Euroterm 2116 Installing And Operating Instructions

2132 and 2116
Installing and Operating Instructions
Thank you for choosing the 2132 or 2116 Temperature Controller.
Supplied in 1/32 and 1/16 DIN panel sizes they are designed for
accurate, stable control of ovens, chillers, sterilisers and other
heating and cooling processes. Two outputs are configurable for
heating, cooling and alarms.
D I
IMENSIONS AND NSTALLATION
Model 2132
48mm (1.89in)
24mm
(0.95in)
Latching ears
Model 2116
48mm (1.89in)
48mm
(1.89in)
Latching ears
E C
LECTRICAL ONNECTIONS
Solid
OR
State
Relay
(SSR)
1B 1A
Logic
I/O
Model 2132
1B
1A
-
+
V- V+ AB AA N
T/C Output 2
Relay
Pt100
Neutral
mA
85-264Vac
2.49 Ω
Sensor Inputs
Wire Sizes
The screw terminals accept wire sizes from 0.5 to 1.5 mm (16 to
22AWG). Hinged covers prevent hands or metal making
accidental contact with live wires. The rear terminal screws
should be tightened to 0.4Nm (3.5lb in).
Issue 2, Nov-98. Applies to software versions 1.3 & 1.4
PID Temperature Controllers
103mm (4.01in)
mm
22.22
x 45
Panel cut-out
Inch
0.88
Panel retaining clips
x 1.77
103mm (4.01in)
Panel cut-out
45 x 45 mm
1.77 x 1.77in
Panel retaining clips
External Relay Module
(Operated by the logic output)
L
20-29 Vac/dc
24 24
Line
Low voltage supply
The controller is supplied configured according to the order code
given on page 11. Check this on the side labels to determine the
configuration of your particular controller.
This controller meets the European Directives on safety and
EMC.
To Install the Controller
Please read the safety information on pages 11 & 12 before
proceeding.
1. Prepare the panel cut-out to the size shown
2. Insert the controller through the cut-out.
3. Spring the panel retaining clips into place. Secure the
-0.0, +0.3
-0.0, +0.6
controller in position by holding it level and pushing both
retaining clips forward.
4. Peel off the protective cover from the display
-0.0, +0.10
Unplugging the Controller
-0.0, +0.02
The controller can be unplugged from its sleeve by easing the
latching ears outwards and pulling it forward out of the sleeve.
When plugging it back into its sleeve, ensure that the latching ears
click back into place to maintain the IP65 sealing.
-0.0, + 0.6
-0.00, +0.02
10mm
(0.4 in)
External Relay Module
(Operated by the logic output)
OR
Solid
State
Relay
(SSR)
Output ratings
Logic Output: 9Vdc, 12mA (non-isolated from sensor input).
Used for: Heating, Cooling or Alarm.
Relay Output: 2A, 264V ac resistive.
Used for: Heating, Cooling or Alarm.
Contact Closure Input (replaces Logic Output).
Used for: Alarm Acknowledge or Timer start/reset
-1-
Recommended minimum
spacing of controllers in
both sizes
38mm
(1.5 in)
(Not to
scale)
Model 2116
L
Line
85-264Vac
N
Neutral
AA
AB
1A
+ V+
Logic
I/O
1B -
V-
T/C Pt100 mA
24
24
20-29V ac/dc
Low voltage
supply
Output 2
Relay
2.49 Ω
Sensor Inputs
HA026270
