Summary of Contents for Hoei Precision DSR-4000dp
- Page 1 HOEI PRECISION DESKTOP CD/DVD DUPLICATOR DSR-4000dp DSR-4000dp-5-MX / DSR-4000dp-10-MX USER’s MANUAL Rev 2.0...
- Page 2 Thank you for your purchase of the DVD duplication system “DSR-4000dp”. Read this user’s manual thoroughly to understand the use and operation of the “DSR-4000dp”. These specifications are subject to change without prior notice due to functional improvements. DSR-4000dp User’s Manual Copyright 2003 by HOEI SANGYO Co.,Ltd.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Names and Functions..........................5 Operation Panel............................7 Notes for handling........................... 10 Power supply............................10 Installation Notes ..........................11 Installation space..........................12 Unpacking ............................13 Maintenance............................13 Transportation ............................13 How to operate the DSR ......................... 14 Operation Panel............................ 14 Turning on/off the power ........................ - Page 4 Display the firmware version (F/W VERSION)................40 Disc Erase ............................41 Error during the process........................42 PRV-LX1..............................43 How to connect with PRV-LX1 ......................43 How to start............................44 How to shut down ..........................44 How to use ............................45 Register to HDD from PRV-LX1 (ToHD) ..................
-
Page 5: Names And Functions
Names and Functions Names and functions are as follows: Front panel (DSR-400dp-5-MX: Master Unit) Operation panel A drive / LED B drive / LED C drive / LED D drive / LED Master DVD-ROM drive / LED Power switch Operation panel : There are LCD (liquid crystal display) to show the status of the DSR and switches to set functions (Refer to “Operation Panel”). - Page 6 Front panel (DSR-4000dp-10-MX: Master Unit) Operation panel A drive / LED B drive / LED C drive / LED D drive / LED E drive / LED F drive / LED G drive / LED H drive / LED Master DVD-ROM drive...
-
Page 7: Operation Panel
Operation Panel LCD (Liquid Crystal Display) Yes Switch No Switch LCD (Liquid Crystal Display) : It shows status messages of the DSR. Yes Switch : To execute each selected mode/menu. No Switch : To select each mode/menu. - Page 8 Rear Panel (DSR-4000dp-5-MX: Master Unit) AC outlet 115/230V switch AC inlet USB connector NET IN connector NET IN NET ID NET ID switch NET OUT NET OUT connector AC outlet : It turns on/off the power, interlocking with the power switch.
- Page 9 Rear Panel (DSR-4000dp-10-MX: Master Unit) AC outlet 115/230V switch AC inlet USB connector NET ID N ET I N NET ID switch N ET O U T NET IN connector NET OUT connector AC outlet : It turns on/off the power, interlocking with the power switch.
-
Page 10: Notes For Handling
Be sure to each the DSR to prevent an accident due to electricity leakage. ・ For grounding, use a 3P outlet or an earth cord from the 3P-2P conversion connector. ・ Moving The DSR-4000dp-5 weights about 16kg. The DSR-4000dp-10 weights about 25kg. Move it very carefully. Caution... -
Page 11: Installation Notes
Notes for Handling Installation Notes Install the DSR in the following conditions: in a level and stable place ・ ・ in an airy place Temperature and humidity ・ ℃ Temperature: 5-40 Humidity: 20-80%RH (no dew formation) Do not install it in the following places: ・... -
Page 12: Installation Space
Notes for Handling Installation space The dimensions of the DSR-4000dp-5-MX are as follows: ４６５ ８０ ８０ ３３２ ６５ ６８ １００ １００ ２００ The dimensions of the DSR-4000dp-10-MX are as follows: ４ ６ ５ ８ ０ ８ ０ ３ ３ ２... -
Page 13: Unpacking
Make sure that the following items are included in the package and there is no damage on the DSR and accessories. Part Name Part No. DSR-4000dp Power cable Instruction manual If anything is missing, please contact the agent where you purchased the DSR... -
Page 14: How To Operate The Dsr
