In the interests of user-safety (Required by safety regulations in some countries) the set should be re-
stored to its original condition and only parts identical to those specified should be used.
• SPECIFICATIONS ............................................ 2
• IMPORTANT SERVICE SAFETY
NOTES (for USA) .............................................. 3
• NOTE TO SERVICE PERSONNEL .................. 5
• OPERATION MANUAL ..................................... 9
• DIMENSIONS ................................................. 14
• REMOVING OF MAJOR PARTS .................... 15
• RESETTING THE TOTAL LAMP TIMER ........ 18
• THE OPTICAL UNIT OUTLINE ....................... 20
• ELECTRICAL ADJUSTMENT ......................... 22
• TROUBLE SHOOTING TABLE ....................... 28
• BLOCK DIAGRAM .......................................... 40
SERVICE MANUAL
MODELS
CONTENTS
Page
• OVERALL WIRING DIAGRAM ....................... 42
• DESCRIPTION OF SCHEMATIC DIAGRAM .. 44
• WAVEFORMS ................................................. 45
• SCHEMATIC DIAGRAM ................................. 46
• PRINTED WIRING BOARD ASSEMBLIES .... 80
• PARTS LIST
Ë ELECTRICAL PARTS ............................... 101
Ë CABINET AND MECHANICAL PARTS .... 113
Ë ACCESSORIES PARTS ........................... 117
Ë PACKING PARTS ..................................... 117
• PACKING OF THE SET ................................ 118
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
XV-Z3000
DT-500
XV-Z3000
DT-500
S26R9XV-Z3000
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XV-Z3000 and is the answer not in the manual?

Questions and answers

john
April 30, 2025

beeping device location

0

Related Manuals for Sharp XV-Z3000

Summary of Contents for Sharp XV-Z3000

  • Page 1 XV-Z3000 DT-500 SERVICE MANUAL S26R9XV-Z3000 PROJECTOR XV-Z3000 DT-500 MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be re- stored to its original condition and only parts identical to those specified should be used.

  • Page 2: Specifications

    Video cable (XV-Z3000E/K), Operation manual When STANDBY Mode is set to "Eco" As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specifica- tion figures indicated are nominal values of production units. There may be some deviations from...

  • Page 3: Important Service Safety Notes (For Usa)

    XV-Z3000 DT-500 IMPORTANT SERVICE SAFETY NOTES (for USA) Ë Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and servicing guidelines as follows: WARNING » Use an AC voltmeter having with 5000 ohm per volt, 1.
  • Page 4 XV-Z3000 DT-500 PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ë Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT • Utiliser un voltmètre CA d'une sensibilité d'au moins 5000Ω/V pour mesurer la chute de tension CA en travers...

  • Page 5: Note To Service Personnel

    XV-Z3000 DT-500 NOTE TO SERVICE NOTE POUR LE PERSONNEL PERSONNEL D’ENTRETIEN 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6...

  • Page 6: Lamp Replacement

    XV-Z3000 DT-500 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6...

  • Page 7: Power Unit

    XV-Z3000 DT-500 WARNING: High brightness light source, do not stare into the beam of light, or view directly. Be especially careful that children do not stare directly in to the beam of light. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO MOISTURE OR WET LOCATIONS.
  • Page 8 XV-Z3000 DT-500 Precautions for using lead-free solder 1 Employing lead-free solder "PWBs" of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 9: Operation Manual

    XV-Z3000 DT-500 Operation Manual Projector Top View Power Lamp indicator indicator STANDBY/ON button For turning the Temperature warning power on and indicator putting the projector into INPUT buttons ('/") standby mode. For switching input mode 1, 2, 3, 4, 5 or 6.

  • Page 10: Rear View

    XV-Z3000 DT-500 Rear View Exhaust vent Intake vent emote control sensor (rear) AC socket Kensington Connect the Security Standard supplied Power cord. connector ear adjustment foot erminals Terminal Description INPUT 1, 2 terminal Connecting video equipment with component output terminal (DVD player, DTV decoder, DVD recorder with hard disc, etc.).
  • Page 11 XV-Z3000 DT-500 ON button For turning the power on. INPUT 1, 2, 3, 4, 5 and 6 STANDBY button buttons For putting the For switching to the projector into the respective input modes. standby mode. MENU button KEYSTONE button For displaying adjustment For entering the and setting screens.

