Page 1: Table Of Contents
Includes/What’s in the Box Introduction Quick Setup Guide & Product Features Setup Apple or Android App ASP4 Installation Instructions Playback Specifications FAQ and Troubleshooting Pictures Warranty & Disclaimers KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 2: Warning & Precautions
/electronic equipment for recycling. This electronic device should not be disposed of in regular trash. We strongly advise you to contact your local authority for proper disposal of this product. KJB Security www.mysleuthgear.com 800-590-4272... -
Page 3: Includes/What's In The Box
5. Remote 6. Power Supply QUAD LCD Version 1. Receiver 2. Remote 3. RCA Cables 4. Receiver Brackets 5. USB Cable 6. Antenna 7. Power Supply KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 4: Introduction
Introduction: Xtreme Life Wireless QUAD/QUAD LCD Thank you for purchasing the Xtreme Life Wireless QUADs, with a Digital Wireless Receiver and built in DVR Recording Systems capable of recording on to an SD card, and has a USB to PC interface that enables Direct to PC Video Recording and Remote Video Access. -
Page 5: Quick Setup Guide & Product Features
• Free Mobile Application (Apple, Android) • When Privacy Matters our Completely Concealed Cameras Hide in Plain Sight • No Visible Wires • 1 Year Manufacture Warranty KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... - Page 6 4. To pair additional cameras press the pair button and quickly release it to change the receiver channel. Then repeat pairing process from step 3 on a new channel. Fig 1 Fig 2 KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
-
Page 7: Setup
LCD screen or monitor . When using / viewing ASP4 software, the camera images will freeze. The next time the PIR detects IR and triggers the transmitter, the image will resume transmitting video. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 8: Remote Control
Key Lock Number 2 & “A B C” Channel 3 & Number 3 & “D E F” Channel 4 & Number 4 & “G H I” KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... - Page 9 REC LED (Green) Mini USB Port Antenna SD Slot (SMA Reverse) Speaker Power Button Power LED (Red) QUAD View/Single Power Socket CH Switching Button Alarm Out Pairing Button KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
- Page 10 PC). * If in an office setting please consult your IT department when installing the ASP4 software. The company network could have a firewall that blocks ASP4 from sending video to the EZ-See website. KJB Security www.mysleuthgear.com 800-590-4272...
-
Page 11: Receiver Menu
Full stop - will stop recording when the card is full. Overwrite - will delete the oldest file when the card is full and replace with new recording files. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 12: Peripheral Setup
Motion Detect - the buzzer will sound when motion is detected. Buzzer Duration - sets the amount of time the buzzer will sound. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 13: System Setup
(camera) will show on the screen before switching to the next channel (camera). To place the monitor in sequence mode, press the Sequence button on the remote. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 14: Factory Default
Brightness Setup Brightness Setup - change the level to increase or decrease the brightness of the QUAD LCD display’s image. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 15: Apple Or Android App
Apple or Android App Open the App Store and search for “EZ-See” to download the app. Phone Tablet KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... - Page 16 Select the receiver ID Watch live stream video KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
-
Page 17: Asp4 Installation Instructions
4. To create a shortcut to the software on your desktop find the installation location of the software. Right click ASP4 and go to send to and select Desktop. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... - Page 18 CH2 Full screen display CH3 Full screen display CH4 Full screen display QUAD-View display Manual recording during Backwards live view & backup files during playback Pause Forwards Stop Play KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
- Page 19 Use Internet Explorer or Google Chrome to log in and access the video live stream by typing in the link to the address bar of the web browser. Click “OK” to save the settings after they have been changed. KJB Security www.mysleuthgear.com 800-590-4272...
- Page 20 2. If user name and password are correct, ASP4 browser plugin will launch and the live video stream will appear. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
-
Page 21: Playback
OK on the remote. During video play back press the up or down arrows to move to the next video. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 22: Specifications
Additional Specifications for Xtreme Life product line only PIR Motion Sensor Yes - Trigger for recording Battery Life Up to 30 days in standby; Up to 8 hours continuous KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 23: Faq And Troubleshooting
No, it only works with Microsoft OS up to Windows 7. Q. Does this work with Windows OS 8? No, it works up to Windows OS 7. KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... -
Page 24: Pictures
Pair Button Location Clock Radio Air Purifi er Pairing Button Pairing Button KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear... - Page 25 Pair Button Location Book Camera Pairing Button KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
- Page 26 Pair Button Location Smoke Detector Pairing Button Rectangle Clock Pairing Button Pairing Button KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
- Page 27 Pair Button Location Mantle Clock Pairing Button Teddy Bear Pairing Button Pairing Button Wall Clock KJB Security www.mysleuthgear.com 800-590-4272 Find us on Facebook at facebook/sleuthgear and on Twitter @sleuthgear...
-
Page 28: Warranty & Disclaimers
RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTIONS AGAINST HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION. THIS EQUIPMENT USES, GENERATES AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH INSTRUCTIONS, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. KJB Security www.mysleuthgear.com 800-590-4272...