How to operate the DSR Operation Panel The DSR works by using the switches on the operation panel. The LCD and LED indicate the status of the DSR. Refer to “Names and Functions of Devices” (Introduction) for details. LCD (Liquid crystal display) It shows the status of the DSR in the normal mode. -
Page 15: Turning On/Off The Power
Turning on the power 1. Press the power switch on the lower right corner on the DSR 2. DSR begins initializing. DSR-4000 HOEI PRECISION Ver X.XX 3. DVD copy function displays after initializing. CD DUPLICATOR If the power is not properly turned on, refer to “Error message” to take proper procedures. -
Page 16: Main Menu
Main menu Select a main menu of DSR you want to use after powering on. DSR boots up the main menu you used last time except UTILITY. Main menus of DSR are as follows: CD DUPLICATOR: You can use the DSR as a standalone CD duplicator. Please refer to “Section 3. -
Page 17: Cd Duplicator
*1 Cannot verify the multi session unless CD-ROM mode 1 or CD-ROM XA form 1. CD-DA Due to the specification of writer installed in the DSR-4000dp, the ISRC and catalogue code do not support even if they are included in the master disc. -
Page 18: Basic Operations For Cd
Basic Operations for CD Copy from disc to disc (CDtoCD) 1. For copying from CD to CD, press the YES switch after confirming the CD main screen as follows. COPY START? COPY START? (DVDtoDVD) (FAST) Notice: It is explained as Copy mode. If you want to change mode, refer to “Setup of CD, Select the mode (MODE SELECT)”. If the master is HDD (displayed “HDtoCD”... -
Page 19: Register The Master Disc (Cdtohd)
Register the master disc (CDtoHD) 1. Start from the CD main screen. No matter which mode/master is selected. Press the NO switch. COPY START? COPY START? (CDtoCD) (FAST) 2. Press the YES button in the master selection screen as follows. MASTER SELECT? 3. - Page 20 CD DUPLICATOR (2). Data already registered in the area you select: Format and capacity of data in the HD area are displayed. Press the YES button to register the master data. To DVD AREA1? To CD AREA1? (CDtoHD) (CD-DA 15:26 Data already registered is overwritten.
-
Page 21: Copy From Hdd To Dvd (Hdtocd)
Copy from HDD to DVD (HDtoCD) 1. Start from the CD main screen. No matter which mode/master is selected. Press the NO button. COPY START? COPY START? (DVDtoDVD) (FAST) 2. Press the YES button in the master selection screen as follows. MASTER SELECT? 3. -
Page 22: Select The Mater Drive
Select the mater drive Selection of master drive which you want to copy from HDD or CD. Master data is supposed to be already registered in the HD area. If it is not, refer to “Register the master disc (CDtoHD)”. 1. -
Page 23: Simulation Copy (Simulation)
Simulation copy (SIMULATION) Simulation is can be a good way to test the system or reliability of master discs. Operation for simulation is exactly same as Copy, but DSR does not record on a blank disc. 1. Press the NO button twice in the CD main screen. COPY START? COPY START? (CDtoCD) -
Page 24: Setup Of Cd (Setup)
Setup of CD (SETUP) SETUP is the menu to change each setup and screen. You can change MODE SELECT, WRITE SPEED and display DRIVE INQUIRY, and F/W VERSION. Change and set each mode There are three modes for CD. * COPY--------------------------------------- Copy the data from master drive to blank disc. -
Page 25: Select The Write Speed (Write Speed)
Select the write speed (WRITE SPEED) Select speed to copy. Write speed may vary depending on a target drive installed in DSR. WRITE SPEED FAST MEDIUM SLOW Disc CD-R CD-RW * Use a compatible disc for each writing speed. 1. In the CD main screen, please the NO button three times to display the SETUP screen. COPY START? COPY START? (CDtoCD) -
Page 26: Display The Drive Inquiry String (Drive Inquiry)
Display the drive inquiry string (DRIVE INQUIRY) DSR displays model number and firmware version of HDD, DVD-ROM drive and DVD-RW drives installed in DSR. 1. In the CD main screen, please the NO button three times to display the SETUP screen. COPY START? COPY START? (CDtoCD) -
Page 27: Display The Firmware Version (F/W Version)