  • Page 12: Inserting The Batteries

    XV-Z3000 DT-500 Inserting the Batteries Press the ' mark on the cover and slide it in the direction of the arrow. Insert the batteries. • Insert the batteries making sure the polarities correctly match the marks inside the battery compartment.

  • Page 13: Connection Pin Assignments

    XV-Z3000 DT-500 Connection Pin Assignments COMPUTER-RGB/COMPONENT INPUT5 Terminal: 15-pin Mini D-sub female connector COMPUTER-RGB Input Component Input Video input (red) Video input (green/sync on green) Video input (blue) Not connected Not connected Not connected Not connected Earth (red) Earth (P...

  • Page 14: Dimensions

    XV-Z3000 DT-500 DIMENSIONS Units: inches(mm) φ9 (69.2) (77.5) (80) (315) (33.8) (46.2) (65.5) (75)

  • Page 15: Removing Of Major Parts

    XV-Z3000 DT-500 REMOVING OF MAJOR PARTS 1. Removing the lamp door and the lamp unit 1-1. Loosen the lamp door fixing screw. Lift off the lamp door. 1-2. Remove 2 lamp unit fixing screws to detach the lamp unit. Lamp Door Lamp Unit 2.
  • Page 16 XV-Z3000 DT-500 3. Removing the main PWB unit and rear RC reciever PWB Unit 3-1. Remove 1 Rear RC reciever PWB fixing screws to detach the Rear RC reciever PWB unit. 3-2. Remove all connectors from the main PWB unit.
  • Page 17 XV-Z3000 DT-500 5. Removing the optical mechanism unit and front RC receiver PWB 5-1. Remove 4 optical mechanism unit fixing screws to detach the optical mechanism unit. 5-2. Remove the RC PWB unit. Optical Mechanism Unit RC PWB Unit 6. Removing the photosensor PWB unit, blower fan, DMD PWB, and DMD 6-1.

  • Page 18: Resetting The Total Lamp Timer

    The lamp life (percentage) can be checked with the on-screen display. ■ Purchase a replacement lamp of type AN-100LP from your place of purchase, nearest Sharp Authorized Projector Dealer or Service Center.
  • Page 19 (Standby) warning abnormally ventilation. indicator high. • Cooling fan • Take the projector to your breakdown nearest Sharp Authorized • Internal circuit Projector Dealer or Service failure Center for repair. • Clogged air intake Lamp Green on Red on The lamp does •...

  • Page 20: The Optical Unit Outline

    XV-Z3000 DT-500 THE OPTICAL UNIT OUTLINE Layout for proper setup of the optical components and parts (top view) (Schematic diagram) Projection lens Illumination lens 2 Illumination lens 1 Reflection mirror Plastic Lens Color wheel Lamp UV Glass Rod Integrator Item...
  • Page 21 XV-Z3000 DT-500 If shading shown in Figure 1 appears on the screen after replacing DMD, turn the adjustment screw of the optical engine to adjust the lighting area of DMD. 1. Loosen the adjustment lever fixing screw 1. After adjusting the lighting area with the adjustment lever 2, tighten the adjustment lever fixing screw 1.

  • Page 22: Electrical Adjustment

    "SS2" on SS menu. set for 15 minutes. Model setting (Process menu) 1. Set as below. 1. Select the following group XV-Z3000: 1 (default) and subject. DT-500: 0 Group: CONFIRM Subject: MODEL-SELECT Adjustment of 1. Signal input: Send 256 1.
  • Page 23 XV-Z3000 DT-500 Check items Adjusting point Adjusting conditions Adjusting procedure Adjustment of 1. Feed 10-step signal with 1. Check the fixed value. Component 480P component 100% C-R-OS : 257 offset C-B-OS : 256 amplitude. 2. Select the following group and subjects.
  • Page 24 1. The model name appears in the MODEL field, and version check Group : INFO/VERSION. the firmware version in the VERSION field. Check that they are correct. MODEL : DT-500 (MODEL-SELECT=0) MODEL : XV-Z3000 (MODEL-SELECT=1) Delivery set- 1. Make the following settings. tings Destination Process...
  • Page 25 XV-Z3000 DT-500 1. Calling and quitting the process mode with the control keys on this model. ∗ Although it is possible for the process OUT to exit using the process menu, the IN/OUT toggle command is also available considering the existing specification.
  • Page 26 XV-Z3000 DT-500 » Adjustment mode process menu Default Default 1st Layer 2nd Layer 1st Layer 2nd Layer ADJUST CW/Auto KS CW-INDEX INFO VERSION MODEL — VER. — K-SENS (127) PATTERN R-CONT RGB50 G-CONT CORSS B-CONT STEP R-BRIGHT COLOR G-BRIGHT B-BRIGHT...
  • Page 27 (Q C N W -E007WJZZ) [Adjustment method] (1) Unplug the ballast unit lamp cable(QCNW-D573WJQZ) of the XV-Z3000, DT-500 projector from the lamp and connect the cable to the connecting cord (QCNW-E007WJZZ). (2) Connect the connecting cord (QCNW-E007WJZZ) to the adjustment jig ( UNTZA018WJZZ).

