CONTENTS Important Safety Instructions Additional Safety Information Preparations What is Included Front / Rear View Wall Mounting Remote Control Connecting External Devices Operating Your TV Turn On/Off Your TV Setup Wizard Selecting the Input Source Channel Selection Volume Adjustment Customizing TV Settings Navigating the On-screen Display Picture Settings Audio Settings... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Read these instructions – All the safety • Refer all servicing to qualified service and operating instructions should be read personnel. Servicing is required when the before this product is operated. apparatus has been damaged in any way, such •... - Page 5 IMPORTANT SAFETY INSTRUCTIONS AVERTISSEMENT: Afin de réduire les risques d’ incendie ou de choc électrique, veuillez ne pas ex- poser cet appareil à la pluie ou à l’ humidité. Veuillez ne pas exposer l’ appareil au ruissellement ou aux éclaboussures. Veuillez ne jamais poser d’ objets remplis de liquide, tels que des vases, sur l’...
-
Page 6: Additional Safety Information
ADDITIONAL SAFETY INFORMATION To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical Safety • The TV set should only be connected to a main power supply with voltage that matches the label at the rear of the product. -
Page 7: Preparations
PREPARATIONS ELEFW505 15930 Valley Blvd., City of Industry, CA 91744 Warranty Card Initial Assembly Remote Control Guide... -
Page 8: Front / Rear View
PREPARATIONS Front View • • • • •... -
Page 9: Wall Mounting
PREPARATIONS Rear View 1. Power Cord 6. VGA Input Connect to AC power outlet. Connect to a computer or other devices 2. Headphone Socket with a VGA interface. Connect to the Headphones. 7. PC AUDIO Input 3. Optical Audio Signal Output Socket Connect to a computer audio output. -
Page 10: Remote Control
PREPARATIONS Remote Control Power Button USB Button Picture Mode Button ASPECT Button Sleep Button Sound Mode Button Numeric Buttons Channel Setup Button Recall Button Mute Button Volume Adjust Button Channel Selection Button TV Setup Menu Button Signal Source Button MTS Button FREEZE Button Information Button Return Button... - Page 11 PREPARATIONS Remote Control TV Operation Switch the TV between on and standby mode. Mute and restore your TV sound. Select a program (ATV/DTV mode) Enter multiple program channel number , such as 2-1. Return to previous viewing channel. Select picture mode: Dynamic/Movie/Natural/User/Standard/ Energy P.MODE Saving...
-
Page 12: Connecting External Devices
CONNECTING EXTERNAL DEVICES... -
Page 13: Operating Your Tv
OPERATING YOUR TV Turning On/Off Your TV • Connect the power cord to the power socket after you have completed all the physical connections. At this stage, the TV will enter Standby Mode and the red LED indicator will illuminate. •... -
Page 14: Selecting The Input Source
OPERATING YOUR TV • Press the buttons to select your desired mode and press OK button to confirm. Setup Wizard English Menu Language Air/Cable Cable Cable System AUTO Auto Scan Select Exit Move MENU Select your desired language to be displayed on the Menu Language menu. -
Page 15: Customizing Tv Settings
CUSTOMIZING TV SETTINGS Navigating the On-screen Display • Press the MENU button to display the main menu. • Press the buttons to navigate and select the available menus. Picture Picture Picture Mode Energy Saving Contrast Sound Mode Standard Brightness Bass Audio Audio Color... -
Page 16: Picture Settings
CUSTOMIZING TV SETTINGS Picture Settings • Press the MENU button on the main unit or on the remote control then Picture press the buttons to select Picture Mode Energy Saving Picture menu and then press the Contrast Audio Brightness or the OK button to enter. Color •... -
Page 17: Audio Settings
CUSTOMIZING TV SETTINGS Audio Settings • Press the MENU button on the main unit or on the remote control then Picture press the buttons to select Sound Mode Standard Audio menu and then press the Bass Audio the OK button to enter. Treble Time Balance... -
Page 18: Time Settings
CUSTOMIZING TV SETTINGS Time Settings • Press the MENU button on the main unit or on the remote control then Picture press the buttons to select Sleep Timer Time menu and then press the Audio Time Zone Pacific Daylight Saving Time the OK button to enter. -
Page 19: Setup Menu
CUSTOMIZING TV SETTINGS Setup Menu • Press the MENU button on the main unit or on the remote control then Picture Menu Language English press the buttons to select Transparency Setup menu and then press the Zoom Mode Audio Wide Noise Reduction Middle the OK button to enter. -
Page 20: Lock Settings
CUSTOMIZING TV SETTINGS Lock Settings • Press the MENU button on the main unit or on the remote control and then press buttons to select Lock menu. • Use the 0-9 buttons to input 4-digit password to enter the Lock menu. •... -
Page 21: Parental Control
CUSTOMIZING TV SETTINGS Parental Control Press the MENU button on the main unit or on the remote control and then press the buttons to select Lock menu. Use the 0-9 buttons to input 4-digit password to enter the Lock menu. If used, this option feature can "block'' undesirable programming from appearing on the TV. - Page 22 PG-13 greater degree of offensive material suggested Cautioned than a PG rated program. Not for children under 17, strong element of Restricted sex and/or violence. No children under N o t f o r c h i l d r e n u n d e r 1 7 u n d e r a n y...
-
Page 23: Channel Settings
CUSTOMIZING TV SETTINGS Channel Settings • Press the MENU button on the main unit or on the remote control and Picture then press the buttons to select Air/Cable Cable Channel menu. Audio Auto Scan • Press buttons to select the Favorite Time Show/Hide... -
Page 24: Usb Multimedia
USB MULTIMEDIA Viewing Pictures • Press the SOURCE button on the C:\PICTURE\ main unit or on the remote control Phot then press the buttons to select 2010100.jpg 2010100.jpg the USB mode and then press OK 2010101.jpg 2010102.jpg button. 2010103.jpg • Press the buttons to select photo and then press OK button. -
Page 25: Troubleshooting
TROUBLESHOOTING Before contacting the service technician, perform the following simple checks. If any problem still persists, unplug the LED TV and call for assistance. PROBLEM POSSIBLE SOLUTIONS • Check that the main plug has been connected to a wall outlet. •... - Page 26 TROUBLESHOOTING Note:When there is aproblem in VGA mode(only when VGA mode is applied). PROBLEM POSSIBLE SOLUTIONS • Adjust resolution, horizontal or vertical frequency. The signal is out of range • Check whether the signal cable is connected or loose. • Check the input source. Ve r t i c a l b a r o r s t r i p o n t h e •...
-
Page 27: Fcc Notes
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.” Please send all correspondence to: Element Electronics Corp. Customer Service 15930 Valley Blvd., City of Industry, CA 91744 customerservice@elementelectronics.com SPECIFICATIONS Panel Size 49.5 inches diagonally... - Page 28 This product contains electrical or electronic materials. The presence of these materials may, if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on the product means it should not be disposed of as unsorted waste and must be collected separately.