Display the firmware version (F/W VERSION) DSR displays its firmware version, hardware version, and total number of disc you copy so far. 1. In the CD main screen, please the NO button three times to display the SETUP screen. COPY START? COPY START? (CDtoCD) (FAST) -
Page 28: Disc Erase
Disc Erase Disc erase can erase data on DVD-RW media simultaneously. There are Full Erase (FULL ERASE) and Quick Erase (QUICK ERASE) for erasing. FULL ERASE: All data on a CD-RW disc is erased. It takes about 20 minutes. *depending on a type of target writer and a type of CD-RW disc QUICK ERASE: Only TOC (Table of Contents) on the CD-RW disc is erased. -
Page 29: Error During The Process
Error during the process During Copy/Verify When an error is occurred during Copy or Verify, the status LED beside the drive with error flashes. Other drives basically continues its process; however, there is a case which all of drives are failed because of the drive with error. After Copy/Verify Media completed is automatically unloaded. -
Page 30: Dvd Duplicator
DVD DUPLICATOR Notice for DVD The followings are notices for operations of DVD with the DSR. Format Supported DVD formats by DSR are as follows: COPY VERIFY DVD-ROM ○ ○ DVD-R (*1) ○ ○ DVD-VIDEO ○ ○ *1 Format not supported by DSR on DVD-R cannot be used. Media DVD-RW drive in DSR is For General. -
Page 31: Basic Operations For Dvd
Basic Operations for DVD Copy from disc to disc (DVDtoDVD) 1. For copying from DVD to DVD, press the YES switch after confirming the DVD main screen as follows. COPY START? COPY START? (DVDtoDVD) (FAST) Notice: It is explained as Copy mode. If you want to change mode, refer to “Setup of DVD, Select the mode (MODE SELECT)”. If the master is HDD (displayed “HDtoDVD”... -
Page 32: Register The Master Disc (Dvdtohd)
Register the master disc (DVDtoHD) 1. Start from the DVD main screen. No matter which mode/master is selected. Press the NO switch. COPY START? COPY START? (DVDtoDVD) (FAST) 2. Press the YES button in the master selection screen as follows. MASTER SELECT? 3. - Page 33 (2). Data already registered in the area you select: Format and capacity of data in the HD area are displayed. Press the YES button to register the master data. To DVD AREA1? To DVD AREA1? (DVDtoHD) (DVD-VIDEO 4.1G) Data already registered is overwritten. Press the YES button to start registration.
-
Page 34: Copy From Hdd To Dvd (Hdtodvd)
Copy from HDD to DVD (HDtoDVD) 1. Start from the DVD main screen. No matter which mode/master is selected. Press the NO button. COPY START? COPY START? (DVDtoDVD) (FAST) 2. Press the YES button in the master selection screen as follows. MASTER SELECT? 3. -
Page 35: Select The Mater Drive
Select the mater drive Selection of master drive which you want to copy from HDD or DVD. Master data is supposed to be already registered in the HD area. If it is not, refer to “Register the master disc (DVDtoHD)”. 1. -
Page 36: Simulation Copy (Simulation)
Simulation copy (SIMULATION) Simulation is can be a good way to test the system or reliability of master discs. Operation for simulation is exactly same as Copy, but DSR does not record on a blank disc. 1. Press the NO button twice in the DVD main screen. COPY START? COPY START? (DVDtoDVD) -
Page 37: Setup Of Dvd (Setup)
Setup of DVD (SETUP) SETUP is the menu to change each setup and screen. You can change MODE SELECT, WRITE SPEED and display DRIVE INQUIRY, and F/W VERSION. Change and set each mode There are three modes for DVD. * COPY--------------------------------------- Copy the data from master drive to blank disc. -
Page 38: Select The Write Speed (Write Speed)
Select the write speed (WRITE SPEED) Select speed to copy. Write speed may vary depending on a target drive installed in DSR. WRITE SPEED FAST MEDIUM SLOW Disc DVD-R DVD-RW * Use a compatible disc for each writing speed. 1. In the DVD main screen, please the NO button three times to display the SETUP screen. COPY START? COPY START? (DVD to DVD) -
Page 39: Display The Drive Inquiry String (Drive Inquiry)
Display the drive inquiry string (DRIVE INQUIRY) DSR displays model number and firmware version of HDD, DVD-ROM drive and DVD-RW drives installed in DSR. 1. In the DVD main screen, please the NO button three times to display the SETUP screen. COPY START? COPY START? (DVD to DVD) -
