Summary of Contents for Cosmo CEB-V850ES/FJ3
- Page 1 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual CEB-V850ES/FJ3·SJ3 EVALUATION BOARD HARDWARE USER’S MANUAL Date Published Sep. 2007 (The 1.1 st edition) COSMO Co., Ltd. Control No. CCEB-HUMFJ3SJ3_01_1E...
- Page 2 • No part of this document may be copied or reproduced in any form or by any means without the prior written consent of COSMO Co., Ltd. • COSMO Co., Ltd. does not assume any liability for infringement of patents, copyrights or other intellectual property rights of third parties by or arising from use of device described herein or any other liability arising from use of such device.
-
Page 3: Table Of Contents
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual CONTENTS Overview ..............................1 Document ..............................1 Hardware Specifications ..........................2 Overview ..............................2 Block Diagram ............................. 3 Configuration ............................... 4 3.3.1 Power supply............................5 3.3.2 CAN-I/F ..............................7 3.3.3 LIN-I/F ..............................11 3.3.4 Expansion connectors (J5, J6) ......................14 3.3.5... -
Page 4: Overview
In addition, USB interface, 7-segment LED, CAN interface, LIN interface, N-wire connector, etc. are carried as a common device. Moreover, the CEB-V850ES/FJ3 Evaluation Board can extend a CAN port by two channels by connecting an optional CAN expansion board(CAN-EXT BOARD). -
Page 5: Hardware Specifications
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3. Hardware Specifications 3.1 Overview The specifications of the CEB-V850ES/FJ3·SJ3 Evaluation Board are shown below. • CPU V850ES/FJ3 × 1 (or V850ES/SJ3) ·V850ES/FJ3 Operating CLK direct mode: 6 MHz, PLL mode: 48 MHz Oscillator (MAIN: 6 MHz , SUB: 32.768 KHz ) ·V850ES/SJ3... -
Page 6: Block Diagram
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.2 Block Diagram Whole block diagram V 850ES/ FJ 3 Evaluation Board whole block diagram FL-PR4/ FL-PR5/ MINICUBE2 MINICUBE + 12V C _ POW FJ 3 USB/ UART C _ POW DIPSW 8 bit 7seg 8bit... -
Page 7: Configuration
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3 Configuration The following figure shows the physical placement and the outside of the major components on the CEB-V850ES/FJ3·SJ3 evaluation CPU board. The various components are described below. Figure 3.3 CN1:CAN0(FJ3) CAN1(SJ3), CN2:CAN1(FJ3) CAN0(SJ3), CN3:LIN0, CN4:LIN1... -
Page 8: Power Supply
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.1 Power supply (1) Power supply part Although premised fundamental on use in +12V input from the attached AC/DC adaptor, it is possible to also make it operate by the power supply supply from a USB port. - Page 9 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (2) Power supply connector (CN8) Please use DC jack side of an attached AC adaptor for a power supply connector (CN8), connecting. The power supply to supply is as follows. AC adaptor : NP12-US1210 (Akizuki Denshi Corp)
-
Page 10: Can-I/F
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.2 CAN-I/F (1) CAN-I/F overview Two CAN interfaces are mounted as standard. A block diagram is shown below. CAN transceiver Open setting Open setting Terminator ( TJA 1050 ) jumper jumper Common change jumper JPX2,4... - Page 11 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (2) CAN-I/F connector (CN1, CN2) In the case of CEB-V850 ES/FJ3, CAN0 is assigned to CN1 and CAN1 is assigned to CN2, respectively. In the case of CEB-V850 ES/SJ3, CAN1 is assigned to CN1 and CAN0 is assigned to CN2, respectively.
- Page 12 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (3) CAN transceiver TJA1050T (Philips Corp.) are mounted in this board as a CAN transceiver. Refer to the applicable data sheet for the details of a device. Connection of CPU and a CAN transceiver is shown below.
- Page 13 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (5) About JPX1-JPX4 Although the pattern connects between 1-2 and between 3-4 of JPX1-JPX4, a signal is separable by cutting the pattern on the back side (soldering side) of each jumper. As standard, the following jumper is un-mounting.