  • Page 28: Trouble Shooting Table

    XV-Z3000 DT-500 TROUBLE SHOOTING TABLE Checking the basic operation Has P1705 come off or is it Does the power LED light Fully insert the connector. loose? up or flash in red or green? Does the set function with its keys or the remote Go to "Main PWB check".
  • Page 29 XV-Z3000 DT-500 Main PWB check s 6 V applied to TL1731 Go to "Power supply and 13 V to TL1734? ballast PWB check". Check C1713 and s approx. 6 V applied to peripheral circuits. TL1710? s 1.5 V applied to...
  • Page 30 XV-Z3000 DT-500 DMD system check heck P6001 for breakage and solder crack and peripheral resistance for solder crack. heck S 9001 for breakage and solder crack. Is there any vertical stripe (block noise) on the Is approx. 7 V applied to...
  • Page 31 XV-Z3000 DT-500 Power supply PWB check Is 6 V applied to pins (7) and (8) of the connector P704? Is 13 V applied to pins (3) Check peripheral circuits of and (4) of the connector IC703. P704? Does the lamp turn on? Check the main PWB.
  • Page 32 XV-Z3000 DT-500 Are connectorsP701 and Securely insert the connectors. P702 fully inserted? Is AC voltage between 100 Replace F701. − 240 V applied to both ends of C707? Is the bimetal broken? Press the red button on the bimetal. (Connection between 1 and...
  • Page 33 XV-Z3000 DT-500 Checking the lamp light-up Go to "Check when the Does the lamp turn on lamp turns off soon after when the power is turned turning on". Securely insert the Is the lamp tight in the connectors. socket? Has the FPC cable to...
  • Page 34 XV-Z3000 DT-500 Check when the lamp turns off soon after turning on Have connectors P1702, P1721, P1722, P1723 and Securely insert the P1724 come off or are they connectors. loose? Is each cooling fan Check the cooling fan. rotating? Check peripheral circuits of Is approx.
  • Page 35 XV-Z3000 DT-500 RGB signal check Send RGB signal from INPUT 5. Select INPUT 5 using keys on the main unit or the remote control. Is image displayed normally? Are picture signals sent to Check Q4003, Q4004, TL3001, TL3002 and Q4005 and the peripheral TL3003? circuits.
  • Page 36 XV-Z3000 DT-500 Component signal check Send component signal of 1080i (or 720P) from INPUT 1 or INPUT 2. Select INPUT 1 or INPUT 2 using keys on the main unit or the remote control. Is image displayed normally? Are picture signals sent to Check IC4002 and the peripheral circuits.
  • Page 37 XV-Z3000 DT-500 S-VIDEO (INPUT 3) VIDEO (INPUT 4) check check Send S-Video signal (color Send VIDEO signal from signal) from INPUT 3. INPUT 4. Use buttons on Select INPUT 3 using keys the main unit or the remote on the main unit or the control to select INPUT 4.
  • Page 38 XV-Z3000 DT-500 HDMI input is not displayed. Do pin 19 of HDMI terminal Check Q3905 and HPD become to "H" (5V) when line of IC6202. connecting a cable? Is TM DS signal fed to Is IC3902 accessed via I2C Check the setting of DVD...
  • Page 39 XV-Z3000 DT-500 - M E M O -...

  • Page 40: Block Diagram

    XV-Z3000 XV-Z3000 DT-500 DT-500 BLOCK DIAGRAM...

