter 5 How to use TENS/EMS 7. Using the UP/DOWN keys, select the desired treatment time and confirm with program P0 Only ENTER (Fig. 4). Program P0 is preset program which you can also customize. To customize your own programe follow the following procedure. 1. From the program charts (page 20 & 22), select a program that is suitable for your Fig.1 pain. - Page 15 8. The device is standby for stimulation (Fig. 9. Press ON/OFF to start the stimulation treatment. The operation status display. The graphic will starts flashing (Fig 6) 10. Adjust the pulse intensity which is the most comfortable for you by rotating intensity adjustment dials (CH 1/CH 2). Fig.5 (Fig.
-
Page 16: Maintenance
MAINTENANCE Chapter 5 1. In order to increase the life of the 10. Store the device in a cool, well-ventilated electrodes, they should be cleaned place. carefully with a damp lint free cloth. 11. Never place any heavy objects on the 2. -
Page 17: Problems & Solutions
Problems and solutions pressing the ON/OFF key. Make sure that the connecting leads are properly The device does not switch on when connected to the electrodes. Make sure the ON/OFF key is pressed. What that there is a firm contact between the should I do? electrodes and the treatment area. 1. - Page 18 In case electrodes gives uncomfortable feeling, what should I do? 1. The electrodes are badly positioned. Check positioning and if necessary reposition the electrodes. 2. The electrodes are worn. Due to the fact that current distribution can no longer be guaranteed evenly over the entire surface, these may lead to skin irritation.
-
Page 19: Technical Specification
TECHNICAL SPECIFICATION Chapter 7 MODEL Health Vision PL-982 Digital Electric Stimulator PULSE DURATION 40-300µs PULSE FREQUENCY 1-120 Hz OUTPUT VOLTAGE Max. 90 Vpp (500 0hm) OUTPUT CURRENT Max. 108 mApp (at 500 0hm) BATTERY 3x AAA batteries... -
Page 20: Electrode Placement Guide 18
ELECTRODE PLACEMENT SUGGESTION... - Page 21 1.) Gel pad placed 2.)Gel pad placed stimulates for surface stimulates for deep tissue muscles which white and which white and gray Gray cable are parallel. cables are crosswise.
-
Page 22: Tens Pre Program Settings
TENS PROGRAM Program AREA OF APPLICATION INDICATOR 04,05,06,18,22 Possible Electrode 1. Arm relaxation Position 2. Chest relaxation Cycle 3. Abdominal relaxation W- Width 4. Articulation area 07,20 Frequency 5. Legs relaxation OT- On time Ver nota / See note / 6. - Page 23 Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) 0.25 0.25...
-
Page 24: Ems Pre-Program Settings
EMS PROGRAM Program AREA OF APPLICATION INDICATOR 05,06,18,22 1. Front and back upper arm musculature (Including biceps), front Possible and back lower arm musculature. Electrode Position 2. Pectoral muscle 3. Straight and transverse abdominal musculature Cycle 07,20 4. Front and back upper thigh musculature Width Frequency 5. - Page 25 Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec)
-
Page 26: Massage Pre-Program Settings
MASSAGE PROGRAM AREA OF APPLICATION INDICATOR Cycle 1. Tap and grasp massage Width 2. Knead and grasp massage Frequency OT- On time 3. Tap massage OF- Off time 4. Side of hand/pressing massage application number 5. Side of hand/pressing massage 6. - Page 27 Program Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) Wi(µs) F(Hz) OT(Sec) OF(Sec) 250ms 250ms 250ms 250ms 250ms 250ms 250ms 250ms 250 20~80~20HZ 20Hz 40µs~250µs~40µs 200...
- Page 30 Labeling & Information This product meets the regulations of Directive 93/42 EEC in medical device EU Representative Manufactured by Manufacture Date Attention, see instructions Dispose of the device in accordance with the directive 2002/96/EC – WEEE (Waste Electrical and Electronic Equipment) Application part type BF HIVOX BIOTEK B.V De Run 4428, 5503 LR...