Page 40: Display The Firmware Version (F/W Version)
Display the firmware version (F/W VERSION) DSR displays its firmware version, hardware version, and total number of disc you copy so far. 1. In the DVD main screen, please the NO button three times to display the SETUP screen. COPY START? COPY START? (DVD to DVD) (FAST) -
Page 41: Disc Erase
Disc Erase Disc erase can erase data on DVD-RW media simultaneously. There are Full Erase (FULL ERASE) and Quick Erase (QUICK ERASE) for erasing. FULL ERASE: All data on a DVD-RW disc is erased. It takes about 20 minutes. *depending on a type of target writer and a type of DVD-RW disc QUICK ERASE: Only TOC (Table of Contents) on the DVD-RW disc is erased. -
Page 42: Error During The Process
Error during the process During Copy/Verify When an error is occurred during Copy or Verify, the status LED beside the drive with error flashes. Other drives basically continues its process; however, there is a case which all of drives are failed because of the drive with error. After Copy/Verify Media completed is automatically unloaded. -
Page 43: Prv-Lx1
Here is the description about the PRV-LX1 feature. Supported product and firmware version Here is the product name supporting the PRV-LX1 feature and its firmware version 1. Pioneer PRV-LX1 Firmware ver2.04 or later 2. HOEI SANGYO DSR-4000dp-5 DSR-4000dp-10 Firmware verX.XX or later Media Media you can use for this PRV-LX1 feature is a blank DVD-R or DVD-RW disc only. -
Page 44: How To Start
Here is the description how to start the PRV-LX1 feature after connecting the USB 2.0 cable. Press the power switch on the lower right corner on the DSR DSR begins initializing. DSR-4300 HOEI PRECISION Ver X.XX CD copy function displays after initializing. Or any other function you used last time displays. -
Page 45: How To Use
How to use DSR can record a DVD-VIDEO image to the multiple DVD-R/RW discs simultaneously from the Pioneer PRV-LX1 directly via the USB2.0. It is not only able to record to the disc directly, but also register the image to HDD in the DSR. Here is the description how to use the PRV-LX1 function. -
Page 46: Register To Hdd From Prv-Lx1 (Tohd)
Register to HDD from PRV-LX1 (ToHD) Here is the description how to register DVD-VIDEO image data to HDD in DSR from PRV-LX1. 1. Check if the DSR is standby of PRV-LX1 function as the following screen. STANDBY OK! To DVD? If the LCD shows any different screen, please refer to “How to start”... -
Page 47: Trouble Shooting
Trouble shooting Check the following items if the PRV-LX1 function does not work properly. If the symptom is not solved even after checking, contact with the reseller of DSR. Symptom Checking Item DSR is not powered on. Check if the power cable is properly connected with the DSR. Check if the power is properly supplied by the cable connected with the DSR. -
Page 48: Utility
You can select the UTILITY mode in the main menu. 1. Turn on DSR. 2. DSR initializes and displays firmware version. DSR-4000 HOEI PRECISION Ver 2.02 3. The DVD DUPLICATOR screen appears after initializing. DUPLICATOR? 4. Press the NO button to select the UTILITY screen. -
Page 49: Hdd Format
HDD FORMAT HDD FORMAT is a feature to format the HDD in DSR. DSR has a larger than 30GB. How to use HDD FORMAT 1. Press the YES button in the HDD FORMAT main screen. HDD FORMAT? 2. Select your requested number of CD area & DVD area by pressing the NO button. Press the YES button to decide. CD: 1 DVD:2? Available number of area Default... -
Page 50: Network
NETWORK How to connect the units Here is the explanation how to connect the units for the NEWWORK feature. In the NETWORK feature, there are two kinds of DSR, the master unit distributing the master data and the slave unit receiving the data. -
Page 51: Power On And Network Ready
Power on and NETWORK READY 1. After setup of NET ID and connecting cables, turn on each DSR. For the master unit, please wait until the LCD displays the following messages. NETWORK CHECK 02 Number of slave unit connected PRESS In this case, two slave units are connected. -
