Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola C650 GSM wireless phone. 5-Way Navigation Menu Key 032338o Scroll through menus & lists Left Soft Key Right Soft Key Perform function in...
Page 2
MOTOROLA and the Stylised M Logo are registered in the US Patent & Trademark Office. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners.
RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits. Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.
Motorola may exceed RF energy exposure guidelines. If you do not use one of the body-worn accessories approved or supplied by Motorola, and are not using the phone held in the normal use position, ensure the phone and its antenna are at least 1 inch (2.5 centimetres) from your body when...
Facilities Turn off your phone in any facility where posted notices instruct you to do so. These facilities may include hospitals or health care facilities that may be using equipment that is sensitive to external RF energy. Aircraft When instructed to do so, turn off your phone when on board an aircraft.
Use While Driving Check the laws and regulations on the use of phones in the area where you drive. Always obey them. When using your phone while driving, please: • Give full attention to driving and to the road. • Use hands-free operation, if available. •...
(short circuit) and become quite hot. Exercise care in handling any charged battery, particularly when placing it inside a pocket, bag, or other container with metal objects. Use only Motorola original batteries and chargers. Your battery or phone may contain symbols, defined as follows: Symbol Definition Important safety information will follow.
or playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your doctor before playing video games on your phone or enabling a blinking- lights feature on your phone.
European Union Directives Conformance Statement Hereby, Motorola declares that this product is in compliance with • The essential requirements and other relevant provisions of Directive 1999/5/EC • All other relevant EU Directives IMEI: 350034/40/394721/9 0168 Product Approval Type: MC2-41H14 Number The above gives an example of a typical Product Approval Number.
Getting Started About This Guide This guide describes the basic features of your Motorola wireless phone. Optional Features This label identifies an optional network, SIM card, or subscription-dependent feature that may not be offered by all service providers in all geographical areas. Contact your service provider for more information.
Caution: To prevent injuries or burns, do not allow metal objects to contact or short-circuit the battery terminals. To maximise your battery’s performance: • Always use Motorola Original batteries and battery chargers. The phone warranty does not cover damage caused from using non-Motorola batteries and/or battery chargers.
Warning: Never dispose of batteries in a fire because they may explode. Installing the Battery Your phone is designed to use only Motorola Original batteries and accessories. We recommend that you store batteries in their protective cases when not in use.
032341o 032340a Installing a Lanyard You can attach a lanyard to your phone to help you carry it. To install a lanyard, remove the back cover. Pull one end of the lanyard 032371a 032371a through a lanyard notch, then through the loop in the other end of the lanyard (as shown).
Charging the Battery New batteries are shipped partially charged. Before you can use your phone, you need to install and charge the battery as described below. Some batteries perform best after several full charge/ discharge cycles. Action 1 Plug the travel charger into the bottom of your phone.
Turning Your Phone On Action 1 Press and hold O for 2 Power Key seconds to turn on the phone. 032346o 2 If necessary, enter your SIM card PIN code and press (+) to unlock the SIM card. Caution: If you enter an incorrect PIN code 3 times in a row, your SIM card is disabled and your phone displays SIM Blocked.
Making a Call Press 1 keypad keys dial the phone number make the call end the call and “hang up” the phone when you are finished Alternatively access the Phonebook by pressing menu M > > scroll through to required entry > Phone Book Send Answering a Call...
Highlight Features You can do much more with your phone than make and receive calls! This section describes some of your phone’s highlight features. Taking and Sending a Photo To activate your phone’s camera: Find the Feature Multimedia Camera > >...
Page 21
Press take a photo CAPTURE view storage options STORE If you choose to store the photo, continue to step 3. delete the photo and return to the active DISCARD viewfinder scroll to Send in Message Store Only , or , or Apply as Wallpaper Apply as Screen Saver Send to Blog...
Sending a Multimedia Message A Multimedia Messaging Service (MMS) message contains one or more slides with text and embedded media objects (including photos, pictures, animations, sounds, voice records, and/or video clips). You can send the multimedia message to other wireless phone users, and to email addresses.