-
Page 14: Lin-I/F
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.3 LIN-I/F (1) LIN-I/F outlline Two LIN interfaces are mounted as standard. A block diagram is shown below. + 12V LIN transceiver ( TJA1020) Open setting jumper JPX5 , 8 TXDA* NWAKE RXDA* Master / Slave... - Page 15 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (3) LIN transceiver TJA1020T (Philips Corp.) are mounted in this board as a LIN transceiver. Refer to the applicable data sheet for the details of a device. Connection of CPU and a LIN transceiver is shown below.
- Page 16 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (5) About JPX5-JPX10 Although the pattern connects between 1-2 and between 3-4 of JPX5-JPX8, and between 1-2 of JPX6, JPX9, JPX10, a signal is separable by cutting the pattern on the back side (soldering side) of each jumper.
-
Page 17: Expansion Connectors (J5, J6)
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.4 Expansion connectors (J5, J6) A signal can be pulled out from this connector and it can connect with a user circuit. Moreover, an optional *CAN expansion board is connectable. As standard, it is not mounted. -
Page 18: 7-Segment Led (Led1)
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.5 7-segment LED (LED1) The seven-segment LED is mounted on a board. The LED can be statically switched on the light or put out from the port of CPU. In case you make each segment turn on, please set a corresponding port as "0."... -
Page 19: Reset
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.7 RESET (1) RESET overview When the time of power on or SW4 are pushed, reset starts a board. It is a RESET signal at the MINICUBE or FL-PR4 or FL-PR5 use and MINICUBE2 use time, and composition differs. -
Page 20: Intp0 Sw (Sw2)
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (2)RESET signal setting (JP7) A setup of a RESET signal changes with apparatus connected. JP7 performs a setup. Function 1-2 short circuit Normal use, During connecting FL-PR4, FL-PR5, MINICUBE (Default ) 2-3 short circuit During connecting MINICUBE2 Table 3.3.7 (2) -
Page 21: Clock
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.10 CLOCK (1) Main Clock The crystal oscillator is connected to X1 and X2 terminals of CPU. Oscillation frequency is 6MHz in FJ3, and it is 4MHz in SJ3. Since the socket is mounted, a crystal oscillator is exchangeable if needed. Please purchase a HC49 U/S type crystal oscillator. -
Page 22: Usb
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.11 USB (1) USB overview USB connection with a personal computer is made using the UART interface of CPU. USB-UART interface device FT232R is mounted and USB is changed into UART. The USB section block diagram is shown below. - Page 23 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (2) USB setting With a flash write-in circuit, since P31 (RXD0) is common, please set a jumper (JP8) to the "1-2" side, and perform USB communication. CPU RXD0（P31） 1-2 short circuit TXD of USB connects. (default) 2-3 short circuit TXD of CN5 connects.
-
Page 24: Evaluation Environment
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.12 Evaluation environment (1) Overview The development environment which can be used on this board is as follows. CPU Built-in FLASH writing - FL-PR4, FL-PR5 Debugging - MINICUBE, MINICUBE2 It is designing on the assumption that the four above-mentioned kinds. - Page 25 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (3)MINICUBE and FL-PR4, FL-PR5, MINICUBE2 connection block diagram FL-PR4/FL-PR5/ FJ3/SJ3 MINICUBE・FL-PR4/FL-PR5/MINICUBE2 connection MINICUBE2 (CN5) C-POW USB-TXD Self-program function USB-RXD /RESout ( Communication / control signal block diagram ) SI / RXD C-POW V850ES/FJ3・SJ3 1kΩ SO/ TXD...
- Page 26 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (4) About the CPU interface at the time of CN5 use FL-PR4, FL-PR5 and MINICUBE2(CN5) support only communication by UART for circuit simplification. * “3-wire serial” mode is not supported.Please use FL-PR4, FL-PR5 and MINICUBE2 by “UART” mode.