  • Page 41: Overall Wiring Diagram

    XV-Z3000 XV-Z3000 DT-500 DT-500 OVERALL WIRING DIAGRAM N0364TA LAMP FAN P 72 VENTILATE FAN B+ 2V B+ 2V B+ 2V B+ 2V LOCK DADADR0 DDB 5N N0364TA DADADR DDB 5P EXHAUST FAN EXHAUST FAN P 722 DADADR2 DDB 4N DADADR3...

  • Page 42: Description Of Schematic Diagram

    XV-Z3000 DT-500 DESCRIPTION OF BESCHREIBUNG DES SCHEMATIC DIAGRAM SCHEMATISCHEN SCHALTPLANS VOLTAGE MEASUREMENT CONDITION: SPANNUNGSMESSUNGEN: 1. Voltages at test points are measured at the 1. Spannungen an den Prüfpunkten werden bei einer supply voltage of AC 220V. Signals are fed by a color...
  • Page 43 XV-Z3000 DT-500 WAVEFORMS 1 TL1740 2 TL6004 3 TL1727 L-POW/SYNC CWY1 CWINDEX H:2msec H:400µsec H:4msec V:1V V:2V V:1V Colour Bar Colour Bar Colour Bar 6 TL3313 4 TL3010 5 TL3009 TE8200_HS TE8200_VS H:10µsec H:4msec H:40µsec V:1V V:1V V:1V XGA60Hz XGA60Hz...
  • Page 44 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-1/11...
  • Page 45 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-2/11...
  • Page 46 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-3/11...
  • Page 47 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-4/11...
  • Page 48 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-5/11...
  • Page 49 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-6/11...
  • Page 50 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-7/11...
  • Page 51 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-8/11...
  • Page 52 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-9/11...
  • Page 53 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-10/11...
  • Page 54 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë MAIN UNIT-11/11...
  • Page 55 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë DMD UNIT-1/2...
  • Page 56 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë DMD UNIT-2/2...
  • Page 57 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë BALLAST POWER UNIT å AND SHADED COMPONENTS=SAFETY RELATED PARTS...
  • Page 58 XV-Z3000 XV-Z3000 DT-500 DT-500 Ë BALLAST CONTROL UNIT å AND SHADED COMPONENTS=SAFETY RELATED PARTS...
  • Page 59 XV-Z3000 DT-500 Ë PHOTOSENSOR UNIT...
  • Page 60 XV-Z3000 DT-500 Ë R/C UNIT...
  • Page 61 XV-Z3000 DT-500 Ë REAR R/C UNIT(XV-Z3000)
  • Page 62 XV-Z3000 DT-500 Ë REAR R/C UNIT(DT-500)