Page 23
Press add a phonebook entry to the list of recipients. Press (-) when DONE you are finished. scroll to Subject select CHANGE Subject 7 keypad keys enter the subject store the subject select CHANGE Attachments 10 S scroll to , or Picture Sounds Video...
Receiving a Multimedia Message When you receive a multimedia message, your phone displays the r (message waiting) indicator and a notification, and sounds an alert. New Message Press open the message READ Multimedia messages that you receive can contain different media objects: •...
The video clip displays in the video clip playback screen. 032349a Press S : to Timer indicates % pause or play the VIDEO played video AREA BACK PAUSE Return to previous Pause video clip screen Press M to open sub-menu Using Event Lights When event lights are activated, your phone displays a light pattern to notify you of the following events: incoming calls, incoming calls...
Using Ring Lights Select a light pattern to display when you receive an incoming call (in addition to or instead of a ring/vibrate alert). To select a light pattern: Find the Feature M > Settings Ring Styles > Ring Lights >...
Learning to Use Your Phone See page 1 for a basic phone diagram. Using the Display The home screen is displayed when you are not on a call or using the menu. You must be in the home screen to dial a phone number. 0323550a Date Service Provider...
Page 28
The following status indicators can display: 6. Messaging 7. Message 4. Roam 5. Active Line Presence 1. Signal 10. Battery Level Strength Service Provider 10/15/04 9. Ring Alert 2. GPRS 8. Location 3. Data STYLES CAMERA Transmission 1. Signal Strength Indicator Vertical bars show the strength of the network connection.
Page 29
3. Data Transmission Indicator Shows connection and data transmission status. Indicators can include: 4 = secure packet data 7 = insecure packet data transfer transfer 3 = secure application 6 = insecure application connection connection 2 = secure Circuit Switch Data 5 = insecure CSD call (CSD) call 4.
Page 30
6. Messaging Presence Indicator Shows when Instant Messaging (IM) is active. Indicators can include: P = IM active I = available for IM _ = busy Q = invisible to IM J = available for phone calls X = offline When a Java application is active, a ` (Java midlet) indicator can display in this location.
8. Location Indicator Your phone may be able to send location information to the network during an emergency call. Indicators show when your phone is sending location information: Ö = location on Ñ = location off 9. Ring Style Indicator Shows the ring style setting.
Using Menus From the home screen, press M to enter the main menu. Menu Key Highlighted Menu Enter menu system Feature Icon Right Soft Key Left Soft Key Perform right function Games & Apps Perform left function EXIT SELECT 5-Way Navigation End Key Exit menu without Scroll up, down, left,...
Selecting a Menu Feature To select a menu feature, starting from the home screen: Find the Feature M > Recent Calls Dialled Calls > This example shows that from the home screen, you must press M, scroll to and select s from the main menu, then Recent Calls .
When an option displays a list of possible numeric values, press a number key to set the value. Entering Text Some features require you to enter information. Press S to scroll Highlighted Option down to other Entry Details options Press CHANGE (+) Name: John Smith Category: General to view details of...
Choosing a Text Entry Method Multiple text entry methods make it easy for you to enter names, numbers, and messages. The method (for example, iTAP predictive text or TAP input mode) you select remains active until you select another method. Press # in any text entry screen to select one of the following entry methods: The primary text entry method (see below to set).
Using Capitalisation Press 0 in any text entry screen to change text case. The following indicators show capitalisation status: U = no capital letters V = capitalise next letter only T = all capital letters Text Entry Method Indicators When you select the text entry method, the Primary Secondary...
Page 37
Press 1 A keypad key one or select a letter, number, or symbol more times 2 keypad keys enter remaining characters. Tip: Press S right to accept a word completion, or * to insert a space. store the text In a text entry screen, you can press # to switch entry methods. is not available as the entry Tap Extended...
When you enter 3 or more characters in a row, your phone may guess the rest of the word. For example, if you enter you might prog see: Press S c to Character displays accept program, or at insertion point press * to reject Ab 1 it and enter a...
Page 39
enter a space (hold to enter a return) change text entry method (hold for default) Note: This chart may not reflect the exact character set available on your phone. In an email address or URL editor, 1 first shows common characters for that editor. Tap Method Text Entry Rules •...