Page 52: Operations Of Network
Operations of NETWORK Distribute the master data from the master disc to the slave unit (CD/DVDtoNET) Here is the explanation how to distribute the master data from the reader of master unit to the slave unit. The master data will be registered in the HD area: 02 in the master &... -
Page 53: Distribute The Master Data From The Master Hd To The Slave Unit (Hdtonet)
Distribute the master data from the master HD to the slave unit (HDtoNET) Here is the explanation how to distribute the master data already registered in the HD of master unit to the slave unit. Set the master disc to the reader of master unit. If blank disc (s) is also inserted in the writer (s) of master & slave units, COPY/VERIFY is automatically started after the master data distribution. -
Page 54: Copy/Verify After The Master Distribution
8. Here is the main screen. Press the YES button to start the distribution. COPY START? COPY START? COPY START? (HD:07 to NET) (DVD VIDEO 3.8G) (FAST) 9. Displays during the distribution are as follows. <Master unit> <Slave unit> DISTRIBUTE 4.5G NET SLAVE VIDEO NETWORK BUSY... -
Page 55: Troubleshooting
Troubleshooting Symptom Checking Item Power is not turned to ON. * Check if the cable is connected to the unit and the respective inlet correctly. * Check if the power is supplied by connecting the cable to the inlet of other equipment. * Check if the power switch is set to the ON position completely. -
Page 56: Error Message
DSR starts to initialize and boot up with a new firmware version. Error message System Message Checking Item ? NO PROGRAM Firmware (program) does not exist in DSR. * Load the firmware CD for DSR. # NO SYSTEM DATA System data does not exist. It usually occurs when the system is unstable. * Reboot DSR or call your reseller. -
Page 57: Others
Others Errors come from DSR and also from each drive in DSR as the error code. Refer to “Appendix A Error Code” for details about error codes. Explanation of displaying error code as follows: Example 1) Read error with the read drive ERROR MASTER CODE 11 05 11 --- ASC (Additional Sense Code) -
Page 58: Error Code List
Error Code List Read drive ASCQ Description CLEANINF REQUESTED NO INDEX/SECTOR SIGNAL NO SEEK COMPLETE LOGICAL UNIT IS IN PROCESS OF BECOMING READY LOGICAL UNIT NOT READY, INITIALIZING CMD. REQUESTED LOGICAL UNIT NOT READY, OPERATION IN PROGRESS NO REFERENCE POSITION FOUND (medium may be upside down) TRACK FOLLOWING ERROR TRACKING SERVO FAILURE FOCUS SERVO FAILURE... -
Page 59: Write Drive
COPY PROTECTION KEY EXCHANGE FAILURE - KEY NOT ESATBLISHED READ OF SCRAMBLED SECTOR WITHOUT AUTHENTICATION MEDIA REGION CODE IS MISMATCHED TO LOGICAL UNIT REGION DRIVE RESION MUST BE PERMANENT/REGION RESET COUNT ERROR CD CONTROL ERROR Write Drive ASCQ Description NO ADDITIONAL SENSE INFORMATION I/O PROCESS TERMINATED AUDIO PLAY OPERATION IN PROGRESS CLEANING REQUESTED... - Page 60 RECOVERED DATA WITH RETRIES AND/OR CIRC APPLIED RECOVERED DATA USING PREVIOUS SECTOR ID RECOVERED DATA WITHOUT ECC – RECOMMEND REASSIGNMENT RECOVERED DATA WITHOUT ECC - RECOMMEND REWRITE RECOVERED DATA WITHOUT ECC - DATA REWRITTEN ASCQ Description RECOVERED DATA WITH ERROR CORRECTION APPLIED RECOVERED DATA WITH ERROR CORR.
- Page 61 CLEANING FAILURE CANNOT WRITE - APPLICATION CODE MISMATCH CURRENT SESSION NOT FIXATED FOR APPEND ASCQ Description MEDIUM FORMAT CORRUPTED FORMAT COMMAND FAILED ENCLOSURE FAILURE ENCLOSURE SERVICES FAILURE UNSUPPORTED ENCLOSURE FUNCTION ENCLOSURE SERVICES UNAVAILABLE ENCLOSURE SERVICES TRANSFER FAILURE ENCLOSURE SERVICES TRANSFER REFUSED ROUNDED PARAMETER SAVING PARAMETERS NOT SUPPORTED MEDIUM NOT PRESENT...
- Page 62 LOG EXCEPTION THRESHOLD CONDITION MET LOG COUNTER AT MAXIMUM LOG LIST CODES EXHAUSTED FAILURE PREDICTION THRESHOLD EXCEEDED FAILURE PREDICTION THRESHOLD EXCEEDED (FALSE) LOW POWER CONDITION ON IDLE CONDITION ACTIVATED BY TIMER STANDBY CONDITION ACTIVATED BY TIMER IDLE CONDITION ACTIVATED BY COMMAND STANDBY CONDITION ACTIVATED BY COMMAND END OF USER AREA ENCOUNTERED ON THIS TRACK PACKET DOES NOT FIT IN AVAILABLE SPACE...
