Wall mounting example
Put•the•clock•in•the•location•where•you•want•to•use•it.
Important!
After hanging the clock onto a hook, screw, etc., move the
O
QQ
clock upwards, downwards, left, and right, and pull lightly
towards you to make sure it is secure. A clock that is hung
in a way that is not secure can fall and cause accidents.
Make sure that the clock is straight while hanging, and is
QQ
O
not at an angle.
OK
12
11
1
10
2
9
3
8
4
7
5
6
Screw•diameter:•4•to•5•mm
Wall
10mm
Screw
Screw•head•diameter:•6•to•8•mm
Important!
Be sure to use a screw that is strong enough to support
O
QQ
the weight of the clock.
Operation Guide ITM-461
NG
••
5