For example, if you press 7764, letter combinations that match your keypresses display: Press S d to accept Program Ab 1 Prog | Press S c to 032359o highlight another combination. Prog Proh Spoi Press * to enter DELETE SELECT Prog and a space Press DELETE (-) to Press SELECT (+)
Press lock a highlighted combination SELECT You can press keypad keys to add more letters to the end of the combination. enter the highlighted combination when it spells a word A space is automatically inserted after the word. If you enter a word your phone does not recognise, the phone stores it to use as one of your word options.
Press lock a highlighted combination SELECT You can press keypad keys to add more symbols to the end of the combination. enter the highlighted combination Symbol Chart Use this chart as a guide for entering characters with symbol method. . ? ! , @ ' - _ : ; ( ) & " ~ 1 0 ¿ ¡ % £ $ ¥ ¤ £ + x * / \ [ ] = >...
Deleting Letters and Words Place the cursor to the right of the text you want to delete, and then: Action Press (-) to delete one letter at a time. DELETE Hold (-) to delete the entire message. DELETE Changing a Code, PIN, or Password Your phone’s 4-digit unlock code is originally set to 1234, and the 6- digit security code is originally set to 000000.
Locking Your Phone Manually M > Find the Feature Settings Security > Phone Lock Lock Now > > Press 1 keypad keys enter your unlock code lock the phone Unlocking Your Phone Your phone’s unlock code is originally set to 1234. Your service provider may reset the unlock code to the last 4 digits of your phone number.
If You Forget a Code, PIN, or Password Your phone’s 4-digit unlock code is originally set to 1234, and the 6- digit security code is originally set to 000000. Your service provider may reset the unlock code to the last 4 digits of your phone number before you receive your phone.
Using the Phonebook This section briefly describes basic phonebook operations. For more information about using the phonebook, see page 68. Shortcut: To open your phonebook from the home screen, you can press S up or down. Storing a Phone Number Enter a phone number in the home screen, then press STORE to create a phonebook entry with that number.
Dialling a Number Press M > > entry to call N. Phonebook Note: You can also access the Phonebook from idle display by pressing S , depending on local settings. Tip: To quickly highlight entries in your list: If your entries Phonebook are sorted by , press an entry’s speed number to highlight it.
Setting Up Your Phone Storing Your Name and Phone Number To store or edit your name and phone number information on your SIM card: M > Find the Feature Settings Phone Status > My Tel. Numbers > Shortcut: Press M # from the home screen to edit your name and phone number.
Setting a Ring Style Your phone rings or vibrates to notify you of an incoming call or other event. This ring or vibration is called an alert. You can select one of five different ring styles. The ring style indicator in the display shows the current ring style (see page 31). To set a ring style: Find the Feature M >...
Press 3 S up or down scroll to a picture/animation Scroll to to turn off the (None) wallpaper image. select the image SELECT scroll to Layout adjust the image layout CHANGE scroll to , or Centre Tile Fit-to-screen places the image in the centre Centre of the display.
Press scroll to Picture open the picture viewer CHANGE 3 S up or down scroll to a picture/animation Scroll to to turn off the screen (None) saver image. select the image SELECT scroll to Delay set the delay interval CHANGE scroll to the inactivity interval that triggers the screen saver confirm the delay setting...
Setting Display Timeout Set the display to turn itself off when no activity is detected for a specified time. Find the Feature M > Settings Initial Setup > Display Timeout > 52 - Setting Up Your Phone...
Calling Features For basic instructions on how to make and answer calls, see page Changing the Active Line Change the active phone line to make and receive calls from your other phone number. Note: This feature is available only for dual-line-enabled SIM cards.
Using Automatic Redial When you receive a busy signal, your phone displays Call Failed, Number Busy To redial the phone number: Press N or activate automatic redial RETRY Your phone automatically redials the number. When the call goes through, your phone rings or vibrates one time, displays , and then connects the call.