  • Page 63: Printed Wiring Board Assemblies

    XV-Z3000 XV-Z3000 DT-500 DT-500 PRINTED WIRING BOARD ASSEMBLIES MAIN Unit (Side-A)
  • Page 64 XV-Z3000 XV-Z3000 DT-500 DT-500 P1702 P1701 P6502 P1721 SC6001 C1735 R1702 D1706 R1800 R1741 C1729 R1703 C1734 C1751 C1744 FB1701 D1702 C1707 FB1713 C2001 C1704 C1706 FB2004 FB2002 L1702 R2004 FB1712 C1743 R6528 R6505 C2004 R2037 C2002 R6529 FB6503 IC1702...
  • Page 65 XV-Z3000 XV-Z3000 DT-500 DT-500 MAIN Unit (Side-B)
  • Page 66 XV-Z3000 XV-Z3000 DT-500 DT-500 P6001 IC1716 Q1709 Q1708 Q1707 TH6501 R2201 R2208 D1711 R1755 R6216 R6215 TH6502 R1771 C2248 X2201 C1701 R1701 IC1718 D1701 C2252 R2025 C6510 FB6505 C2251 R1756 R2041 R1721 C1749 R1782 C6508 R2038 R2239 R6233 D6003 D6004...
  • Page 67 XV-Z3000 DT-500 DMD Unit (Side-A) SC9001 R9003 C9002 R9001 TH9002 C9001 R9002 C9506 C9508 C9507 C9509 C9504 FB9303 R9304 FB9301 C9303 C9317 C9304 C9316 C9315 R9302 L9301 D9303 C9308 C9306 C9307 IC9301 FB9302 C9313 R9306 R9301 C9318 R9305 C9321 D9301...
  • Page 68 XV-Z3000 DT-500 DMD Unit (Side-B)
  • Page 69 XV-Z3000 XV-Z3000 DT-500 DT-500 BALLAST POWER Unit (Side A)
  • Page 70 XV-Z3000 XV-Z3000 DT-500 DT-500 BALLAST POWER Unit (Side B)
  • Page 71 XV-Z3000 XV-Z3000 DT-500 DT-500 FB701 R762 R708 FB702 R711 C703 R707 FB704 C713 C705 C706 R710 R703 R704 R705 R706 C702 D705 R759 R760 R702 IC902 R718 D704 C708 R732 R758 R757 R728 R712 R736 D722 C724 R735 R715 R752...
  • Page 72 XV-Z3000 DT-500 BALLAST CONTROL Unit (Side A) R7704 P7701 C7701 D7715 R7708 R7761 C7745 D7714 IC7707 C7709 C7727 R7719 D7713 R7775 R7776 C7742 C7712 C7713 C7728 R7726 C7710 R7793 D7711 R7721 C7715 IC7709 C7719 C7734 R7731 D7703 D7712 Q7707 C7717...
  • Page 73 XV-Z3000 DT-500 BALLAST CONTROL Unit (Side B) R7702 R7703 C7735 IC7704 R7705 C7702 R7739 Q7702 C7705 R7710 C7706 Q7701 C7708 C7703 R7748 R7781 C7704 R7788 Q7711 R7728 R7713 R7756 R7718 R7711 IC7705 R7786 R7785 R7701 C7711 R7716 R7753 R7735 C7723...
  • Page 74 XV-Z3000 DT-500 PHOTOSENSOR Unit (Side-A) PHOTOSENSOR Unit (Side B) R1109 R1108 R1106 R1107 PHOTOSENSOR Unit (Chip Parts Side B)
  • Page 75 XV-Z3000 DT-500 R/C Unit (Side-A) R/C Unit (Side B)
  • Page 76 XV-Z3000 DT-500 REAR R/C Unit (Side-A) REAR R/C Unit (Chip Parts Side A) REAR R/C Unit (Side-B)

  • Page 77: Main Unit

    Electrolytic Please call Toll-Free; 1-800-BE-SHARP C1746 VCKYCY1EF104ZY J 0.1 Ceramic C1749 VCEAPF1EW336MY J 33 Electrolytic in CANADA: Contact SHARP Electronics of Canada Limited C1750 VCEAPF1EW336MY J 33 Electrolytic Phone (416) 890-2100. C1751 VCEAPF1EW336MY J 33 Electrolytic C1752 VCEAPF1EW336MY J 33 Electrolytic ★...
  • Page 78 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code DUNTKD575FMF0 C3023 VCKYCY1EF104ZY J 0.1 Ceramic C3024 VCKYCY1EF104ZY J 0.1 Ceramic MAIN UNIT (Continued) C3025 VCKYCY1EF104ZY J 0.1 Ceramic C3026 VCKYCY1EF104ZY J 0.1 Ceramic C3027 VCKYCY1EF104ZY J 0.1...
  • Page 79 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code DUNTKD575FMF0 C3958 VCKYCY1EF104ZY J 0.1 Ceramic C3960 VCKYCY1EF104ZY J 0.1 Ceramic MAIN UNIT (Continued) C3961 VCKYCY1HB102KY J 1000p 50V Ceramic C3962 VCKYCY1HB102KY J 1000p 50V...
  • Page 80 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code DUNTKD575FMF0 FB1706 RBLN-A068WJZZY J Ferrite Bead, BLN-A068WJ AB FB1707 RBLN-A068WJZZY J Ferrite Bead, BLN-A068WJ AB MAIN UNIT (Continued) FB1708 RBLN-A187WJZZY J Ferrite Bead, BLN-A187WJ AB...
  • Page 81 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code DUNTKD575FMF0 L3303 VPD9M1R0JR57NY J Peaking, 1µH L3304 VPD9M1R8JR84NY J Peaking, 1.8µH MAIN UNIT (Continued) L3305 VPD9M1R8JR84NY J Peaking, 1.8µH L3306 VPD9M1R8JR84NY J Peaking, 1.8µH...
  • Page 82 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code R1805 VRS-CY1JF000JY 1/16W Metal Oxide DUNTKD575FMF0 R1806 VRS-CY1JF101JY J 100 1/16W Metal Oxide MAIN UNIT (Continued) R1807 VRS-TW2HF1R0JY J 1 1/2W Metal Oxide R1808 VRS-TW2HF1R0JY J 1...
  • Page 83 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code R3309 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide DUNTKD575FMF0 R3310 VRS-CY1JF221JY J 220 1/16W Metal Oxide MAIN UNIT (Continued) R3311 VRS-CY1JF221JY J 220 1/16W Metal Oxide...
  • Page 84 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code R4706 VRS-CY1JF103JY J 10k 1/16W Metal Oxide DUNTKD575FMF0 R4707 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide MAIN UNIT (Continued) R4708 VRS-TW2HF5R6JY J 5.6 1/2W Metal Oxide R4709 VRS-TW2HF5R6JY J 5.6...
  • Page 85 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code C9507 VCKYCY1HF104ZY J 0.1 Ceramic DUNTKD575FMF0 C9508 VCKYCY1HF104ZY J 0.1 Ceramic MAIN UNIT (Continued) C9509 VCKYCY1HF104ZY J 0.1 Ceramic C9510 VCKYCY1HF104ZY J 0.1 Ceramic C9511 VCKYCY1HF104ZY J 0.1...
  • Page 86 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code L901 RCiLCA126WJZZ J Coil DUNTKD147WEF3 L902 RCiLPA475WJZZ J Coil BALLAST POWER UNIT(Continued) LUG701 QLUGHA002WJZZ J Lug LUG702 QLUGHA002WJZZ J Lug å P701 å C735...
  • Page 87 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code C7712 VCKYCY1CB104KY J 0.1 Ceramic DUNTKD147WEF3 C7713 VCKYCY1HB102KY J 1000p 50V Ceramic BALLAST POWER UNIT(Continued) C7715 VCKYCY1EB103KY J 0.01 Ceramic C7716 VCKYCY1EB333KY J 0.033 25V...
  • Page 88 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code DUNTKD141WEF0 DUNTKD148WEF0 PHOTOSENSOR Unit BALLAST CONTROL UNIT (Continued) C1101 VCKYCY1EF104ZY J 0.1 25V Ceramic R7717 VRS-CY1JF151JY J 150 1/16W Metal Oxide C1102 VCKYCY1EF104ZY J 0.1...