-
Page 27: The Connector For Minicube (Cn6)
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.13 The connector for MINICUBE (CN6) It is a connector for connecting MINICUBE which is a target CPU debugger. Signal Signal /DRST PORT0 /RESET PORT1 FLMD0 Table 3.3.13... -
Page 28: The Connector For Fl-Pr4, Fl-Pr5, Minicube2 (Cn5)
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.14 The connector for FL-PR4, FL-PR5, MINICUBE2 (CN5) It is a connector for connecting MINICUBE2 which is a target CPU debugger. Moreover, it is as common as the connection connector of FL-PR4 or FL-PR5 which is a FLASH write-in tool with a built-in CPU. -
Page 29: The Connector For Cpu I/O Pins Check
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.3.15 The connector for CPU I/O pins check The through hole for checking each terminal of CPU is arranged around a CPU chip. The column from which the CPU pin number is "-" is not pulled out to the connector for a check. - Page 30 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (3) J3 Signal name CPUpin Signal name CPUpin P912/SCKB2/… P913/INT4/… P914/INT5/… P915/INT6/… PCD0 PCD1 PCD2 PCD3 PCS0/CS0 PCS1/CS1 PCS2/CS2 PCS3/CS3 PCM0/WAIT PCM1/CLKO PCM2/HLDAK PCM3/HLDRQ PCM4 PCM5 PCS4 PCS5 PCS6 PCS7 PCT0/WR0 PCT1/WR1 PCT2 PCT3 PCT4/RD...
-
Page 31: Memory Map
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.4 Memory map (1) V850ES/FJ3 ‘F3380 Built-in FLASH 512KB, Built-in RAM32KB x3FFFFFFH x3FFFFFFH Built-in peripheral I/O area [80KB] x3FFF000H (4KB) x3FEC000H x3FEBFFFH Built-in RAM area (32KB) x3FF7000H Prohibition of use x3FEF000H Prohibition of use Area for AFCAN... - Page 32 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual (2) V850ES/SJ3 ‘F3368 Built-in FLASH 1024kB, Built-in RAM60kB x3FFFFFFH x3FFFFFFH Built-in peripheral I/O area [80KB] x3FFF000H (4KB) x3FEC000H x3FEBFFFH Built-in RAM area (60KB) x3FF0000H Prohibition of use x3FEF000H Prohibition of use Area for AFCAN (12KB)
-
Page 33: Notes At The Time Of User Circuitry
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.5 Notes at the time of user circuitry In adding and connecting a user circuit at an evaluation board, please consider the following notes to the design and manufacture which cannot receive influence of a noise etc. in reference easily. -
Page 34: A Jumper Setup At The Time Of Shipment
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual 3.6 A jumper setup at the time of shipment A setup of the jumper at the time of shipment is as in the following tables. State Function 1-2 OPEN CAN0(FJ3) CAN1(SJ3) no terminator 3-4 OPEN... -
Page 35: Can Expansion Board
(As standard, it is not attached. Moreover, extension of CAN I/F cannot be performed in CEB-V850ES/SJ3.) 4.1 Specifications The CAN expansion board, which expands the number of CAN channels by 2 channels, is used connected to the J5 and J6 connectors of the CEB-V850ES/FJ3. 4.2 Block diagram CAN expansion board (CAN-EXT BOARD) block diagram... -
Page 36: Board Size
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual Board size 65 . 00 Expansion connector （ 30 pin ） 10 . 00 CAN connector [ CAN 2 ] ( 9pin - DSUB ) CAN circuit ( CAN 2 ＆ CAN 3 ) CAN connector [ CAN3 ] ( 9 pin- DSUB ) Expansion connector （... -
Page 37: External Connectors
P96(A6) P70/ANI0 P92(A2) P71/ANI1 P97/SIB1(A7) P65/CTXD2 Expansion CAN(CAN2)TXD P93(A3) P66/CRXD2 Expansion CAN(CAN2)RXD CPOW P94(A4) P67/CTXD3 Expansion CAN(CAN3)TXD _RESET P68/CRXD3 Expansion CAN(CAN3)RXD +12V Table 4.4 * J3 is connected to J5 of CEB-V850ES/FJ3. * J4 is connected to J6 of CEB-V850ES/FJ3. -
Page 38: Evaluation Board Mating
CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual Evaluation board mating The following figure illustrates mating of the V850ES/FJ3 evaluation CPU board and expansion board. 《 》 Longitudinal View FJ3 Evaluation CPU board CAN connector DIPSW DIPSW J6 connector CAN expansion board Expansion CAN connector MINICUBE connector 《... - Page 39 CEB-V850ES/FJ3·SJ3 Evaluation Board HardwareUser’s Manual Revision History Edition Page(s) Description The 1.0 st Apr. 2007 The first-edition issue The 1.1 st Sep. 2007 The 1.1 st edition issue...