You can override the default caller ID setting when you make a call. While dialling (with digits visible in the display): Press M > hide or show your caller ID for the Hide ID/Show ID next call Cancelling an Incoming Call While the phone is ringing or vibrating: Press cancel the incoming call...
Dialling International Numbers Press and hold 0 to insert the local international access code ( for the country from which you are calling. Viewing Recent Calls Your phone keeps lists of the calls you recently received and dialled, even if the calls did not connect. The lists are sorted from newest to oldest entries.
Option Description Create a phonebook entry with the number Store in the field. Delete the entry. Delete Delete all entries in the list. Delete All Hide or show your caller ID for the next Hide ID/Show ID call. Open a new text message with the number Send Message in the field.
Using the Notepad The most recent set of digits entered on the keypad are stored in your phone’s notepad memory. This can be a phone number that you called, or a number that you entered but did not call. To retrieve the number stored in the notepad: Find the Feature M >...
To speed dial a phonebook entry: Press 1 keypad keys enter the speed dial number for the entry you want to call submit the number call the entry Calling With 1-Touch Dial To call phonebook entries 1 to 9, press and hold the single-digit speed dial number for one second.
Receiving a Voicemail Message When you receive a voicemail message, your phone displays the f (voicemail message) indicator and a New VoiceMail notification. Press listen to the message CALL The phone calls your voicemail phone number. If no voicemail number is stored, your phone prompts you to store a number. Storing Your Voicemail Number If necessary, use the following procedure to store your voicemail phone number on your phone.
Using Call Waiting When you are on a call, an alert tone sounds to indicate that you have received a second call. Press answer the new call switch between calls SWITCH connect the 2 calls LINK M > end the call on hold End Call On Hold You must turn on call waiting to use the feature.
Transferring a Call You can announce that you are transferring an active call to another party, or you can directly transfer the call. Announce the Call Transfer Find the Feature M > Hold Press 1 keypad keys dial the number where you are transferring the call call the number and speak to the person who answers...
Phone Features Menu Map Main Menu á Phonebook Web Access • Browser Recent Calls • Web Shortcuts • Received Calls • Stored Pages • Dialled Calls • History • Notepad • Go To URL • Call Times • Browser Setup •...
Feature Quick Reference This section helps you locate features on your phone that are not described in this guide. Calling Features Feature Description Conference Call During a call: M > , dial next number, Hold press N, press LINK Call Diverting Set up or cancel call diverting: M >...
Feature Description Use MMS Open an MMS template with Template preloaded media: M > > Messages New Message > MMS Templates Read Message Read a new text or multimedia message that you have received: Press (+). READ Store Message Go to a multimedia message Objects slide, then: M >...
Page 67
Feature Description Open Active Open a conversation in Conversation progress: From your , highlight a Contact List name in , press Conversations (+). VIEW End Conversation From the conversation display: M > End Conversation Log Out Log out of instant messaging: Select from the Log Out...
Page 68
Phonebook Feature Description Create Entry Create a new phonebook entry: Type in telephone number > > enter other details Store Create Group Create a group mailing list as a Mailing List phonebook entry: M > Phonebook M > > Mailing List Dial Number Call a number stored in the phonebook: M >...
Page 69
Feature Description Set Picture ID for Assign a picture to display when you Entry receive calls from an entry: M > > entry Phonebook M > > > picture Edit Picture Note: The option is not available for Picture entries stored on the SIM card. Set Category for Set the category for a phonebook entry: Entry...
Feature Description Set Primary Set the primary number for a phonebook Number entry with multiple numbers: M > , scroll to entry, press Phonebook M > > phone number Set Primary 1-Touch Dial Set 1-touch dial to call entries stored in your phone memory phonebook or the SIM card phonebook: M >...
Page 71
Feature Description Clock View Display an analogue clock or digital time readout in the home screen: M > > > Settings Personalise Home Screen > Clock Menu View Display the main menu as graphic icons or as a text-based list: M >...
Menu Features Feature Description Language Set menu language: M > > > Settings Initial Setup Language Master Reset Reset all options except unlock code, security code, and lifetime timer: M > > > Settings Initial Setup Master Reset Master Clear Reset all options except unlock code, security code, and lifetime timer, and clear all user settings and entries except SIM...