  • Page 89: Cabinet And Mechanical Parts

    XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code QCNW-D518WJQZ J EA Wire CABINET AND MECHANICAL PARTS QCNW-D575WJPZ J Baimetal Wire XBBSN30P08000 J Screw, x2 XBPS830P08JS0 J Screw, x2 XEBSN30P12000 J Screw,x19 DBDYTA149WEF0...
  • Page 90 XV-Z3000 DT-500 CABINET AND MECHANICAL PARTS 11-1 2-2-3 2-2-2 2-2-1 2-1-3 2-1-4 2-1-1 2-1-2...
  • Page 91 XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code OPTICAL MECHANISM PARTS CCAPHA024WJSA J Lens Cap Ass'y CCHSKA019WEF4 J Optical Mechanism Unit (XV-Z3000U/E/K) CCHSKA019WEF6 J Optical Mechanism Unit (DT-500) LCHSKA019WJF2 J Engine Base...
  • Page 92 XV-Z3000 DT-500 OPTICS MECHANISM PARTS 4-31 4-32 4-29 4-29 4-38 4-36 4-32 4-33 4-11 4-33 4-12 4-20 4-13 4-34 4-30 4-29 4-26 4-14 4-21 4-16 4-29 4-14-1 4-29 4-29 4-37 4-29 4-25 4-14-3 4-14-2 4-35 4-14-4 4-23 4-19 4-18 4-17...

  • Page 93: Supplied Accessories

    XV-Z3000 DT-500 ★ ★ Ref. No. Part No. Description Code Ref. No. Part No. Description Code PACKING PARTS SUPPLIED ACCESSORIES (NOT REPLACEMENT ITEM) RRMCGA444WJSA J Remote Control unit SPAKCC445WJZZ - Packing Case — (XV-Z3000U) (XV-Z3000U/E/K) RRMCGA444WJSB J Remote Control unit...

  • Page 94: Packing Of The Set

    XV-Z3000 DT-500 PACKING OF THE SET Lens cap FRONT SIDE...
  • Page 95 XV-Z3000 DT-500...
  • Page 96 XV-Z3000 DT-500 © COPYRIGHT 2006 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
