Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
- The Foodprocessor is equipped with mechanical and
thermal safety switches.
Materials used:
- Food processor bowl and lid, : SAN
blender jar & safety lid
- Pushers, blender lid,
inlay bowl handle
- Housing, Screw cap
- Safety lever blender jar
- Feeding tray, sausage horn
- Kneading accessory
- Toolholder bowl,
sausage seperator
- Balloon beater
- Grip blender jar
- Food processor knifes
- Food processor discs
- Cutter, grinding discs
- Meat mincer processing tube, : Alu - alloy
worm shaft :
- Fruit filter
Colours:
- White with vapor dusk grey accents, clear transparent
bowl & jar, brushed stainless steel screw cap and control
panel.
Published by Philips Domestic Appliances and Personal Care
05/11
Essence
: PP
: Stainless steel, PP
: PC
: ABS
: PP / 30% chalk,
stainless steel
: POM
: POM, Alu,
stainless steel
: ABS
: Stainless steel / PP
: Stainless steel / POM
: Metal
: PP, stainless steel (mesh)
Printed in the Netherlands
TECHNICAL INFORMATION
- Motor
: universal, radio / TV interference
suppressed
- Power consumption
: 800 Watt max.
- Voltage & frequency : 230 V, 50 Hz
- Cordset
: 100 cm, double insulated with
moulded on plug
- Speed setting
: 2 speeds + pulse
- Bowl capacity
: 2.5 L dry ingredients, 1.7 L liquids
- Blender capacity
: total jar capacity 2.0 L,
- Speeds unloaded
: blender drive shaft 19500 rpm (max)
accessories drive shaft 2150 rpm
(max at speed 2 + pulse)
accessories drive shaft 1700 rpm
(min at speed 1)
- Weight in fancy box : 7.0 kg
- Dimensions
: 395 x 380 x 398 (mm)
fancy box (l x w x h)
Safety:
- Automatically resettable : protects motor against
thermal cut out
- Built - in safety lock
: detects wheter lid & bowl are
- Motor brake system
: stops the appliance within
- This product meets the requirements regarding interference
suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as officially
laid down at this moment.
© Copyright reserved
Foodprocessor
HR7765
1.5 L effective
overheating
assembled
1.5 seconds
Subject to modification

Advertisement

loading

Summary of Contents for Philips Essence HR7765

  • Page 1 - After the product has been repaired, it should function properly and has to meet the safety requirements as officially laid down at this moment. Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved...
  • Page 2: Repair Instructions

    HR7765 DISASSEMBLY- AND RE-ASSEMBLY ADVISE - The blender coupling on the motor shaft has been provided Safety lock (item 7) with a customary left-handed thread. Place the lid on the bowl in the right position. The appliance The drive coupling (item 10) can be detached by means of will only function if the line on the applinace is directly a hammer and a screwdriver.
  • Page 3: Parts List

    PARTS LIST HR7765 Service code Description Service code Description 4203 065 65810 Blender cap 4203 065 63800 Pusher closed bowl 4203 065 63620 Screw cap 4203 065 63760 Bowl lid 4203 065 65950 Top housing 4203 065 63770 Lid bearing 4203 065 60630 Switch Assy 4203 065 63780...
  • Page 4 EXPLODED VIEW HR7765...
  • Page 5 EXPLODED VIEW HR7765...
  • Page 6 EXPLODED VIEW HR7765...
  • Page 7 EXPLODED VIEW HR7765...
