Summary of Contents for Ground Hog C-71-5
- Page 1 DO NOT THROW AWAY IMPORTANT MANUAL MODEL C-71-5 TWO-MAN EARTH DRILL Operator’s Manual P.O.BOX 290 • San Bernardino, CA. 92402 Phone (909) 478-5700 • Fax (909) 478-5710 • (800) 922-4680 E-mail: sales@groundhoginc.com • www.groundhoginc.com...
-
Page 2: Warnings And Safety Instructions
Coming into contact with buried utilities while digging can cause severe • injuries or DEATH. Contact appropriate utility representatives to determine if/where electrical • cables, gas lines, water lines, etc. are buried BEFORE operation. C-71-5 Page 1 ®... - Page 3 4. Use only genuine replacement parts as rec- 4. Use only the # 1300 auger attachment pin and ommended by Ground Hog or the engine make sure that it is properly attached. manufacturer. 5. Be sure the auger bit stops turning when you release the throttle.
- Page 4 Because the C-71-5 is a hand operated, portable type machine, it is limited in what it is capable of doing. The job site, soil conditions, job specifications and operator experience may dictate that a different tool or method be used to do the job.
- Page 5 KEY POINTS OF THE C-71-5 Handle Bar Stop Switch ThrottleLever Gearbox Output shaft Belt Guard Auger Attachment Pin Auger Bit C-71-5 Page 4 ®...
- Page 6 Ground Hog or the engine operators causing injury and cause damage to manufacturer. the machine.
- Page 7 Always shut off all stop switches when not in use. • Keep children, bystanders and animals clear of earth drill at all times. • Secure the earth drill in a manner that will not allow it fall, tip over or roll. C-71-5 Page 6 ®...