Feature Description Quick Dial Your service provider may program your phone with one or more quick dial numbers, such as the customer service number. Dial preprogrammed phone numbers: M > > Office Tools Dialling Services > Quick Dial DTMF Tones Activate DTMF tones: M >...
Feature Description Call Times View call timers: M > > Recent Calls Call Times In-Call Timer Display time or cost information during a call: M > > Settings In-Call Setup > In-Call Timer Call Cost View call cost information: M > >...
Feature Description Auto Handsfree Automatically route calls to a car kit when connected: (car kit) M > > Settings Car Settings > Auto Handsfree Power-Off Delay Set the phone to stay on for a specified time after the ignition (car kit) is switched off: M >...
Network Features Feature Description Network Settings View network information and adjust network settings: M > > Settings Network Personal Organiser Features Feature Description Create Datebook Create a new datebook event: Event M > > , highlight the Office Tools Datebook day, press the centre select button, press M >...
Feature Description Calculator Calculate numbers: M > > Office Tools Calculator Currency Convert currency: Converter M > > Office Tools Calculator M > Exchange Rate Enter exchange rate, press (+), enter amount, and select in the bottom of the display. Security Feature Description...
News and Entertainment Feature Description Launch Micro- Start a micro-browser session: Browser M > > Web Access Browser Download Objects Download a picture, sound, or from Web Page phone theme from a Web page: Highlight the file, press (+), press (+).
Page 79
Feature Description Launch Game or Launch a Java game or Application application: M > , highlight the Games & Apps application, press SELECT Manage Pictures Manage pictures and animations: M > > Multimedia Pictures Manage Sounds Manage ring tones, sounds that you have composed or downloaded: M >...
Specific Absorption Rate Data This model phone meets international standards for exposure to radio waves Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population.
Page 81
2 CENELEC is a European Union standards body. 3 Additional related information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product. Specific Absorption Rate Data - 81...
Index extending battery life 14, 51 installing 15 accessories 13 level indicator 31 accessory connector port 1 browser. See micro-browser active line indicator 29 active line, changing 53 alarm clock 76 calculator 77 alert call creating 79 alert, turning off 18 defined 49 answering 19 setting 18, 49, 70...
Page 83
speakerphone 74 customising the menu 71 timers 74 transferring 62 unanswered call 57 data call 75 Call Failed, Number Busy date, setting 48 message 54 datebook 76 call waiting 61 dialled calls list 56 caller ID 21, 54 dialling a number 19, 72, 73 calling line identification.
Page 84
location 31 message 30 fax call 75 message waiting 24 5-way navigation key 1, 31 messaging presence 30 fixed dial 72 ring style 31 roam 29 signal strength 28 games 78 text case 36 GPRS indicator 28 text entry method 30, 36 groove tunes 79 transmission 29 voicemail message 30, 60...
Page 85
voice 1 using 32 volume control 1, 18 view, changing 71 keypad menu key 1 volume, setting 70 message chat 67 MMS template 66 MMS, defined 22 language, setting 72 multimedia message 65 left soft key reading 66 functions 1, 27 text 65, 66 personalising 71 message indicator 30...
Page 86
ring style 18, 49, 70 security code 43 network settings 76 time, setting 48 notepad 58 turning on/off 18 number unlock code 43 storing your number 48 unlocking 18, 43 viewing your number 19 phone number numbers, entering 41 active line indicator 29 active line, changing 53 attaching 2 numbers 58 1-touch dial...
Page 87
voice dialling 68 right soft key photo functions 1, 27 downloading 78 personalising 71 picture ID 21, 54 ring lights 26 sending 20 ring style indicators 31 taking 20 ring style, setting 18, 49, 70 picture ring tone downloading 78 creating 79 screen saver 50 downloading 78...
Page 88
SIM card defined 13 tap method text entry 36 installing 13 telephone number locking 77 storing your number 48 PIN code entry 18 viewing your number 19 PIN code, changing 43 text PIN2 code, changing 43 capitalisation, changing 36 precautions 13 character chart 38 SIM Blocked message 18, entering 34...
